VAMP 210
Generator protection relay
Operation and configuration
instructions
Technical description

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 210 and is the answer not in the manual?

Questions and answers

Related Manuals for VAMP 210

Summary of Contents for VAMP 210

  • Page 1 VAMP 210 Generator protection relay Operation and configuration instructions Technical description...
  • Page 2 VAMP 210 Generator protection relay VAMP Ltd Operation and configuration Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...
  • Page 3 VAMP Ltd Generator protection relay VAMP 210 Operation and configuration VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 4: Table Of Contents

    6.1. PC user interface.............. 29 6.1.1. Using the VAMPSET program......... 29 6.2. Remote control connection........... 29 7. Commissioning configuration..........30 7.1. Factory settings..............30 7.1.1. Configuration during commissioning ....30 7.1.2. Configuration example ......... 31 Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 5: General

    VMMC.EN0xx. 1.1. Relay features The flexible multi-stage protection functions make the VAMP 210 ideal for small and medium sized generators. It features the following protection functions: Three overcurrent stages • One overcurrent stage with voltage restraint •...

  • Page 6: Operating Safety

    Any operational measures must be carries out according to national and local handling directives and instructions. Carefully read through the relay operation instructions before any relay operational measures are carried out. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 7: User Interface

    Operation and configuration User interface 2.1. General The VAMP 210 protection relay can be controlled in three ways: Locally with the push-buttons on the relay front panel • Locally using a PC connected to the serial port on the front •...

  • Page 8: Display

    Generator protection relay VAMP Ltd Operation and configuration 2.2.1. Display The VAMP 210 protection relay is provided with a back lit LCD dot matrix display. The display is divided into sections as shown in the next figure. lcdnaytt È È É...

  • Page 9: Indicators

    Internal relay fault, operates in parallel with the self supervision output relay Serial communication indicator Alarm Start indicator of protection stage Trip Trip indicator of protection stage A - C Can be programmed for application-related status indications VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 10: Local Panel Operations

    The possible navigating directions in each part of the menu are shown in the upper left corner by means of the black triangular symbols. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 11: Function Menu Table

    6. Push the INFO key to obtain additional information about any menu item. 7. Push the CANCEL key to revert to the normal display. 3.1.1. Function menu table MEAS (Measurements) POWER • CURRENTS • VOLTAGES • PHASE VOLTAGES • VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...
  • Page 12 • SET I> • LOG I> • LOG2 I> • I> event mask • I>> I>> STATUS • SET I>> • LOG I>> • LOG2 I>> • I>> event mask • Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...
  • Page 13 • SET2 IoDir> • LOG IoDir> • LOG2 IoDir> • Ioϕ> event mask • Io2> Io2> STATUS • SET Io2> • LOG Io2> • LOG2 Io2> • Io>2 event mask • VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...
  • Page 14 • SET U>> • LOG U>> • LOG2 U>> • U>> event mask • U1< U1< STATUS • SET U1< • LOG U1< • LOG2 U1< • U1< event mask • Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...
  • Page 15 • CONF (Configuration) DEVICE SETUP • POWER SCALING • CURRENT SCALING • VOLTAGE SCALING • Io1 SCALING • Io2 SCALING • DEVICE INFO • DATE/TIME SETUP • CLOCK SYNC • VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 16: Basic Menu Structure Of Protection Functions

    Order number of start 1 – 8, 1=latest 2002-08-22 Time stamp of event 20:34:11 67ms I> event mask: St_On Start on event St_Off Start off event Tr_On Trip on event Tr_Off Trip off event Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 17: Operating Levels

    The level is automatically closed when 10 minutes has elapsed since a key was pushed or a setting was done via the local port. The level can also be closed by giving the password 9999 VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 18: Opening Operating Levels

    RIGHT key and then setting the desired digit value using the UP key. 3. Push ENTER. 3.2.2. Changing passwords The set passwords can only be changed using a PC connected to the local RS-232 port on the relay. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 19: Operating Measures

    Submenu CURRENTS The CURRENTS display shows a list of parameters and their values. currents CURRENTS 308A MEAS 317A Evnt 309A 0.16A 50.010Hz Prot Figure 4.1-1 Current and frequency data. VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 20: Operation Indicators

    ENTER key. The latchings can also be reset via the communications bus or via a DI input configured for that purpose. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 21: Reading Event Register

