HBM DMCplus Technical Specifications

Digital amplifier system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Technical Specifications
Digital Amplifier System
DMC
plus
Elektrical
measurement
of mechanical
quantities

Advertisement

Table of Contents
loading

Related Manuals for HBM DMCplus

Summary of Contents for HBM DMCplus

  • Page 1 Elektrical measurement of mechanical quantities Technical Specifications Digital Amplifier System plus...

  • Page 3: Table Of Contents

    Contents Survey of the chapters ........... . . Notes on safety .
  • Page 4 2.2.3 DV30 600Hz-CF amplifier ......B-41 2.2.4 DV35 600Hz-CF amplifier ......B-42 2.3 Function cards .
  • Page 5 IEEE 488-78 parallel interface ........3.1 IEEE 488-78 .

  • Page 6: Survey Of The Chapters

    Survey of the chapters Chapter A Introduction General notes on how to use this manual. A documentation survey informs you on the manuals available for the system device. plus Chapter B complete system plus Provides information on the system design and gives technical background information.
  • Page 7 Chapter E Communication with the DMC plus Informs on how to connect the DMC to your computer. plus Chapter F Technical data Provides the technical data for the complete system. Chapter G Glossary In the form of a ”lexicon” the glossary explains the most important technical terms used in this manual.

  • Page 8: Notes On Safety

    Notes on safety Prior to power-up make sure that the mains voltage and NP03 current type specified on the type plate match the mains voltage and current type at the site of installation and that the electric circuit used has been fused sufficiently. Prior to power-up: D Check the position of the voltage selection-switch on the DMC...
  • Page 9 To ensure sufficient EMI-proofness, use the Greenline screening only (see HBM special brochure on the Green- line screening concept, EMI- proof measurement cables, G36.35.0). Appropriate use The DMC plus- system with the connected transducers may be used for measurement and directly related control and regulation tasks, only.
  • Page 10 Residual dangers The DMC plus- scope of performance and supply covers part of the measuring-technology, only. The plant designer/constructor/operator must in addition design, realise and take responsibility for the measuring-system’s safety such that potential residual dangers are minimized. The respective regulations must in any case be observed. Residual dangers regarding the measuring system must be specified explicitly.
  • Page 11 Reconstruction and modifications HBM’s express consent is required for modifications regarding the DMC plus- system construction and safety. HBM does not take responsibility for damage resulting from unauthorized modifications. In particular, repair and soldering works on the boards (replacement of components except for EPROMS) are pro- hibited.
  • Page 12 Qualified personnel Qualified personnel means: personnel familiar with the installation, mounting, start-up and operation of the prod- uct, and trained according to their job. The device may be used by qualified personnel, only; the technical data and the special safety regulations must in any case be observed.

  • Page 13: A Introduction

    Introduction Introduction Survey of documentation ..........1 .1 How to use this manual .
  • Page 14 Introduction DMC plus Technical specifications...

  • Page 15: Survey Of Documentation

    Introduction Survey of documentation Survey of documentation The product documentation supplied with the DMC Digital plus amplifier system includes two references: The ”Technical specifications” contain background knowledge on the whole amplifier system The manual ”Operation with terminal or computer” explains programming and measuring with the via terminal and/or computer plus Two additional computer programs for...

  • Page 16: How To Use This Manual

    Introduction How to use this manual 1.1 How to use this manual This manual is to introduce you to the DMC with all its plus components. It is intended for both, beginners and the more experienced who already have worked with computers. You have several guidelines at your disposal: D The table of contents on the first pages of the manual gives a first impression.

  • Page 17: Bdmc Plus Complete System

    DMC plus -complete system -complete system plus System design ............1.1 Housing types .
  • Page 18 DMC plus -complete system DMC plus Technical specifications...

  • Page 19: System Design

    DMC plus complete system System design System design DMC plus characteristics: The DMC plus is a digital amplifier system with up to 28 channels (2 channels per amplifier plug-in unit) that is 100% computer-controlled. The system design is characterised by its bus structure similar to that of a microprocessor system.
  • Page 20 DMC plus complete system System design Measure Σ Zero Transducer Cal. Analogue-to-digital Filtering Averaging Zero balance Sensitivity Taring conversion (9600meas./s . . . balance GA02 75meas./s*) EEPROM ....n DV .
  • Page 21 DMC plus complete system System design Analogue-to-digital conversion HBM has developed a special ADC method based on a dual-channel 16-bit-converter. Contrary to conventional methods, the HBM converter does not restrict the resolution and converts without loss of information over the whole bandwidth even with highly dynamic processes.
  • Page 22 DMC plus complete system System design Data transmission rates The amplifiers supply measurements at data rates between 75 and 9600measurements/s. With data transmission rates smaller than 9600measurements/s, measurements are averaged in the gate-array. With even smaller data transmission rates (between 1 and 60measurements/s, the CPU determines an additional average value.

  • Page 23: Ieee 488-78 Parallel Interface

    DMC plus complete system System design Transducer and RS-232 Signal sources RS-422/485 Thermoc. CP03 DV01 µ Measurement DV10 68 000 memory DV30 Resistors DV35 Pt100 Measurement Additional memory memory DV55 Inductive 8 bits input 8 bits output Torque Frequenz/ DV60 SY01 Speed Synchronisation DMC plus...

