Commend C-G3-TEL Product Manual page 18

Auto-dialler mode
System messages No. "0" to No. "13"
The system messages No. "0" to No. "13" are required to generate call request messages (e.g. "Calls:
one, emergency calls: three") or for call number announcement of individual messages
dividual messages" on page
NOTE: System messages No. "0" to No. "13"
These messages may not be changed in content, but recording of these speech messages with the same
meaning in other languages is allowed.
System messages No. "14" and No. "15"
 The system message No. "14" is used as calm-down message.
 The system message No. "15" is used as location message.
NOTE: System messages No. "14" and No. "15"
These messages can be changed, resp. No. "14" shall be changed in content and recorded individually
(e.g. "Parking East").
Individual messages No. "20" to No. "26"
The messages No. "20" to No. "26" can be used for additional information
on page 19).
NOTES: System messages No. "20" to No. "26"

More "individual messages" than just No. "20" to No. "26" can be loaded into the speech storage of
the telephone interface. For maximum speech storage capacity,
 For an overview of switching on several speech messages in auto-dialler mode, see
speech messages" on page 10
Calm-down message for call requests
For switching on calm-down message at a
figuration in CCT 800 is required:
 Subscriber > Feed-in > Radio conference
 Configure for the telephone interface in order to be able to play the calm-down message.
NOTES: Calm-down message
 Only the first calling station receives the calm-down message from the speech storage of the
telephone interface. It is possible, however, to feed a separate calm-down message through a
subscriber for which "feed-in of radio conference" is configured, independently from the speech
storage of the telephone interface. In this case, it is not required to configure "feed-in of radio
conference" for the telephone interface. Thus, each calling station receives the calm-down message.
For further information on configuration, see manual "Intercom Server Configuration".

If the telephone interface is already in a conversation, no calm-down message (pre-recorded audio
from the speech storage of the telephone interface) will be put out.
 For call requests to a control desk, it is possible to use the calm-down message of the speech storage
of the telephone interface for a calling station.
ATTENTION: Control desk and switch-over
 For the respective call request, the telephone interface has to be configured as additional control
desk. For the telephone interface, "feed-in of radio conference" has to be configured as described
above.
 If this feature is used for internal call requests, all these calls requests will also be transferred through
the telephone interface. To avoid this, it is possible to configure a switch-over of the dialling sequence
(see also "Activate dialling sequence" on page
18
19).
and "Examples for the call procedure" on page
"Call request/input
15).
(see "Individual messages"
see "Technical data" on page
12.
message", the following additional con-
G8-TEL / G3-TEL
(see also "In-
5.
"Switch on
2.0/0817