    Figure 4.4-1 Selection of the Force function. 4. Push the ENTER key. 5. Push the UP or DOWN key to change the "OFF" text to "ON", i.e., to activate the Force function. VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 22: Setting Range Limits

    The readability of the LCD varies with the brightness and the temperature of the environment. The contrast of the display can be adjusted via the PC user interface, see chapter 6 on page Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 23: Configuration And Parameter Setting

    DOWN keys to change the digits. 6. Push the ENTER key to accept the new value. 7. If you want to leave the parameter value unchanged, then exit the edit state by pushing the CANCEL key. VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 24: Disturbance Recorder Menu Dr

    • Clear all links (ClrLnks) • Available links: DO, DI • Uline, Uphase • • U2/U1, U2, U1 • I2/Ign, I2/I1, I2, I1 • CosFii • PF, S, Q, P • Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 25: Configuring Digital Inputs Di

    In the Prot menu you can reset all counters (PROTECTION • SET/ClALL) Read the status of all protection functions (PROTECT • STATUS 1-3) Enable and disable protection functions (ENABLED • STAGES 1-3) Define the interlockings between signals. • VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 26: Setting Protection Function Parameters

    • Rated generator voltage (Ugn) • Rated generator current (Ign) (derived value) • Prime mover shaft power (Pm) • Calculated power CTxVT (CTxVT) (derived value) • Unit transformer used? (Trafo) • Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...
  • Page 27 DEVICE INFO (only display) Relay type (Type VAMP 210) • Serial number (SerN) • Software version (PrgVer) • DATE/TIME SETUP Date (Dat) • Time (Time) • Presentation style of date information (Style) • VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 28: Protocol Menu Bus

    IP address of the Name Server (NameSv) • IP address of the SNTP Server (NTPSvr) • IP port number for Protocol (Port) • IEC-60870-5-103 Slave address (Addr) • Transfer rate (bit/s) • Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 29: Pc Software

    ModBus, SPA_Bus, IEC 60870-5-103, ProfiBus or ModBus TCP can be used as REMOTE communication protocols (see details in Chapter 2.5.2 in technical description). Additional operation instructions for various bus types are to be found in their respective manual. VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 30: Commissioning Configuration

    7.1.1. Configuration during commissioning The settings of the generator protection relay VAMP 210 can be defined and checked during commissioning in accordance with the instructions given in chapter 5 of this manual, for example, in the following order: 1.

  • Page 31: Configuration Example

    VAMP Ltd Generator protection relay VAMP 210 Operation and configuration Figure 7.1.1-1 Principle for scaling the measured values of the VAMP 210 relay. 7. Activation of desired protection functions, Prot menu. See chapter 5.5 on page 25. 8. Setting values of the protection function parameters (e.g. I>...
  • Page 32 I (T/SET T>) (k k (T>) 1,06 setting for stage T>) Generator heating time constant tau (τ) 40 min (T/set tau) Generator thermal alarm level T> (Θ) 90 % (T/set ALARM>) Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...
  • Page 33 SET U< U1< t< NoCmp I<Blk 10.00 s 10.00 s Reverse power stage P< (32): SET P< P< t< 2.00 s Unbalanced load stage I >: SET I2> K1> Type 20.00 s VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...
  • Page 34 MCB of the potential transformers blocks the U< and f< functions. 4 Configuration of output relays The required groupings of the output relays and output signals are configured in the DO menu, see chapter 5.4 on page 25. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...
  • Page 35 4. Connections .................43 4.1. Digital inputs..............43 4.2. Auxiliary voltage............... 44 4.3. Output relays ..............44 4.4. Serial communication connection ....... 44 4.5. Arc Protection..............44 4.6. Block diagram ..............45 VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...
  • Page 36 5.3.7. Arc fault protection stages (option) ....55 5.4. Disturbance Recorder (DR) ..........55 6. Construction .................56 6.1. Dimensional drawing............56 6.2. Panel mounting ..............57 6.3. Semi-flush mounting............57 7. Order information..............58 8. Reference information ............59 Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 37: Introduction

    The modern technology in association with an extensive self- supervision system and a reliable construction ensures an extremely high availability for the VAMP 210 protection relay. 1.2. Main features Fully digital signal handling with a powerful 16 bit micro •...
  • Page 38 40 to 265 V dc or Built-in disturbance recorder for evaluating primary and • secondary, as well as neutral currents of the protected object. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 39: Functions