  • Page 24: Housing Types

    DMC plus complete System design Housing types 1.1 Housing types The DMC plus Digital amplifier system is available in three versions: D The narrowdesktop housing can be equipped with max. 12 amplifier channels (corresponds to 6 slots), D The wider version can be equipped with max. 28 channels (corresponds to 14 slots).
  • Page 25 DMC plus complete system System design Housing types Due to the compact construction in SMD technique, two amplifier channels have been realised per slot in the DMC plus thus enabling each device to be equipped with a large quantity of channels. Designation Maximum 19”...

  • Page 26: Device Front

    DMC plus complete System design Device front B-10 1.1.1 Device front AC DC Fig. B 3: Front view of the 12-channel desktop housing DMC plus Technical specifications...
  • Page 27 DMC plus complete system System design Device front B-11 After power-up, the device performs a lamp test, i.e. all LEDs will light up for a short time (approx.100ms). In operating mode, the LEDs signal the following: WAITING FOR COMMAND The DMC plus waits for an instruction. BUSY The device is processing an instruction.
  • Page 28 DMC plus complete System design Device front B-12 SYSTEM REQUEST System error. The LED is on until the error has been queried with the SST? instruction. COMMAND ERROR A wrong instruction or wrong parameters have been entered. The LED is on until the error has been queried with the *ESR? or EST? instruction.

  • Page 29: Device Rear

    DMC plus complete system System design Device rear B-13 1.1.2 Device rear DMC91T1 * Other power packs also Parallel-I/O possible, see page B-21 DMC91T1B NP 03* SY01 CP03 Channel numbers DMC91E1 Channel numbers Slot numbers Slot 6: for IE01, DV... or other func- RS-232-Computer connection tion board as desired DMC91T2...
  • Page 30 DMC plus complete System design Device rear B-14 NP04 POWER DC DV 55 AU 01 DV60 PI 01 IE 01 SY 01 CP 03 12V = BUFFER 11...30V CHANNEL A INPUT MD FUNCTION CHANNEL A PARALLEL RESET 24V = BATT. FUNCTION Bu12 Bu11...

  • Page 31: Amplifiers For The Dmc Plus

    DMC plus complete system System design Amplifiers for the DMCplus B-15 1.2 Amplifiers for the DMC plus The amplifier plug-in units are autonomous components that acquire measurement signals from the transducers, digitise them and make them available to be queried by the CP03.

  • Page 32: Interfaces

    DMC plus complete System design Operation/interfaces B-16 1.3 Interfaces The DMC plus is controlled by a computer or terminal. There are no controls for manual operation. For operation via computer or terminal, there are the following standard interfaces: RS-232-C (V.24) and RS-422/485 With the IE01 interface board an IEEE 488-78-interface...

  • Page 33: Instruction Set

    DMC plus complete system System design Instruction set B-17 1.4 Instruction set The instruction set included in the device’s firmware permits communication with the computer. The instruction set contains codes that are easy to learn; via the interface these codes together with the setup parameters are transmitted from the computer to the DMC plus .

  • Page 34: Synchronisation

    Synchronisation DMC plus complete System B-18 1.5 Synchronisation Synchronising the amplifiers in one device: D Set DIP switches 2 and 3 on the SY01 Control unit to ’Single device’ position. Single device (default) 2nd device Synchronising 2 and more devices: 1st device and further With more than one DMC plus , the individual devices must be...

  • Page 35: Components Of The System Device

    DMC plus complete system Components of the system device B-19 Components of the system device DMC plus Technical specifications...
  • Page 36 DMC plus complete Components of the system device B-20 The following components are included in the DMC plus basic device: D Desktop housing or plug-in rack module D Power supply / power pack D CP03 Central processing unit D SY01 Control unit Depending on the measurement task, the DMC plus can be completed with: D DV...

  • Page 37: Basic Components

    DMC plus complete system Components of the system device Power supply B-21 2.1 Basic components 2.1.1 Power supply/power pack The NT010 Power pack has been designed for 230V (115V) NT010 connection. The unit is automatically adapted to a 115V/230V mains. Tolerances: 230V –25%,+15% 115V –25%,+15%...
  • Page 38 (voltage-selection switch). In these cases, please remember to exchange the fuses: 115V mains voltage: 2.0A/T 230V mains voltage: 1.0A/T) POWER AC In general, the DMCplus is single-pole protected. 230V -10% To exchange the fine-wire fuse(s) after blowing or to 115V...
  • Page 39 DMC plus complete system Components of the system device Power supply B-23 The NP04 Power pack has been designed for mains Battery-monitoring function connection, and in addition for connection of a 12V or 24V Battery connection battery thus enabling the DMC plus to be operated independent of a mains unit.
  • Page 40 DMC plus will immediately be ready for operation. 1,0A/T 2,0A/T However, measurement functions have to be restarted. After a battery replacement due to discharged battery, the DMCplus behaves as after ’Mains on’. 230V -10% The upper 6.3A/T L fine-wire fuse is used for battery...

