VAMP 135
Over-, under-, residual voltage and
frequency relay
Operation and configuration
instructions
Technical description

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VAMP 135 and is the answer not in the manual?

Questions and answers

Related Manuals for VAMP VAMP 135

Summary of Contents for VAMP VAMP 135

  • Page 1 VAMP 135 Over-, under-, residual voltage and frequency relay Operation and configuration instructions Technical description...
  • Page 2 VAMP 135 Over-, under-, residual voltage and VAMP Ltd frequency relay Operation and configuration VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 3: Table Of Contents

    6. PC software................26 6.1. PC user interface...............26 6.1.1. Using the VAMPSET program........26 6.2. Remote control connections ..........26 7. Commissioning configuration..........27 7.1. Factory settings..............27 7.1.1. Configuration during commissioning....27 7.1.2. Configuration examples .........28 VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 4: General

    Two underfrequency stages • Circuit breaker failure protection • The VAMP 135 relay can be connected to the system to be protected using three alternative modes, which are selected during commissioning. The following modes can be selected: Line, Line+U and Phase. For more detailed information, see Chapter 2.2 in this manual and Chapter 5.5 in the Technical...

  • Page 5: Operating Safety

    Any operational measurements must be voltages! voltages! voltages! carried out according to national and local handling directives and instructions. Carefully read through the relay operation instructions before any relay operational measures are carried out. VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 6: User Interface

    Operation and configuration User interface 2.1. General The VAMP 135 relay can be controlled in three ways: Locally with the push-buttons on the relay front panel • Locally with a PC connected to the serial port on the relay •...

  • Page 7: Display

    Operation and configuration 2.2.1. Display The VAMP 135 relay is provided with a clear 10 character alphanumerical LED display, which normally shows a scrolling text. Use the SERVICE/Setup/Bright menu to set the brightness of the display. The display is dimmed after a preset time.

  • Page 8: Indicators

    Error Error self-supervision fault, the self-supervision output relay operates in parallel with the indicator Alarm Alarm Alarm Alarm starting of protection stage Trip Trip Trip Trip tripping of protection stage VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 9: Local Panel Operations

    5. Push LEFT for at least 2 s to exit from the setting state of a parameter without changing the setting value or, 6. Push ENTER to confirm and store the parameter setting. VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...
  • Page 10 VAMP 135 Over-, under-, residual voltage and VAMP Ltd frequency relay Operation and configuration SUBMENUS MAIN MENU menurakenne_100sarja Figure 3.1-1. The principle of the menu structure and navigation in the menus. VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 11: Function Menu Table

    The structure of the menu is clear and straightforward. The main menu holds eighteen submenus, each with varying numbers of submenus and parameters. Figure 3.1.1-1. Main menu of the VAMP 135 relay. VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 12: Basic Menu Structure Of Protection Functions

    The level is automatically closed 10 minutes after a key being pushed last or a setting being performed via the local port. Closing can also be performed by giving the password 9999. VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 13: Opening Operating Levels

    UP key. 3. Push ENTER. 3.2.2. Changing of passwords The set password can only be changed locally using a PC connected to the local RS 232 port on the relay. VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 14: Operating Measures

    MEASURES U12: 10950V U23: 10960V U31: 10950V UL1: 6320V UL2: 6330V UL3: 6320V U0: 0V U0: 0.0 % f= 50.2Hz measuremode.eps Figure 4.1-1. Measures menu of the VAMP 135 relay. VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 15: Operation Indicators

    ENTER key. The latchings can also be reset via the communications bus or via a DI input configured for that purpose. VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 16: Reading Of Event Register

    Event list text. Scroll the event list by pushing the UP and DOWN keys. 7. Push the LEFT key twice to move from the event list to the main menu. VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 17: Forced Control (Force)

    13. Push the LEFT key to return from the Force: setting state to the Relays submenu. 14. Push the LEFT key to return to the main menu. VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 18: Setting Range Limits

    The scroll speed of the text in the display can be adjusted in the SERVICE/Setup/ScrolDelay: menu. 4.7. Setting date and time Date, time and style are set in the SERVICE/Setup/Date, Time and Style menus. VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 19: Configuration And Parameter Setting