    Technical description Functions The individual protection functions of the generator protection relay VAMP 210 can independently of each other be enabled or disabled according to the requirements of the intended application. See the configuration instructions, Chapter 5 and 7, in the first part of this manual.
  • Page 40 Setting Is Asettelu Is Delay Definite / inverse Vakio-/käänteis- Inverse time Multiplier Tapahtumien Enable events time characteristics aika tyyppi aika toiminto sallinta Figure 2.1-3 Block diagram of a single-phase protection function. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 41: Protection Relay Functions

    Figure 2.2.1-1 shows a functional block diagram of the I> stage of the overcurrent unit. Figure 2.2.1-1 Block diagram of the three-phase overcurrent stage I>. VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...
  • Page 42 12.5 x I although the curves are defined up to 20 x I 2. The fastest possible operating time is about 60 ms at inverse time characteristic according to curve types VI and Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...
  • Page 43 VAMP Ltd Generator protection relay VAMP 210 Technical description Figure 2.2.1-2 Block diagram of the three-phase overcurrent stage I>>. VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...
  • Page 44 Figure 2.2.1-3 Normal Inverse (IEC 60255-3) characteristic. ⋅ ⎛ ⎞ − ⎜ ⎟ > ⎝ ⎠ t[s] = Trip time = Time multiplier = Measured current I> = I set current Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...
  • Page 45 VAMP Ltd Generator protection relay VAMP 210 Technical description Figure 2.2.1-4 Very Inverse (IEC 60255-3) characteristic. ⋅ ⎛ ⎞ − ⎜ ⎟ > ⎝ ⎠ (See explanation for formula on page 10.) VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...
  • Page 46 VAMP 210 Generator protection relay VAMP Ltd Technical description Figure 2.2.1-5 Extremely Inverse (IEC 60255-3) characteristic. ⋅ ⎛ ⎞ − ⎜ ⎟ > ⎝ ⎠ (See explanation for formula on page 10.) Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...
  • Page 47 Generator protection relay VAMP 210 Technical description Figure 2.2.1-6 Long Time Inverse (IEC 60255-3) characteristic. ⋅ ⎛ ⎞ − ⎜ ⎟ > ⎝ ⎠ (See explanation for formula on page 10.) VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 48: Voltage Restrained And Voltage Controlled Overcurrent Function (51V)

    2.2.2-2 the function is said to be voltage controlled. Note: The overcurrent function can be used as a normal high- set overcurrent stage I>>>, if I and I are set to 100%. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...
  • Page 49 Final value of voltage control = X2% x U1 > Current start value = Y1% x Iv> proportional to the voltage > Current start value = Y2% x Iv> proportional to the voltage VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 50: Unbalance Protection (46)

    The operating time of the unbalanced load unit depends on the magnitude of the negative phase sequence current, i.e. the greater the unbalance the shorter the operating time. Figure 2.2.3-1 shows the characteristic curve of the unbalanced load unit. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...
  • Page 51 Operating time [s] SCntr Cumulative start counter Recorded values TCntr Cumulative start counter Maximum fault current EDly Elapsed time as compared to the set operating time, 100% = tripping VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 52: Directional Earth-Fault Protection (67N)

    Enable events Io > s Icos / Isin I > s Figure 2.2.4-1 Block diagram of the directional earth-fault stage I ϕ>. Figure 2.2.4-2 Operation characteristic of the directional I cosϕ. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 53: Earth Fault Protection (50N/51N)

    VAMP 210 has four unidirectional earth fault stages and two separate energizing inputs for earth fault current i.e. I . The two first stages are using input I...
  • Page 54 Using an external injection device like VEO-MSV these stages can be used for rotor earth fault detection. Figure 2.2.5-1 Block diagram of the earth fault stage I >. Figure 2.2.5-2 Block diagram of the earth fault stage I >>. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 55: Residual Voltage Protection (59N)

    The neutral voltage function comprises two overvoltage stages, both with separately adjustable definite time operation delays. VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 56: Overvoltage Protection (59)

    Setting U>, U>> Setting value U > values Setting value as compared to U>, U>> _ %Ugn generator rated voltage Ugn t>, t>> Operating time Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 57: Undervoltage Protection (27/60)

    This setting is common for both stages. alijsuoja2 > & Start & Register event Block Trip Register & event Setting Delay Enable events U<s Figure 2.2.8-1 Undervoltage protection VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 58: Overload Protection (49)

    The thermal overload stage is provided with a separately adjustable alarm function, the setting range of which is 60...100% of the thermal trip level. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 59: Underexcitation Protection (40)