  • Page 41: Cp03 Central Processing Unit

    DMC plus complete system Components of the system device CP03 Central processing unit B-25 2.1.2 Central processing unit CP03 The CP03 Central processing unit manages the DMC plus amplifiers internally and controls communication with a CP 03 computer via serial and parallel interfaces externally. RESET The central processing unit has been realised using a microprocessor (68 000) with 12.5MHz clock.
  • Page 42 DMC plus complete Components of the system device CP03 Central processing unit B-26 D Serial interface connections The interfaces may only be operated alternatively. Assignment of socket Bu1: RS-232-C- (V.24) interface CP 03 (suits point-to-point connections of up to 20m) RESET Assignment RS-232-C...
  • Page 43 DMC plus complete system Components of the system device CP03 Central B-27 The default values (factory setup) of the RS-232-C interface correspond to the setup after a cold start. They are as follows: Word length: 8 bits Stop bits: Parity: Even Baud rate: 9600 baud...
  • Page 44 DMC plus complete Components of the system device CP03 Central processing unit B-28 Assignment of socket Bu2: RS-422/485 interface (suits point-to-point connections over longer distances of up to 1200m and bus operation) CP 03 Assignment RESET Ground RS-232-C TxD-P(B) transmitted data (+) V.24 RxD-P(B’) received data (+) Ground...
  • Page 45 DMC plus complete system Component of the system device CP03 Central B-29 D Light-emitting diodes The three light-emitting diodes below socket Bu2 indicate the device’s operating state. After power-up, the LEDs STOP (red) ERR (yellow) RUN (green) will light up in sequence. With a successful system startup, the green LED will be light continuously.
  • Page 46 D The red LED (STOP) does not go out after power-up, the red LED lights up during operation: The device is defective, a system error has occurred. Contact your HBM representative or send the device to the factory. D The yellow LED (ERR) lights up after startup or during operation: A program error has occurred.
  • Page 47 Components of the system device CP03 Central processing unit B-31 If the yellow LED still does not go out, contact your HBM representative or send the device to the factory. D After reset to W, the green and yellow LED (RUN and ERR) on the CP03 will both light up: Due to the supply-voltage loss a ’Mains failure’...

  • Page 48: Sy01 Control Unit

    DMC plus complete Components of the system device SY01 Control unit B-32 2.1.3 SY01 Control unit The SY01 Control unit clocks and synchronises the amplifiers. The SYN plug connector enables several devices to be SY 01 synchronised (see chapter B 1.5). DIP switch factory-setup Components on the SY01...
  • Page 49 DMC plus complete system Components of the system device SY01 Control unit B-33 D I / O socket Eight digital inputs and outputs (8bit input/8bit output), control SY 01 signals and status reports are available at this socket. The connections are not electrically separated. DIP switch factory setup Assignment of the I/O socket:...
  • Page 50 DMC plus complete Components of the system device SY01 Control unit B-34 max. +50V START Ground Fig. B 7: Start signal on the I/O socket Use the START signal at pin 14 of the I/O socket to start or terminate a measurement. max.
  • Page 51 DMC plus complete system Components of the system device SY01 Control unit B-35 Common 2.7k max.100mA max.50V 7.2k Ground Fig. B 9: Status signal on the I/O socket Common 2.7k Output 0...7 max. 100mA max.50V 7.2k Ground Fig. B 10: Output configuration on the I/O socket DMC plus Technical specifications...
  • Page 52 DMC plus complete Components of the system device SY01 Control unit B-36 D SYN plug connector With more complex measurement systems, the DMC plus must SY 01 be synchronized via this plug connector. DIP switch Assignment of the SYN plug connector: factory setup Assignment SYRES...

  • Page 53: Amplifiers

    DMC plus complete system Components Amplifiers B-37 2.2 Amplifiers The amplifier plug-in units are autonomous components that acquire measurement signals from the transducers, digitise them and make them available to be queried by the CP03 Central processing unit. They have been designed for different transducer types and are therefore differing with regard to their construction, e.g.: D for DC-voltage or carrier-frequency operation, D with or without transducer supply,...
  • Page 54 DMC plus complete Components of the system device SY01 Control unit B-38 D with different transmission characteristics. Each amplifier plug-in unit has been designed according to the dual-channel principle using two 15-pin input sockets. Above each of them, there is one LED (two-colour LED) indicating the operating mode.

