3 OVERVIEW

DESCRIPTION

The Control X is CZone's most flexible digital switching module yet, offering configurable input and output channels
allowing for multiple configuration options. The Control X features configurable software fusing, meaning no need to
purchase and install physical fuses. Current is monitored on all circuits to provide the overcurrent protection and circuit
bypass is available via the capacitive touch buttons on the module. The 45% smaller footprint than the COI/Control 1
has been achieved with an all-new electrical design and moulding the connector receptacles directly into the housing,
and a new IPX7 enclosure allows for installation in all environments.

FEATURES

• Compact size ensures ease of installation on wide range of boats and RV's where space is limited.
IPX7 enclosure allows for installation in all environments.
•
100% solid state switching provides improved reliability, silent operation & smaller footprint than traditional
•
relays.
• Current is monitored and displayed for each circuit and also provides overcurrent protection and low
current/systems on detection.
Software fuse ratings entered in configuration file, no need to purchase and install physical fuses.
•
• Configurable PWM Frequency.
Automatic bilge pump feedback monitoring.
•
Dual speed wiper motor controller with synchronization for up to 8 motors with 3 configurable intermittent timer
•
settings and the Control X PLUS has a switch to ground brake option for compatible wiper motors.
• RGB / RGBW lighting control with configurable zones for dimming, effects and sequences.
Support for multiplex switch inputs means multiple mechanical switches can be connected to a single input
•
channel.
