PCE-7132/5132/5032 LGA1200 Intel
i3/ Pentium
Board with (ECC/non-ECC) DDR4/M.2 (2280)/ Dual
GbE LAN
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. PCE-7132/5132/5032 PICMG 1.3 single host board
2. PCE-7132/5132/5032 startup manual
3. Serial ATA HDD data cables P/N: 1700003194
4. COM + printer ports cable kit P/N: 1701260305
5. Warranty card P/N: 2190000902
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1:
For detailed contents of PCE-7132/5132/5032,
please refer to user manual on the Advantech
Website.
Note 2: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at: get.
adobe.com/reader (Acrobat is a trademark of
Adobe)
For more information on this and other Advantech prod-
ucts, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our sup-
port website at:
https://advt.ch/PCE-7132
https://advt.ch/PCE-5132
https://advt.ch/PCE-5032
Register your products on our website and get 2 months
extra warranty for Free at:
http://www.register.advantech.com
This manual is for the PCE-5032/5132/7132
Part No. 2041513200
Printed in China
ECC/non-ECC PICMG 1.3 Single Host
®
1st Edition
September 2020
Core
®
Specifications
General
• LGA1200 10th Intel
Core™ i9/i7/i5/i3/Pentium
®
• BIOS: AMI 256 Mb SPI BIOS
• Chipset:
- PCE-7132: Intel W480E
- PCE-5132: Intel Q470E
- PCE-5032: Intel H420E
• System memory:
- PCE-7132: Supports dual channel DDR4 2666/2933
32GB per DIMM with ECC/non-ECC; Max. capacity is
up to 64GB
- PCE-5132/5032: Supports dual channel DDR4
2666/2933 32GB per DIMM without ECC; Max. capacity
is up to 64GB
Note: Please select Intel ECC supported processor to
enable ECC function.
• SATA Ports:
- PCE-7132/5132 supports 6 x SATA3.0 ports with SW
Raid 0,1,5,10.
- PCE-5032 supports 4 x SATA3.0 ports without Raid
function.
• M.2 Ports: PCE-7132/5132 supports M.2 2280 type M
module and compatible to PCI Express 3.0
• Serial ports: Two RS-232 with pin headers
• Parallel port: One parallel port, supports SPP/EPP/ECP
mode
• Watchdog timer: 255 level timer intervals
• USB 2.0:
- PCE-7132/5132/5032: 6*USB2.0 (USB Type
A*1+Rear*1, 4 on backplane)
• USB 3.2:
- PCE-7132/5132: 6*USB3.2 (Gen1) (Pin-header*6),
2*USB3.2 (Gen2) (Rear I/O)
- PCE-5032: 2*USB3.1 (Gen1) (Pin-header*2), 2*USB3.2
(Gen1) (Rear I/O)
• GPIO: One programmable 8-bit GPIO pin-header
VGA Interface
• Chipset: Intel
HD Graphics
®
• Shared system memory is subject to OS
Ethernet Interface
• Chipset supports:
- LAN 1: I219LM(PCE-7132/5132); I219V(PCE-5032)
- LAN 2: I210AT(PCE-7132/5132); I211AT (PCE-5032)
• Connection: 2 x on-board RJ-45 connectors with LED
indicators.
PCE-7132/5132/5032 Startup Manual 1
i9/i7/i5/
TM
/Xeon
®
®