    Configure the analog output in the mA OUTPUT position of • the main menu, see chapter 5.9. Set the Date and time in the SERVICE position of the main • menu, see chapter 5.11. VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 20: Principle Of Parameter Setting

    6. Push the LEFT key twice to return to the main menu. change setting 10100 10100 10000 SCALING UpPrim:10000V 10900 change setting Usec :100V change setting Line Line+Uo Umode Phase Un: 10000V scalingmode Figure 5.1-1. Changing parameters. VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 21: Enabling And Disabling Protection Functions (Enable)

    Over- and underfrequency stages (f>, f>>, f< and f<<) • Ena CBFP Circuit Breaker Failure Protection stage (CBFP) • RESET Reset the software of the VAMP 135 relay and reset • latches (Reset and Latch) NOTE! Disabling a protection function will remove the item from the menu.

  • Page 22: Configuring Digital Outputs Dout

    Via the submenus of the COM menu the following functions can be read and set: Active Communication protocol of REMOTE port (Protocol) • Message counter (Msg#) • Communication error counter (ERRORS) • Communication time-out counter (Tout) • VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...
  • Page 23 IP address of the SNTP Server (NTPSvr) • IP address of the Gateway (Gatew) • IP port number for Protocol (Port) • Local Port Transfer rate of local serial bus (bit/s) • VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 24: Analog Output Ma Output

    Scroll list of active links (Links) • Add a link to the recorder (AddLink) • Clear all links (ClrLink) • Manual trigger (MnlTrig) • Count of ready records (ReadyRec) • VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 25: Service Menu Service

    Setup of screen scroll delay (ScrlDelay) • Changing of password (ChgPwd) • Changing of date, time and date style(Date, Time, • Style) DeviceInfo Serial number of the device (SerN) • Software version (Prgver) • VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 26: Pc Software

    REMOTE communication protocols (see details in Chapter 2.6.2. in technical description). Additional operation instructions for various bus types are to be found in their respective manual. VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 27: Commissioning Configuration

    The scaling is done in the software block of the measured signals, Figure 7.1.1-1. Thus the scaling affects all the protection functions. Figure 7.1.1-1 Principle for scaling the measured values of the VAMP 135 relay. 5. Activation of the desired protection functions, ENABLE menu, see Chapter 5.2.

  • Page 28: Configuration Examples

    Selection of the protection mode Line+Uo (SCALING/U mode:) Transforming ratios of measurement transformers Voltage transformers (VT) Unom 2000 V (SCALING) Usec 100 V Residual voltage transformer (VT) Uosec 100 V (Uo SCALING) VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...
  • Page 29 0.20 s Overfrequency stage f>> f>> 52.0 Hz t>> 0.10 s Underfrequency stage f< f< 48.0 Hz t< 3.00 s Ublock Underfrequency stage f<< f<< 47.0 Hz t<< 0.10 s Ublock VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...
  • Page 30 DOUT menu, see Chapter 5.5. In the example, relay T1 is programmed to open the circuit- breaker with a trip signal (for example U>>) selected in the DOUT menu. VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...
  • Page 31 4.3. Output relays ..............27 4.4. Serial communication connections .......27 4.5. Voltage transducer............27 4.6. Block diagram ..............28 4.7. Connection diagram ............29 5. Technical data ..............30 5.1. Connections ..............30 5.1.1. Measuring circuitry ..........30 VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...
  • Page 32 5.3.2. Undervoltage protection ........33 5.3.3. Residual voltage protection ........33 5.3.4. Overfrequency protection........34 5.3.5. Underfrequency protection ........34 5.4. Disturbance Recorder (DR) ..........34 6. Dimensional drawing ............35 7. Order information..............36 8. Reference information ............37 VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 33: Introduction

    The versatile basic protection functions, the wide variety of additional functions and several available communication protocols render the Over-, under-, residual voltage and frequency relay VAMP 135 an ideal protection relay for power plants and substations as well as for industry, marine and off- shore applications.

