Reset button functions for SPX+ units

There are specific commands you can send to the unit by holding the Reset button for a specified
amount of time.
You'll have to use something sharp, such as a straightened paperclip to be able to press Reset.
Commands:
Time to hold Action
< 3 sec Speak/show IP and broadcast its info (display on LCD sensor too, if connected)
3..7 sec Reboot (reset CPU)
7..12 sec Web UI password reset
12..17 sec Clear the sensor, notification and access DBs, logs
Serial flash erase (
17..25 sec Reset to factory defaults (serial flash erase + config erase)
> 25 sec No action (useful when the button was pressed by mistake)
Notes:
- When the Reset button is held for longer than 12 seconds (DB erase) and then released, the Sensor
Port 1 and 2 LEDs will give a visual indication of the state of database erase (the reboot and
password reset doesn't have visual indication).
- When the button is held longer than 17 seconds (factory reset) and then released, these sensor port
LEDs will be blinking fast and alternate during the factory reset mode.
SPX+ Introduction Manual - updated until firmware 4997
DB erase without factory reset, the system configuration is kept
