10 Technical Specifications

Specifications
Circuit protection
NMEA2000 connectivity
Output wire range
Maximum current
Power consumption max
Power consumption sleep
Reverse Motor Control
RGBW Zones
Circuit Current Monitoring
Bilge Pump Running Detection
Addition Inputs
Power supply
Network Supply voltage
Circuit bypass
Ingress protection
Compliance
Warranty period
Operating temperature range
Storage temperature range
Dimensions W x H x D
Weight
EN / CZone® Control X User & Installation Manual
Software Fusing (Configurable using CZone Configuration Tool)
1 x CAN Micro-C port, 1 LEN
0.5 - 6mm (24AWG – 8AWG)
120A Total Module Current
200mA
<5mA
Control X:0
Control X PLUS: 2
Control X:1
Control X PLUS: 2
All Output Channels
All High Side Output Channels
Shunt/State Of Charge, Multiplex Switch Inputs
M6 (1/4") Positive Terminal (9-32V)
9-16V via NMEA2000
Electronic via Capacitive Touch Panel
IPx7 (mounted vertical on bulkhead and flat)
Ignition protected, CE, RCM, NMEA2000, UK-CA (with connectors,
connector plugs and dipswitch cover fitted)
2 years
-15C to +55C (-5F to +131F)
-40C to +85C (-40F to +185F)
246.5mm x 137.4mm x 54.0mm
Control X:792g, Control X PLUS: 810g
