Quadratec 12033.1001 Assembly & Installation Manual

Assembly & Installation Manual: for 2" Receiver Hitches
PARTS LIST:
Cargo Rack Halves - QTY 2
2" Receiver Tube Assembly - QTY 1
Connecting Plates - QTY 2
M12 x 75 Bolts - QTY 3
M12 Flat Washers - QTY 6
M12 Nylock Nuts - QTY 3
Plastic End Cap - QTY 1
Hitch Pin & Cotter Pin - One Each
# 12033.1001
M10 x 20 Carriage Bolts - QTY 8
M10 Flat Washers - QTY 8
M10 Nylock Nuts - QTY 8
REQUIRED TOOLS:
Safety Glasses
19mm Wrench & Socket
17mm Wrench or Socket
TO REDUCE RISK OF SERIOUS INJURY OR PROPERTY DAMAGE:
READ ALL SAFETY MESSAGES AND UNDERSTAND ALL INSTRUC-
TIONS AND PROCEDURE NOTICES BEFORE ATTEMPTING TO
INSTALL OR USE THIS PRODUCT. FOLLOW ALL INSTRUCTIONS
AND WARNINGS WITH PRODUCT & VEHICLE OWNERS MANUAL.
REGARDING RECEIVERS: SEE PAGE 2 FOR URGENT RECEIVER
CAPACITY WARNINGS. DO NOT ALLOW RECEIVER MOUNTED
ACCESSORIES (RACKS, ETC.) TO BLOCK VEHICLE MIRRORS
OR LIGHTS. READ AND UNDERSTAND ALL CAPACITY WARNINGS.
RISK OF EYE INJURY! SAFETY GLASSES MUST BE WORN AT
ALL TIMES WHILE INSTALLING OR MAINTAINING THIS PRODUCT.
TORQUE AND RECHECK FASTENERS AFTER 250 MILES AND
FREQUENTLY THEREAFTER. INSPECT BUMPER AND MOUNT
BEFORE USE. DO NOT USE IF DAMAGED.
CHECK STATE AND LOCAL HIGHWAY SAFETY LAWS REGARDING
PERMITTED HITCH MOUNTED ACCESSORIES