  • Page 55: Dv01 Dc Amplifier

    DMC plus complete system Components Amplifiers DV01 B-39 2.2.1 DV01 DC amplifier D Transducer-connection sockets Thermocouples, cold junction reference, DC-voltage DV 01 orDC-current sources for channel A and B are connected to CHANNEL A these sockets. They both have the same assignment. GREEN OVER- ACTIVE...
  • Page 56 DMC plus complete Components Amplifiers DV30 B-40 2.2.2 DV10, DV30,DV55600Hz-CF amplifier D Transducer-connection sockets for Channel A and B Strain gauges in half and full bridge circuit, potentiometers and DC-voltage sources for channel A and B are connected to CHANNEL A these sockets.
  • Page 57 DMC plus complete system Components Amplifiers DV35 B-41 2.2.3 DV35 600Hz-CF amplifier D Transducer-connection sockets for Channel A and B Pt100 (RTD) resistance thermometers, resistors, single strain DV 35 gauges and DC-voltage sources for channel A and B are CHANNEL A connected to these sockets.
  • Page 58 DV60 B-42 2.2.4 DV60 MD-/n-amplifier D Transducer-connection sockets for Channel A and B DV 60 The following HBM devices can be connected to these CHANNEL A INPUT MD sockets: T30FN...T36FN torque transducers, the MBL40 non-contacting measurement transmitter and incremental and...
  • Page 59 DMC plus complete system Function boards PI01 Digital input/output board B-43 2.3 Function boards 2.3.1 PI01 Digital in/output board The digital input/output board enables digital and analogue signals to be recorded simultaneously . PI 01 PARALLEL Components on the PI01 D Memory-aid panel and I / O modules The upper field on the PI01 boards front panel functions as a sort of memory aid for the assignment of the four I/O module...
  • Page 60 DMC plus complete Function boards PI01 Digital input/output board B-44 Determination of the I/O-module functions Four I/O modules with 8bits each are plugged onto the PI01 input/output board; the modules have been marked with direction arrows. Depending on the plug-in direction, the boards function as input or output modules, thus enabling any configuration desired to be arranged.
  • Page 61 DMC plus complete system Function boards PI01 Digital input/output board B-45 D 50-pin plug and LED U EXTERN Use this plug for output or reading of digital data (max. 32 PI 01 bits). The supply voltage (U ) for the output or reading of EXTERN PARALLEL data must be supplied externally (+5 bis 30V).
  • Page 62 DMC plus complete Function boards PI01 Digital input/output board B-46 Assignment of the 50-pin plug: Assignment PI 01 PARALLEL Extern Strobe 2 Strobe 1 Strobe 0 EXTERN Comment: +U = External supply voltage (+5 to 30V) Extern Strobe Channel/Port B/1+2 The pin assignment of the 50-pin plug corresponds to the assignment of commercial SPS input/output modules.
  • Page 63 DMC plus complete system Function boards PI01 Digital input/output board B-47 Assignment of the 50-pin plug: PI 01 Channel A Channel B PARALLEL Port Port module module EXTERN DMC plus Technical specifications...
  • Page 64 DMC plus complete Function boards PI01 Digital input/output board B-48 The 32 data lines are programmable as inputs or outputs in groups of 8 bits (see figure). The electrical separation of the data lines from the internal electronics requires an external supply voltage of +5V ... +30V. The input signals are charged with approx.
  • Page 65 DMC plus complete system Function boards AU01 Analogue output board B-49 2.3.2 AU01 Analogue output board The AU01 Analogue output board enables digital measurement values resulting from the amplifier or numerical AU 01 values resulting from the computer to be converted into analogue signals.
  • Page 66 DMC plus complete Function boards IE01 Interface board B-50 2.3.3 IE01 Interface board This interface board extands the DMC plus by a parallel interface (IEEE-488). IE 01 The maximum data transmission rate is 400KB/s or 100,000 measurement values/s. Components on the IE01 D DIP switch Use the DIP switch to select from the following setups: = Controller...
  • Page 67 DMC plus complete system Function boards IE01 Interface board B-51 Address setting: IE 01 Addr. Addr. ON 0 1 OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF ON OFF OFF OFF OFF ON OFF OFF ON OFF OFF OFF OFF OFF ON OFF OFF ON...
  • Page 68 DMC plus complete Function boards IE01 Interface board B-52 Assignment IEEE 488-78 interface (suitable for BUS operation 2...20m) IE 01 ON 0 1 Assignment DIO1 DIO2 DIO3 DIO4 NRFD NDAC IEEE 488-78 Screen DIO5 DIO6 DIO7 DIO8 Ground 6 Ground 7 Ground 8 Ground 9 Ground 10...
  • Page 69 DMC plus complete system Function boards Digital counter board B-53 2.3.4 DZ65 Digital counter board D Transducer-connection sockets for Channel A and B Measurement transducers generating and transmitting digital DZ 65 signals can be connected to these sockets such as, incremen- CHANNEL A tal and pulse transmitters whose frequencies are to be deter- GREEN...
  • Page 70 DMC plus complete system Function boards Digital counter board B-54 The digital counter board enables pulses to be counted, period Schematic circuit diagram lengths or frequencies to be measured and acquired isochro- nously with the measurements resulting from the other chan- Channel A +2.5 nels.
  • Page 71 DMC plus complete system Function boards Digital counter board B-55 b) Preset counter Pulses are counted consecutively until the preset number (adjustable from 2...4,000,000) has been reached. The preset number cannot be output as measurement due to the fact that the counter is immediately set to zero when the preset number has been reached and counting is restarted.
  • Page 72 DMC plus complete system Function boards Digital counter board B-56 D Transducer-connection sockets, interface description 1) Input signals a) Functions IN1+ (Pin 8) / IN1- (Pin 15): Counter input 1 IN2+ (Pin 5) / IN2- (Pin 6): Counter input 2 For connecting the second phase of a 2-phase transducer, for recognition of the counter direction or to increase the resolu- tion,...