  • Page 34: Main Features

    40 - 265 V dc/ac, optionally 24 V dc. Built-in disturbance recorder for evaluating primary and • secondary, as well as neutral currents of the protected object. VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 35: Functions

    Technical description Functions The individual protection functions of the VAMP 135 voltage and frequency relay with residual voltage protection can independently of each other be enabled or disabled according to the requirements of the application. See the configuration instructions, Chapter 5 and 7, in the Operation and configuration instructions.
  • Page 36 Figure 2.1-2 Block diagram of a software based protection relay. 1VUSLOHKO & Start > Event & register Blocking Trip Event & register Setting Delay Enable U>s event Figure 2.1-3 Block diagram of a single-phase protection function. VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 37: Relay Protection Configurations

    (100% = U = voltage transformers primary voltage VT which primary is defined by the user. The residual voltage stages U > and U >> are not in use. • VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 38: Protection Configuration Line+U

    If the fault appears again before the delay time has elapsed, the delay counter continues from the previous value. This means that the relay trips after a certain number of intermittent faults. VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...
  • Page 39 Figure 2.3.1-2 shows the functional block diagram of the overvoltage unit’s U>, U>> and U>>> stages. Figure 2.3.1-2. Block diagram of the three-phase overvoltage stages U>, U>> and U>>>. VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 40: Undervoltage Protection U<, U<<, U<<< (27)

    The three-phase undervoltage unit comprises three separately adjustable undervoltage stages (stage U<, U<< and U<<<). The undervoltage unit measures the fundamental frequency component of the line voltages. The protection stages operate with definite time characteristics. VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...
  • Page 41 Self-blocking value in relation to the rated voltage Un ReleaseDly Release delay [s] (only U<) Hysteresis Deadband (only U<) Recorded SCntr Start counter (Start) reading values TCntr Trip counter (Trip) reading VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 42: Residual Voltage Protection U >, U >> (59N)

    Setting value in relation to the values rated voltage U t>, t>> Operation time ReleaseDly Release delay (only U >) Recorded SCntr Start counter (Start) reading values TCntr Trip counter (Trip) reading VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 43: Overfrequency And Underfrequency Protection (81H/81L)

    Disabled S_Off Enabled; Enabled Start off event Disabled T_On Enabled; Enabled Trip on event Disabled T_Off Enabled; Enabled Trip off event Disabled Mode > or < > Frequency protection mode VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 44: Underfrequency Protection F<, F<< (81L)

    & Start Event & register Blocking Trip Event & register Enable Setting Delay events f< s Figure 2.3.5-1. Block diagram of the underfrequency stages f< and f<< VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 45: Circuit-Breaker Failure Protection Cbfp (50Bf)

    Parameter Parameter Value/unit Value/unit Parameter Parameter Value/unit Value/unit Setting CBRel Relay to be supervised values t> Operation time Recorded SCntr Start counter (Start) reading values TCntr Trip counter (Trip) reading VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 46: Measurement Functions Of The Relay

    • 2.5. Output relay and blocking functions In the VAMP 135 relay all start and trip signals of the protection stages can be freely routed to the output relays and operation indicators according to the requirements of the application. The functions can also be blocked and for this purpose both internal relay signals and external control signals can be used.

  • Page 47: Output Relay Matrix

    The bus type selection and the parameterization of the bus are carried out as the relay is configured. Optional accessories are available for RS485 connection (VSE 002), Ethernet connection over TCP/IP protocol (VEA 3CG) and VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 48: Disturbance Recorder

    8.x or newer. The recording is in COMTRADE format so also other programs can be used to view the recordings. For more detailed information, see separate Disturbance Recorder manual VMDR.EN0xx. VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 49: Self-Supervision

    If the relay is fully operational with the auxiliary power supply, the IF contact is on the open position. VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 50: Application Examples

    The digital input (DI) can be used for blocking of the residual voltage stages. The digital input is controlled by the auxiliary contact of the contactor’s secondary measuring circuit. VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 51: Feeder Over- And Undervoltage Protection (3Line Mode)

    The residual voltage protection is not in use. The analogue output (mA) can be used as a voltage transducer for one line voltage to a local analogue meter or a substation. VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 52: Feeder Over-, Under- And Residual Voltage Protection