    The measurement of the degree of excitation is based on a complex three-phase power vector, which is calculated from the fundamental components of the phase currents and phase-to- phase voltages. VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...
  • Page 60 Q1 and Q2.The shaded area constitutes the area of operation. In the above example the operation solely depends on the reactive power, because the operating line is vertical (Q1 - Q2 = 0%). Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 61: Reverse Power Protection (32R)

    The reverse power protection is provided with two adjustable reverse power stages with separately adjustable limit values and operating times. VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 62: Overfrequency Protection (81H)

    The resolution of the frequency measurement is 0.01 Hz and the overfrequency protection has two adjustable frequency stages. Figure 2.2.12-1 Block diagram of the overfrequency protection. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 63: Underfrequency Protection (81L)

    Figure 2.2.13-1 Block diagram of the underfrequency protection. The operation of the underfrequency stages can be blocked by other stages or digital inputs via block matrix. The two stages have also a common undervoltage block limit. VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 64: Circuit-Breaker Failure Protection (50Bf)

    Output relay to be supervised values t> Operating time Recorded SCntr Cumulative start counter, only values selected ArcCn arc activations TCntr Cumulative trip counter EDly Elapsed time as compared to the set operating time, 100%=tripping Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 65: Arc Fault Protection (Option) Arci> (51 L>), Arci (51N L>), Arci > (51N L>)

    (BO) in the output matrix, DO menu. The binary output can be used to forward light information to another relay, e.g. VAMP 140. The binary output can be connected to a maximum of three binary inputs of another relay.

  • Page 66: Measurement Functions Of The Relay

    0 - 175 V ac Residual voltage U Measuring range 0 - 175 V ac Frequency f Measuring range 16 - 75 Hz Reverse power factor P.F. Measuring range 0...+1 inductive -1...0 capacitive Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 67: Output Relay And Blocking Functions

    0... ±2 x S 2.4. Output relay and blocking functions In the generator protection relay VAMP 210 all start and trip signals of the protection stages can be freely routed to the output relays and operation indicators according to the requirements of the application.

  • Page 68: Output Relay Matrix

    IEC-103 connection can be made using a special internal or external bus connection module. The bus type selection and the parameterization of the bus are carried out as the relay is configured. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 69: Disturbance Recorder

    The recordings can be viewed by VAMPSET program. The recording is in COMTRADE format so also other programs can be used to view the recordings. For more detailed information, see separate Disturbance Recorder manual VMDR.EN0xx. VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 70: Self-Supervision

    IF alarm is automatically given, because the IF output relay is normally always energized when the auxiliary supply is on and within the permitted range. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 71: Applications

    A/D conversion the VAMP 210 generator protection relay fulfils also these requirements. The three generator protection applications on the following pages illustrate how the flexibility of the VAMP 210 generator protection relay can be utilized. VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 72: Directly Connected Generator

    Figure 3.1-1 Generator connected directly to the distribution busbar. Earthed generator neutral. The generator protection relay VPG 210 is suitable for use in directly earthed and high/low resistance earthed systems. The differential and directional earth-fault protection provides a sensitive and selective protection solution in high resistance earthed systems.

  • Page 73: Directly Connected Generator With Unearthed Generator Neutral

    In this case the earth-fault protection principle is straight- forward. It is simply based on the measurement of the earth- fault current (I ) between the generator and the distribution busbars. VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 74: Generator-Transformer Unit

    Digital inputs Figure 3.3-1 Generator-transformer unit Besides the typical generator protection functions the VPG 210 relay includes the transformer earth-fault protection. Whatever phase difference and voltage ratio of the transformer can be compensated in the relay in case VTs and CTs are on different sides of the unit transformer.

  • Page 75: Trip Circuit Supervision

    The trip relay should be configured as non-latched. • Otherwise a superfluous trip circuit fault alarm will follow after the trip contact operates and remains closed because of latching. VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...
  • Page 76 CB position is doubled-lined. The value for R1 in this application is 3k3 and 2W. These can be calculated from the resistance and voltage operating range of the coil of K1 and the tolerance of the wetting voltage. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 77: Connections

    The digital uses the internal 48 V dc auxiliary voltage of the relay (terminal X3: 1). Potential-free contacts must be available in the protected object for transfer of status information to the relay. VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 78: Auxiliary Voltage

    This is a 48 Vdc signal. Connections: X6: 1 Digital input (BI) X6: 2 Digital output (BO) X6: 3 X6: 4-5 Sensor 1 X6: 6-7 Sensor 2 Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 79: Block Diagram