  • Page 73 DMC plus complete system Function boards Digital counter board B-57 b) Configuration Schematic circuit diagram The IN1...IN3 inputs are differential inputs with voltage levels 2.5V between –15V and +15V. The switching hysteresis can be ad- justed (through software via the computer) to suppress inter- ferences and to determine the switching threshold (triggering).
  • Page 74 DMC plus complete system Function boards Digital counter board B-58 Input signal related to ground Schematic circuit diagram TTL signals (0...5V) or CMOS signals (0...15V) can be connec- 2.5V ted directly to the IN+ inputs or to the IN– inputs, if the nega- tive edge is to be counted.
  • Page 75 DMC plus complete system Function boards Digital counter board B-59 2) Current supply for the transducer Internal supply voltages of +15V, –15V and +5V are available for each channel to supply the measurement transducers that are connected. The +15V and –15V voltages are connected via internal protective resistors of 100 ohms each, thus redu- cing the output resistance according to the load.
  • Page 76 DMC plus complete system Function boards Digital counter board B-60 3) Output signals OUT1 (Pin 9): Counter control-output 1 OUT2 (Pin 14): Counter control-output 2 For monitoring purposes, e.g., to adjust the hysteresis (trigger threshold) or for transducer adjustment, the outputs OUT1 and OUT2 permit connection to an oscilloscope.
  • Page 77 DMC plus complete system Function boards PC01 PCMCIA-hard disk B-61 2.3.5 PC01 PCMCIA-hard disk Description: – Type III PCMCIA slot – 170MB hard-disk drive PC01 The PC01 plug-in unit makes available a PCMCIA slot for a hard-disk drive. The PC01 with an integral 170MB hard disk Eject expands the RAM to >40,000,000 measurements (standard button...
  • Page 78 4 bytes. The maximum file size is limited by the maximum data depth of 1 million measurements per DMCplus channel. The maximum number of files is subject to the DOS conventions. The files can be read on a computer with appropriate PCMCIA slot.
  • Page 79 Channel connection Channel connection Connection cable ........... Types of connection for the DV.
  • Page 80 Channel connection DMC plus Technical specifications...
  • Page 81 Connection cables Channel connection Connection cables The measurement transducers are connected to the dual-channel amplifiers either directly by means of the transducer cable or with additional adapter cable. D The transducer cable has free ends: Connect a 15-pin plug connector (stock no. 2-9278.0321) use the Kab134 adapter cable and connect it to the transducer’s free ends.
  • Page 82 Connection cables Channel connection D An MS-plug has been connected to the transducer cable: Use the Kab133 adapter cable. Adapter cable 133 7-pin coupler socket 15-pin D-plug connector Transducer DMC plus Cable length: 0.3m Cable diameter: 7.5mm MS3101A 16S-1S Fig. C 2: Connection to transducer cable with 7-pin coupler socket DMC plus Technical specifications...
  • Page 83 (electromagnetic compatibility) that has been carried out by HBM. These diagrams show the screen connection that has been used with HBM devices up to now. The screen is connected to a plug point (here, PIN 1). This solution offers only relatively low EMC protection and should only be used in special cases.
  • Page 84 Measuring range 100mV GREEN OVER- ACTIVE FLOW Active transducers that Measuring transmitters, e.g. HBM type can beconnected PE200, P19AV, P19IV Support power supply 16V / 0 / –15V; I = 50mA Meas ring ranges Measuring ranges 20mA...
  • Page 85 Channel connection Types of connection for DV01 Thermocouple with electrical cold junction reference* DV 01 DV01 with Reference point CHANNEL A 15-pin socket Cu-lines Thermo- GREEN OVER- ACTIVE couple FLOW – – Operating- Thermo- voltage zero couple (ground) extension wires e(VMA) CHANNEL B Supply voltage...
  • Page 86 Types of connection for DV01 Channel connection Voltage source* DV01 with 15-pin socket DV 01 CHANNEL A GREEN OVER- ACTIVE Operating-voltage zero FLOW (ground) – – 100mV; 1V; Operating-voltage zero (ground) CHANNEL B Cable screen GREEN OVER- ACTIVE Current source* FLOW –...
  • Page 87 Channel connection Types of connection for DV01 Measuring converter, e.g. Digibar PE200 with voltage supply by amplifier plug-in unit DV 01 DV01 with CHANNEL A 15-pin socket GREEN OVER- ACTIVE FLOW – Input resistance for Operating- DC-current sources: voltage zero 5Ω...
  • Page 88 C-10 Types of connection for DV01 Channel connection Measuring converter with external voltage supply DV01 with DV 01 15-pin socket CHANNEL A 0 . . .+20mA GREEN OVER- ACTIVE – FLOW Input resistance for Operating- DC-current sources: voltage zero 5Ω (ground) –...
  • Page 89 Channel connection Types of connection for DV01 C-11 Measuring converter, e.g. P19AV with voltage supply by amplifier plug-in unit DV 01 CHANNEL A GREEN OVER- ACTIVE DV01 with FLOW 15-pin socket – – Operating- voltage zero (ground) +16V supply voltage CHANNEL B 50mA max.
  • Page 90 C-12 Channel connection Types of connection for DV10, DV30, DV55 2.2 Types of conn. for DV10, DV30, DV55 Amplifier plug-in units DV10 DV30 DV55 Amplifier type 600 Hz-CF 4,8 kHz-CF Transducers that can be connec- S/G half and full bridges, single S/G, CHANNEL A potentiometers Induktiv-...
  • Page 91 Types of connection for DV10, DV30, DV55 C-13 Channel connection S/G half bridge DV10, DV30, DV55 with 15-pin socket CHANNEL A Measuring signal GREEN OVER- ACTIVE FLOW Bridge excitation voltage* Bridge excitation voltage* 3’ Sense line CHANNEL B 2’ Sense line GREEN OVER- ACTIVE...
  • Page 92 C-14 Channel connection Types of connection for DV10, DV30, DV55 Single strain gauge in three-wire circuit (Programming mode: Strain gauge half bridge) DV10, DV30, DV55 with 15-pin socket CHANNEL A Bridge excitation GREEN OVER- ACTIVE voltage* FLOW 2’ Sense line Active S/G e.g.
