Assembly & Installation Manual: for 2" Receiver Hitches
PARTS LIST:
2" Receiver Tube Assembly - QTY 1
Cargo Basket - QTY 1
M10 Carriage Bolts - QTY 4
M10 Nylock Nuts - QTY 4
Reinforcing Plates - QTY 4
#
12033.1003
PARTS LIST:
Cotter Pin - QTY 1
5/8" Hitch Pin - QTY 1
REQUIRED TOOLS:
Safety Glasses
17mm Wrench or Socket
TO REDUCE RISK OF SERIOUS INJURY OR PROPERTY DAMAGE:
READ ALL SAFETY MESSAGES AND UNDERSTAND ALL INSTRUC-
TIONS AND PROCEDURE NOTI ES BEFORE ATTEMPTING TO
INSTALL OR USE THIS PRODUCT. FOLLOW ALL INSTRUCTIONS
AND WARNINGS WITH PRODUCT & VEHICLE OWNERS MANUAL.
REGARDING RECEIVERS: SEE PAGE 2 FOR URGENT RECEIVER
CAPACITY WARNINGS. DO NOT ALLOW RECEIVER MOUNTED
ACCESSORIES (RACKS, ETC.) TO BLOCK VEHICLE MIRRORS
OR LIGHTS. READ AND UNDERSTAND ALL CAPACITY WARNINGS.
RISK OF EYE INJURY! SAFETY GLASSES MUST BE WORN AT
ALL TIMES WHILE INSTALLING OR MAINTAINING THIS PRODUCT.
TORQUE AND RECHECK FASTENERS AFTER 250 MILES AND
FREQUENTLY THEREAFTER. INSPECT BUMPER AND MOUNT
BEFORE USE. DO NOT USE IF DAMAGED.
CHECK STATE AND LOCAL HIGHWAY SAFETY LAWS REGARDING
PERMITTED HITCH MOUNTED ACCESSORIES
The Trusted Source
Advertisement
Table of Contents
Related Manuals for Quadratec 12033.1003
Summary of Contents for Quadratec 12033.1003
- Page 1 Assembly & Installation Manual: for 2” Receiver Hitches 12033.1003 PARTS LIST: PARTS LIST: 2” Receiver Tube Assembly - QTY 1 Cotter Pin - QTY 1 Cargo Basket - QTY 1 5/8” Hitch Pin - QTY 1 M10 Carriage Bolts - QTY 4...
- Page 2 Careful attention is required to this instruction or operation but does ® generally not relate to personal injury. Damage to your Quadratec product or other property may result if you don’t follow instructions. Before You Begin Installation:...
- Page 3 Cargo Rack Installation: Place the Cargo basket onto the receiver Then, insert a carriage bolt through tube assembly as shown with the reflec- the receiver tube and cargo basket. tors facing the rear. Align the square holes in the reliever tube with the square holes in the cargo basket.
- Page 4 Quadratec to obtain a RGA number only to Quadratec branded accessories first sold (610-701-3336). All labor, removal, shipping in the United States, Quadratec warrants to the and installation costs are customer’s initial retail purchaser only that your responsibility.
