Advantech PCE-5127 Startup Manual

PCE-5127/7127 LGA1155 Intel
tium /Xeon
®
(ECC) DDR3 / Dual GbE LAN
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. 1 PCE-5127/7127 PICMG 1.3 Single Host Board
2. 1 PCE-5127/7127 startup manual
3. 1 CD with utility
4. 1 user note for full-sized CPU card
5. 2 Serial ATA HDD data cables
6. 2 Serial ATA HDD power cables
7. 1 COM + printer ports cable kit
8. 1 4-port USB cable kit
9. Keyboard and mouse Y cable
10. 1 jumper package
11. 1 warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1:
For detailed contents of PCE-5127/7127, please
refer to information on the enclosed CD-ROM (in
PDF format).
Note 2:
Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at: get.
adobe.com/reader (Acrobat is a trademark of
Adobe)
Note 3: PCE-7127G2-CN don't support printer port,
Hardware monitor and IPMI. 1701260305 (Print
port+COM cable) is excluded in package
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/default.
aspx
This manual is for the PCE-5127/7127 Series Rev. A1.
Part No. 2006512701
Printed in China
PICMG 1.3 Single Host Board with
®
2nd Edition,
Sep. 2014
Core
® TM
Specifications
General
• LGA1155 Intel Core™ i7/i5/i3/Pentium
®
• BIOS: AMI 64 Mb SPI BIOS
• Chipset:
- PCE-7127: Intel C216
- PCE-5127: Intel Q77
• System memory:
- PCE-7127G2: Supports dual channel DDR3 1333/1600
8GB per DIMM with ECC; Max. capacity is up to 16GB
- PCE-5127G2: Supports dual channel DDR3
1333/1600 8GB per DIMM without ECC; Max. capacity
is up to 16GB
• SATA ports:
- PCE-7127G2: Supports 2 SATA3.0 and 4 SATA2.0 with
Raid 0, 1, 5, 10.
- PCE-5127G2: Supports 2 SATA3.0 and 4 SATA2.0 with
Raid 0, 1, 5, 10.
Note 1: SATA3.0: 600MB/sec; SATA2.0:300MB/sec
Note 2: PCE-5127/7127 does NOT support any IDE ports.
• Serial ports: Two RS-232 with pin Headers
• Parallel port: One parallel port, supports SPP/EPP/ECP
mode. PCE-7127 CN version don't support printer port
• Keyboard/mouse connector: Supports one standard
PS/2 keyboard and mouse connector and one external
6-pin header
• Watchdog timer: 255 level timer intervals
• USB 2.0:
- PCE-7127G2: 9*USB2.0 (Pin-header*4+USB Type A*1+
4 on backplane)
- PCE-5127G2: 9*USB2.0 (Pin-header*4+USB Type A*1+
4 on backplane)
• USB 3.0:
- PCE-7127G2: 3*USB3.0 (Pin-Header*2+Rear*1)
- PCE-5127G2: 3*USB3.0 (Pin-Header*2+Rear*1)
• GPIO: One programmable 8-bit GPIO pin-header
VGA Interface
• Chipset: Intel HD Graphics
®
• Shared system memory is subject to OS

Ethernet Interface

• Chipset supports:
- LAN 1: Intel
82579LM for all SKUs
®
- LAN 2: Intel 82583V for PCE-5127G2 and
®
Intel 82574L for PCE-7127G2
®
• Connection: 2 on-board RJ-45 connector with LED
indicators
PCE-5127/7127 Startup Manual 1
i7/i5/i3/ Pen-
/Xeon
® ®
PCE-7127G2-CN