  • Page 93 Types of connection for DV10, DV30, DV55 C-15 Channel connection Potentiometric transducer (Programming mode: Strain gauge half bridge) DV10, DV30, DV55 CHANNEL A with 15-pin socket GREEN OVER- ACTIVE FLOW Measuring signal Bridge excitation voltage* Bridge excitation voltage* CHANNEL B 3’...
  • Page 94 C-16 Channel connection Types of connection for DV10, DV30, DV55 Inductive full bridge DV55 with 15-pin socket Insert core: display +; Pullout core: display – DV 55 CHANNEL A Measuring signal GREEN OVER- ACTIVE FLOW Measuring signal Bridge excitation voltage * Bridge excitation voltage * 3’...
  • Page 95 Types of connection for DV10, DV30, DV55 C-17 Channel connection Inductive half bridge DV55 with 15-pin socket Insert core: display +; Pullout core: display – DV 55 CHANNEL A Measuring signal GREEN OVER- ACTIVE FLOW Measuring signal Bridge excitation voltage * Bridge excitation voltage * 3’...
  • Page 96 C-18 Channel connection Types of connection for DV10, DV30, DV55 Voltage source* DV55 with 15-pin socket DV 55 CHANNEL A GREEN OVER- ACTIVE FLOW Operating-voltage zero (ground) – Operating-voltage zero CHANNEL B (ground) – GREEN OVER- ACTIVE FLOW * Please see note on page C-6 DMC plus Technical specifications...
  • Page 97 Channel connection Types of connection for DV35 C-19 2.3 Types of connection for DV35 Amplifier plug-in unit DV35 Amplifier type 600Hz-CF DV 35 Transducers that can be Pt100, Resistors, Single strain gauges CHANNEL A connected Transducer supply voltage 0.025mA; 2.5mA GREEN OVER- ACTIVE...
  • Page 98 C-20 Types of connection for DV35 Channel connection Voltage source* DV35 with 15-pin DV 35 socket CHANNEL A GREEN OVER- ACTIVE FLOW Operating-voltage zero (ground) – – Operating-voltage zero CHANNEL B (ground) – GREEN OVER- ACTIVE FLOW * Please see note on page C-6 DMC plus Technical specifications...
  • Page 99 0,05 GREEN ACTIV OVERFLOW Amplifier type f / U-converter Transducers that can be Type series T30FN...T36TF torque transdu- connected cers by HBM; MBL40 measuring transmitters; incremental encoders; frequency signal-sources Supply for transducer rotor: Voltage/Initiate 55 (square wave) / – calibration...
  • Page 100 0..2; 0..20; 0..200 ranges Representation of nomi- 4.000.000 nal frequency range 5..30 Voltage range Dynamic range 0..700 (–1dB), 0..150 (–1dB) .. 200 (–3bB) 900 (–3bB) HBM Torque transducer Torque Speed: Pulses Pulses per second transducer Rev. / min. revolution Minimum Maximum Minimum...
  • Page 101 Channel connection Types of connection for DV60 C-23 Measuring cable DV60 Torque/speed amplifier Torque transducers, Measuring transmitters Channel A/Input MD (Measure) (Calibr.) Rotor supply-voltage T30FN, T32FN Kab0116-6 T34FN, MBL40 Kab0130-3 T36FN Kab141A-25 +15V Preamplifier supply-voltage T30FNA, T32FNA Kab139A-6 –15V T36FN, T36ST Torque measuring signal T34ST 2-9268.0601...
  • Page 102 C-24 Types of connection for DV60 Channel connection DV60 Torque/speed amplifier Inkremental transducer for speed measurement, 2-phase transducer Channel A/Input MD (Measure) (Calibr.) Rotor supply-voltage +15V Preamplifier supply-voltage suitable –15V Torque measuring-signal Operating-voltage zero Screen/protective housing Channel B/Input n Speed signal 1 Speed signal 2 Operating-voltage zero Screen/protective housing...
  • Page 103 Channel connection Types of connection for DV60 C-25 DV60 Torque/speed amplifier Inkremental encoder for speed measurement, 1-phase transducer Channel A/Input MD (Measure) (Calibr.) Rotor supply-voltage +15V Preamplifier supply-voltage suitable –15V Torque measuring-signal Operating-voltage zero Screen/protective housing 7-pin MS-socket Channel B/Input n Speed signal 1 Directional signal Operating-voltage zero...
  • Page 104 C-26 Types of connection for DV60 Channel connection DV60 torque/speed amplifier Frequency transducer Channel A/Input MD (Measure) (Calibr.) Rotor supply-voltage +15V Preamplifier supply-voltage –15V Frequency signal Frequency-signal Operating-voltage zero Screen/protective housing Channel B/Input n Frequency signal Frequency-signal Direction-signal Operating-voltage zero Screen/protective housing 7-pin MS-socket S: Generation of a...
  • Page 105 Channel connection Types of connection for DZ65 C-27 2.5 Types of connection for DZ65 Incremental shaft encoder DZ 65 Sinusoidal incremental signals. The second signal leads or CHANNEL A trails by 90 and is used for recognition of the direction of rota- tion.
  • Page 106 C-28 Types of connection for DZ65 Channel connection Incremental shaft encoder DZ 65 TTL square-wave pulse-sequences and appertaining inverted CHANNEL A pulse sequences. The second pulse-sequence output leads or trails by 90 and is used for recognition of the direction of rota- GREEN OVER- ACTIVE...
  • Page 107 Channel connection Types of connection for DZ65 C-29 Pulse generator with TTL/HCMOS output DZ 65 15-pin socket CHANNEL A GREEN OVER- ACTIVE FLOW IN1+ Counter pulses Ground IN3+ Reset or counter-pulse suppression CHANNEL B GREEN OVER- ACTIVE Pulse generator with open-collector outputI FLOW 15-pin socket IN1+...
  • Page 108 FLOW 1kΩ –15V Balance R1 and R2 to optimum operating point * The second transducer is only required if recognition of the di- rection of rotation is desired. E.g. HBM product OA1 (no longer commercially avaiable). DMC plus Technical specifications...
  • Page 109 FLOW IN1+ IN1– +15V IN2– Ground CHANNEL B GREEN OVER- ACTIVE FLOW The second transducer is only required if recognition of the direction of ro- tation is desired. E.g. HBM product MA1 (no longer commercially avaiable). DMC plus Technical specifications...
  • Page 110 DV10, DV30 and DV55 amplifiers are used for torque measurement.I * For recognition of the direction of rotation E.g. HBM product T4WA/S (no longer commercially avaiable). DMC plus Technical specifications...

