Section 2 – Operating Instructions

Training

On site training classes are available. For more information, contact our Sales Department at
Chandler Engineering.

Preparing the Instrument for a Test

Prior to running a test, the following steps must be performed.

Configuring the Consistency Display

1. Turn on the instrument.
2. Press
A manual has been enclosed for your reference.

Programming the Temperature and Pressure Controllers

The programming for the temperature and pressure controllers is identical. Following is a
brief procedure for programming the controllers. For complete instructions, see the Model
8050/8051 Temperature Controller and Model 8060/8061 Pressure Controller manuals.
1. Press and hold the Advance key
(ProF) will appear in the lower display and the profile number (e.g. P1) appears in the
upper display.
2. Multiple profiles (P1 to P4) can be stored in the device. The shortcut keys (EZ1 and EZ2)
are factory configured to start and stop profile P1. The 5270 DACS software also utilizes
P1 when a profile is downloaded to the controller for an automated test. Press the Up
or Down
3. Press the Advance Key
4. Press the Up
5. Press the Advance Key
6. Press the Up
7. Press the Infinity Key
8. Press the Infinity Key
9. From any point press and hold the Infinity Key
Page.
10. To manually start or stop a profile, press either the EZ1 or EZ2 key.

API Slurry Cup Preparation

For an accurate thickening time test to be performed, it is important for the slurry cup to be
properly maintained and prepared. The following procedure should serve as a guideline for
slurry cup preparations. While assembling the slurry cup, refer to drawing 07-0031 in the
or (Up or Down) to change the alarm limit.
keys to select P1.
to move to the first step.
or Down keys to move through and select the step type.
to move through the selected step settings.
or Down keys to change the step settings.
at any time to return to the step number prompt.
again to return to the profile number prompt.
for approximately five seconds. The profile prompt
for two seconds to return to the Home
SECTION 2 - OPERATION 2-1
