- Page 1 Electric Central Heating Flow Boiler EKCO.R2 Assembly and operating manual...
- Page 2 This appliance may be used by children at the min. age of 8 years and by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge about the product, provided that they have been given supervision or instruction concerning safe usage of the appliance and that they are aware of potential dangers that might result from usage of the appliance.
-
Page 3: Safety Instructions
Safety instructions Read and strictly follow the installation and operating instructions to ensure a long life and reliable boiler operation. An efficient electrical installation which has been completed in accordance with the binding norms of electric installation. A wet central heating system equipped with appropriate expansion vessel made according to the binding norms of hydraulic installation –... -
Page 4: Installation
Installation Hang the boiler up in a vertical position on fixing screws with the inlet and outlet pipes to the bottom, maintaining clearances from the walls and the ceiling according to the figure. Connect the boiler to the central heating system equipped with cut-off valves. - Page 5 Connection to the three-phase electrical system . PNL - points of neutral and protective conductor connection PF - points of phase conductors connection [1] - temperature limiter Connection to the single phase electrical system (for boilers of 4kW,6kW) PNL - connection points of neutral, protective and phase conductors [1] - temperature limiter [2] - additional conductors (for single phase...
-
Page 6: Connection Of External Appliances
Connection of external appliances Room thermostat (NA entry) – when the voltage free contact gets opened the boiler will stop heating. NA Q Twej Twyj The entry is responsible for boiler control depending on the room temperature. Room Termostat thermostat pokojowy Start up Disconnect the flat multi-conductor cable from ZM... -
Page 7: Control Panel
Control panel 4 0 5 0 6 0 7 0 8 0 4 5 5 5 6 5 7 5 8 5 [1] - boiler „on” button [5] - economy mode „on” indicator [2] - economy mode button [6] - temperature setting indicator [3] - boiler „on”... - Page 8 Operating mode of the pump EKCO.R2 has two operating mode of the pump (constant and automatic). To set the automatic mode (pump is „off” when the room thermostat switch off the boiler heating operation) press [1] to switch off the boiler then press and hold [2]. A temperature setting display [6] will start to flicker after a few seconds which indicate the switching pump mode for automatic mode.
-
Page 9: Technical Data
Technical data Max.pressure Min.pressure 0,05 Outflowing water temp. °C 35 ÷ 85 Max. water temp. °C Overall dimensions (height x width x depth) 660 x 380 x 175 Weight Water connection G 3/4" Safety class IP 22... - Page 10 Rated power Rated voltage 220V~ 380V 3N~ Rated current 18,3 27,4 36,4 3x6,1 3x9,1 3x12,2 Fuse rated current Min. connecting wires section 3x2,5 3x4 5x1,5 Max. connecting wires section 3x16 5x16 The maximum allowed network impedance Ω 0,27 0,17 0,15 0,27 Rated power Rated voltage...
- Page 11 Used product can’t be treated as general communal waste. Disassembled appliance has to be delivered to the collection point of electrical and electronic equipment for recycling. Appropriate utilisation of used product prevents potential negative environmental influences that may occur as a result of inappropriate handling of waste. In order to get more detailed information about recycling this product you should contact the local government unit, waste management service or the shop where this product has been purchased.
- Page 12 KOSPEL S.A. 75-136 Koszalin, ul. Olchowa 1 tel. +48 94 31 70 565 serwis@kospel.pl www.kospel.pl...