  • Page 111: Ieee 488-78

    Interfaces Interfaces Interfaces Comparsion of the interfaces ........RS-232-C, RS-422/485 serial interfaces .
  • Page 112 Interfaces DMC plus Technical specifications...
  • Page 113 Interfaces Comparison of the interfaces Comparison of the interfaces The DMC plus includes two serial interfaces: – RS-232-C and – RS-422/485 An IEEE488-78 Bus interface can be installed as an option. The instrument can only be operated via one interface at a time.
  • Page 114 Interfaces Comparison of the interfaces IEEE 488-78 interface D Relatively ”high” transmission speed. D A number of devices can be interconnected to form a system. Data is transmitted faster than with the serial interface. When using this parallel interface you benefit from its higher data-transmission speed, because in the case of communication with several devices a serial bus’...
  • Page 115 Interfaces RS-232-C / RS-422/485 serial interfaces RS-232-C, RS-422/485 serial interfaces DMC plus Technical specifications...
  • Page 116 Interfaces RS-232-C / RS-422/485 serial interfaces 2.1 RS-232-C- and RS-422/485 interface Both interfaces are called serial interfaces, because data is transmitted successively bit by bit. The interfaces differ with regard to the voltage level used and to their construction; the RS-232-C interface is suitable for point-to-point connections up to 20m, the RS-422/485 is appropriate for point-to-point connections over longer distances up to 1200m and for bus...
  • Page 117 Interfaces RS-232-C / RS-422/485 serial interfaces Data transmission is computer-controlled with the X-ON (DC1) and X-OFF (DC3) software handshake or with the RTS and CTS hardware handshake. If the computer is ready to receive data, it issues the X-ON (DC1) control character. If it cannot receive any data, e.g. if there is no free memory space, the X-OFF (DC3) control character is issued.
  • Page 118 Interfaces RS-422/485 bus 2.1.1 RS-422/485 bus This 4-wire bus enables up to 32 devices to be connected. In contrast to the RS-232-C interface, only one computer interface is required for the connection of several devices. The bus explained in this section is an extended version of the RS-422 interface that - contrary to the RS-422 - enables several transmitters to be used.
  • Page 119 Interfaces IEEE 488-78 Bus interface IEEE 488-78 Bus interface DMC plus Technical specifications...
  • Page 120 The two plugs are electrically equivalent; the drawback of the 25-pin plug is that it can easily be mistaken for the RS-232-C plug. For this reason, HBM has used the 24-pin Amphenol plug on the IE01 function card. This bus enables max. 15 devices to be interconnected in parallel to form a system.
  • Page 121 Interfaces IEEE 488-78 Bus interface D-11 The bus comprises 16 lines; three groups are distinguished: 8 data lines 3 handshake lines 5 control lines The devices are electrically interconnected via the bus. Instructions and data are transmitted from device to device via the bus.
  • Page 122 D-12 Interfaces IEEE 488-78 Bus interface Device 1 Device 2 Device 3 Computer Correct cabling of devices Fig. D 4: DMC plus Technical specifications...

  • Page 123: Data Lines

    Interfaces IEEE 488-78 Bus interface Data lines D-13 3.1.1 Data lines For transmission of the 8-bit-long data the IEEE 488-78 bus uses eight data lines (DIO1 to DIO8). The interface instructions are also transmitted via these lines; in this case, however, at least one additional control line is used.

  • Page 124: Handshake Lines

    D-14 Interfaces IEEE 488-78 Bus interface Handshake lines 3.1.2 Handshake lines The whole data communication on the data bus is controlled according to the three-wire handshaking method by these three lines. Data-Valid signals the validity and availability of data on the data bus.

  • Page 125: Control Lines

    Interfaces IEEE 488-78 Bus interface Control lines D-15 3.1.3 Control lines The control lines are required for correct information flow through the interface: ’Interface clear’ sets the interface system to a precisely defined initial state. It is transmitted by the controller exclusively.

  • Page 126: Controller, Talker And Listener Functions

    D-16 Interfaces IEEE 488-78 Bus interface Controller, talker, listener functions 3.2 Controller, talker and listener functions Each device connected to the bus must at least have been provided with one of the following functions: Controller In general, a computer that controls the connected devices.

  • Page 127: Addressing

    In general, the address is set using a switch on the device and numbered in sequence from 0 to 30. Each device can be addressed with its individual address. For HBM devices, the factory-set address is 4. DMC plus Technical specifications...

  • Page 128: Service Request (Srq

    D-18 Interfaces IEEE 488-78 Bus interface Service request (SRQ) 3.4 Service request (SRQ) In an interconnected system of several measuring devices, it may happen that a measuring cycle requires a longer period of time. The controller waits for the end of this procedure. All other devices connected are disabled during this period of time.

  • Page 129: Serial Poll (Spoll

    Interface IEEE 488-78 Bus interface Serial poll (SPOLL) D-19 3.4.1 Serial poll (SPOLL) If a measurement has been interrupted by a service request, the computer is able to determine the device that has caused the interrupt by starting a serial poll. The computer must address all devices and poll their status value.
  • Page 130 D-20 Interfaces IEEE 488-78 Bus interface Serial poll (SPOLL) The status bits transmitted during a serial poll have the following meaning: Bit: RQS ESB MAV Status-byte register 16 Data available 32 Error-sum bit 64 SRQ code Request service Event-status bit Message available The computer must respond to the Data available message with an INPUT or ENTER and accept data.