    VAMP 210 Technical description The GND must be connected together between the GND of the connected devices. 4.6. Block diagram Figure 4.6-1 Block diagram of the generator protection relay VAMP 210. VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 80: Connection Diagram

    VAMP 210 Generator protection relay VAMP Ltd Technical description 4.7. Connection diagram Figure 4.7-1. VAMP 210 connection diagram Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 81: Technical Data

    48 V dc Current drain when active (max.) Approx. 20 mA Current drain, average value < 1 mA Terminal block: Max. wire dimension: - Phoenix MVSTBW or equivalent 2.5 mm (13-14 AWG) VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 82: Trip Contacts (T1 And T2)

    RS 232 (option) Plastic fibre connection (option) Data transfer rate 1 200 - 38 400 kb/s Protocols ModBus‚, RTU master ModBus‚, RTU slave SpaBus, slave IEC-60870-5-103 Profibus DP (option) TCP/IP (option) Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 83: Tests And Environmental Conditions

    Environmental conditions Operating temperature 0 to +55°C Transport and storage temperature -40 to +70°C Relative humidity < 75% (1 year, average value) < 90% (30 days per year, no condensation permitted) VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 84: Casing

    - Operate time ±1% or ±25 ms *) This is the instantaneous time i.e. the minimum total operational time including the fault detection time and operation time of the trip contacts. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 85: Earth-Fault Protection Stages

    Earth fault stage I >> (50N/51N) Setting range 0.01 - 2.00 pu Definite time function: - Operating time 0.08 – 300.00 s (step 0.02 s)* Start time <60 ms Reset time <60 ms VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 86: Voltage Protection Stages

    Setting range 50 – 150% x Ugn Definite time function: - Operating time 0.08 – 300.00 s (step 0.02 s)* Start time <60 ms Reset time <60 ms Reset ratio 0.97 Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 87: Power Protection Stages

    0 – -100% x S Definite time function: - Operating time 0.08 – 300.00 s (step 0.02 s)* Start time <60 ms Reset time <60 ms Reset ratio 1.03 (x S VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 88: Frequency Protection Stages

    Circuit breaker failure protection stage Circuit breaker failure protection CBFP (50BF) Relay to be supervised T1 or T2 Definite time function: - Operating time 0.1 – 10.0 s (step 0.1 s)* Inaccuracy: Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 89: Arc Fault Protection Stages (Option)

    1 min Recording time (one record) 0.1 s – 12 000 min (must be shorter than MAX time) Pre trigger rate 0 – 100% Number of selected channels 0 – 12 VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 90: Construction

    VAMP 210 Generator protection relay VAMP Ltd Technical description Construction 6.1. Dimensional drawing 28.0 181.0 27.0 208.0 190.0 >20.0 193.0 PANEL CUT-OUT 1.0-10.0 P200_ulkomitat_kannella Figure 6.1-1 Dimensional drawing and panel cutout dimensions. Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 91: Panel Mounting

    6.3. Semi-flush mounting 21.0 28.0 181.0 27.0 P200_semi-flush Figure 6.3-1 Semi-flush mounting of protection relay Depth with raising frames Type designation VYX076 40 mm 169.0 mm VYX077 60 mm 149.0 mm VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...

  • Page 92: Order Information

    TTL/RS232 Converter Cable ( for Modem MD42, ILPH, ..) Cable length 4m VA 1 DA-6 Arc Sensor Cable length 6m VYX076 Raising Frame for 200-serie Height 40mm VYX077 Raising Frame for 200-serie Height 60mm Vamp 24h support phone: +358 (0)20 753 3264 VM210.EN004...

  • Page 93: Reference Information

    Email: vamp@vamp.fi URL: http://www.vamp.fi 24h support phone: Tel. +358 (0)20 753 3264 Email: vampsupport@vamp.fi During office hours 6.00 - 14.00 GMT, please use the following telephone number +358 (0)20 753 3200 VM210.EN004 Vamp 24h support phone: +358 (0)20 753 3264...
  • Page 94 We reserve the rights to changes without prior notice VAMP Ltd Street address: Yrittäjänkatu 15 Phone: +358 20 753 3200 Post address: Fax: +358 20 753 3205 P.O 810, FIN 65101 Vaasa, Internet: www.vamp.fi Finland Email: vamp@vamp.fi VM210.EN004...
