- Page 2 3 fixed settings (medium/fast/slow) to set the slew applied to the raw signal coming from the sensor. Gain: Sets the gain for both outputs Offset: Adjusts the Offset for the main Output. Inverted Offset: Adjusts the Offset for the Inverted Output. Specs: ±50mA 4.5cm deep ADDAC SYSTEM page 2...
-
Page 3: Controls Description
Couter Clockwise : Less Sensitivity Clockwise : More Sensitivity Output CV Gain LIGHT RESPONSE SLEW Medium / Fast / Slow Bipolar Monitor LEDs CV Offset Bipolar Monitor LEDs Inverter CV Offset Sensor Input CV Output Inverted CV Output ADDAC SYSTEM page 3... - Page 4 ADDAC308 User’s Guide ADDAC308 LIGHT TO CV SIGNAL FLOW DIAGRAM EXTERNAL SENSOR INPUT LIGHT SENSOR SENSITIVITY SENSITIVITY KNOB GAIN GAIN KNOB MEDIUM RESPONSE SLEW FAST SLOW INVERTED OFFSET OFFSET KNOB OFFSET KNOB OFFSET CV OUTPUT INVERTED CV OUTPUT ADDAC SYSTEM page 4...
- Page 5 For feedback, comments or problems please contact us at: addac@addacsystem.com ADDAC308 USER’S GUIDE Revision.01 December.2020...