  • Page 131: Parallel Poll (Ppoll

    Interfaces IEEE 488-78 Bus interface Parallel poll (PPOLL) D-21 3.4.2 Parallel poll (PPOLL) With a parallel poll the computer is also able to determine the device that has caused the interrupt. However, the reason for the interrupt cannot be determined. In the DMC plus , the PPOLL interface function has been realised.

  • Page 132: Interface Instructions

    D-22 Interfaces IEEE 488-78 Bus interface Interface instructions 3.5 Interface instructions These instructions are not described in the ’Operating manual’. They refer to the IEEE interface exclusively. The below table shows the most important interface instructions. The instructions are to be output via the interface as ASCII code.

  • Page 133: Interface Functions

    Interfaces IEEE 488-78 Bus interface Interface functions D-23 3.6 Interface functions The instruction interpreter included in the DMC plus has been provided with the following interface functions: Plug connection: 24-pin Cannon socket (IEEE 488-78 standard) on the IE01 Interface card. Interface function Abbreviation Meaning...
  • Page 134 D-24 Interfaces IEEE 488-78 Bus interface Interface functions DMC plus Technical specifications...

  • Page 135: E Communication With The Dmc Plus

    Communication with the DMC plus Communication with the DMC plus Communication with the DMC plus Connecting the computer to the DMC plus ......DMC plus Technical specifications...
  • Page 136 Communication with the DMC plus DMC plus Technical specifications...

  • Page 137: Connecting The Computer To The Dmc Plus

    Communication with the DMC plus Connecting the computer to the DMCplus 1 Connecting the computer to the DMC plus Do not yet switch on DMC plus nor computer. 9-pin 9-pin plug socket D RS-232-C interface (socket Bu1): DMC plus Kab255-3...
  • Page 138 Communication with the DMC plus Connecting the computer to the DMCplus D IEEE 488 interface : 24-pin 24-pin plug/socket plug/socket You need the IE01 Interface board and the Kab0488-2 connection cable. DMC plus Kab0488-2 IE01 plug-in unit When the devices have been connected, the DMC plus and the computer may be switched on.

  • Page 139: F Technical Data

    Technical data Technical data DMC plus Technical specifications...
  • Page 140 Technical data Technical data DMC plus Type DMC91T1(B) DMC91E1 DMC91T2 DMC91E2 Number of slots 14 + 1 (for IE 01 only) Number of channels max. 12 max. 28 Measurement memory Standard Measurements 40.000 With Extension Measurements 500.000 Measuring rate Measurement/s 1...9600 Measurement resolution 20...15...

  • Page 141: Technical Data Dmc Plus

    Technical data Amplifier plug-in units Technical data DMC plus / Amplifier plug-in units Amplifier plug-in channels DV 01 DV 35 Channels A and B Accuracy class 0.02 Amplifier type TF 600Hz Transducers that can be connected Thermocouples J, T, K, S, Pt100 (RTD), Pt1000;...
  • Page 142 Technical data Amplifier plug-in units Technical data DMC plus / Amplifier plug-in units Amplifier plug-in channels DV 10 DV 30 DV 55 Channels A and B Accuracy class 0.02 Amplifier type CF 600Hz CF 4800Hz Transducers that can be connected Strain gauges in half and full bridge circuits;...
  • Page 143 Accuracy Class 0.05 Type of amplifier F/V-converter Transducers that can be connected HBM-Torque-Transducers of family T30FN...T36FN; Measuring transmitter MBL40; Inkremental transducers; Frequency-sources Transducer-rotor excitation: Voltage / Trigger of Calibration signal 55 (rectangular) / 75 Current / Trigger of Calibration signal 0.8/1...

  • Page 144: Technical Data Function Cards

    Technical data Function cards Technical data for the IE01 Function Card IEEE-488-Interface IE 01 Electrical and mechanical construction IEEE 488.1 Code, format, protocol IEEE 488.2 Maximum data transmission speed kByte/s Connection Socket Type (24-pole plug connection) Interface functions Abbrevation Source handshake Acceptor handshake Talker function Listener function...
  • Page 145 Technical data Function cards Technical data for the AU01 Function Card Digital-to-analogue converter AU 01 Number of channels Output voltage Resolution 0.64 Bandwidth –1 dB 5.000 –3 dB 5.800 Ω Internal resistance < 1 Ω Load resistance 2.000 Linearity deviation 0.01 PDM residual carrier (38.4kHz) <...
  • Page 146 Technical data Function cards Technical data for the DZ65 Function Card 2-channel counter plug-in unit DZ65 Channels A and B Transducers that can be conencted Incremental transmitters, pulse transmitters, Speed transducers OA1, MA1 Torque/Screw Transduceer T4WA Measuring Transmitter MBL 40 Operating modes and nominal measuring ran- ges: Pulses...

  • Page 147: G Glossary

    Glossary Glossary DMC plus Technical specifications...
  • Page 148 Glossary This glossary includes terms used in the manual ”DMC plus Technical specifications”. ASCII American Standard Code for Information Interchange is a standard coding method. A specific code, e.g. 4F for the character O, is assigned to every computer print – and control –...
  • Page 149 Glossary DIP-switch Usually, a DIP switch is a miniature switch containing 8 single switches. Firmware Computer programs stored in EEPROM or PROM determining the device function. The firmware is encoded permanently and does not run on an external computer. Parallel interface A parallel interface is a standardised interface with 25 connection pins, for example.
  • Page 150 Glossary DMC plus Technical specifications...