    U , U , U U , U , U VAMP135Appl3 Figure 3.3-1. Three-phase overvoltage, undervoltage and residual voltage protection of a feeder. The voltage measurement mode is set to “ 2Line+U ” VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...
  • Page 53 The residual voltage is measured with an open-delta transformer. The auxiliary contact of the voltage transformer’s contactor is connected to the digital input for blocking of the undervoltage stages. VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 54: Trip Circuit Supervision

    The user may also configure a dedicated digital input event text, e.g. "TRIP CIRCUIT FAILURE", to be displayed on the local display of the protective relay whenever there is a trip circuit failure. VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...
  • Page 55 CB position is marked with an extra parallel line. The resistor device VR10CB offers an active input state for the digital input although the open coil auxiliary contact is open. VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 56: Connections

    VAMP Ltd frequency relay Technical description Connections Figure 4-1. Connections on the rear panel of the VAMP 135 relay. The VAMP 135 relay is connected to the protected object through the following measuring and control connections: • Phase voltage U...

  • Page 57: Output Relays

    Technical description 4.3. Output relays The VAMP 135 relay is equipped with five configurable output relays and a separate output relay for the self-supervision system, Figure 4-1. Trip relays T1 and T2 (terminals X2: 19 - 20 and 16 - 17) •...

  • Page 58: Block Diagram

    VAMP 135 Over-, under-, residual voltage and VAMP Ltd frequency relay Technical description 4.6. Block diagram Figure 4.6-1. Block diagram of the overvoltage, undervoltage and frequency relay VAMP 135. VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 59: Connection Diagram

    VAMP Ltd Over-, under-, residual voltage and VAMP 135 frequency relay Technical description 4.7. Connection diagram Figure 4.7-1. VAMP 135 connection diagram. Relay contact positions when no power supply connected. VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 60: Technical Data

    2 making contacts Rated voltage 250 V ac Continuous carry Max. making current 15 A Breaking capacity, AC 2 000 W/VA Breaking capacity, DC (L/R=40ms) 50 W Contact material AgNi 90/10 VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 61: Alarm Contacts (A1

    5.1.8. mA output Number of outputs Output signal 0/1 - 5 mA or 0/4 - 20 mA or any between 0...20mA Load resistance RL < 600 W Accuracy Class 1 VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 62: Tests And Environmental Conditions

    < 90% (30 days per year, no condensation permitted) 5.2.5. Casing Degree of protection (IEC 60529) IP20 Dimensions (W x H x D) 99 x 155 x 225 mm Weight 1.6 kg VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 63: Protection Stages

    >) Starting time <300 ms Resetting time <300 ms Resetting ratio 0.97 Accuracy: - starting ±2% of set value or ±3% of U - operate time ±1% or ±30 ms VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 64: Overfrequency Protection

    1 min Recording time (one record) 0.1 s – 12 000 min (must be shorter than MAX time) Pre trigger rate 0 – 100% Number of selected channels 0 – 12 VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 65: Dimensional Drawing

    VAMP Ltd Over-, under-, residual voltage and VAMP 135 frequency relay Technical description Dimensional drawing VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...

  • Page 66: Order Information

    TTL/RS232 Converter Cable ( for Modem MD42, ILPH, ..) Cable length 4m VX008-4 Raising Frame for 100-serie Height 40mm VYX078 Raising Frame for 100-serie Height 60mm VYX079 3 Phase Nominal Voltage Matching Transformer 690V->230V , 400V->110V VM690/230 VAMP 24h support phone : +358 (0)20 753 3264 VM135.EN008...

  • Page 67: Reference Information

    FIN-65101 Vaasa, Finland Street address: Yrittäjänkatu 15 Tel: +358 (0)20 753 3200 Fax: +358 (0)20 753 3205 Email: vamp@vamp.fi URL: http://www.vamp.fi 24h support phone: Tel . +358 (0)20 753 3264 Email: vampsupport@vamp.fi VM135.EN008 VAMP 24h support phone : +358 (0)20 753 3264...
  • Page 68 We reserve the rights to changes without prior notice VAMP Ltd Street address: Yrittäjänkatu 15 Phone: +358 20 753 3200 Post address: Fax: +358 20 753 3205 P.O Box 810, FIN 65101 Vaasa, Internet: www.vamp.fi Finland Email: vamp@vamp.fi VM135.EN008...
