- Page 2 ADDAC305 Assembly Guide November.2017 Parts included in the kit: 1x Front Panel 1x Pcb 3x 10uF SMD Capacitors 4x 100nF SMD Capacitors 8x 1k SMD Resistors 8x 470R SMD Resistors 1x 78M05 IC 2x 10mm female/female spacer 4x M3 fiber washer...
- Page 3 ADDAC305 Assembly Guide STEP 1: Locate Pcb and surface mount parts. STEP 2: Start by adding a bit of solder to every smd part right pads, this will make it easier to solder the surface mount parts. If you’re left handed then add solder to the left pads.
- Page 4 ADDAC305 Assembly Guide STEP 3: Now let’s place all 8 of the 1k resistors, use a tweezer and solder the right pad of each by heating the already added solder and place the part in place. STEP 4: Next solder the right pad for all four 100nF capacitors.
- Page 5 ADDAC305 Assembly Guide STEP 5: Repeat the process for the eight 470R resistors. STEP 6: Finally rotate the pcb 180 degrees and solder all left pads of all smd parts. ADDAC SYSTEM page 5...
- Page 6 ADDAC305 Assembly Guide STEP 7: Place and solder the 78M05 IC. STEP 8: Next place and solder the three 10uF capacitors. ADDAC SYSTEM page 6...
- Page 7 ADDAC305 Assembly Guide STEP 9: Place and solder the IDC power connnector, note that the indent faces down. STEP 10: Next place the spacers adding a fiber washer between the pcb and the spacer. ADDAC SYSTEM page 7...
- Page 8 ADDAC305 Assembly Guide STEP 11: Locate the jacks and cut the smallest legs like shown below. We’ll now populate all front panel parts: DO NOT SOLDER ANY PART UNTIL ALL PARTS ARE PLACED! STEP 12: Locate and place, do not solder, the 3 jacks with threaded shaft at the bottom.
- Page 9 ADDAC305 Assembly Guide STEP 14: Next let’s place latch buttons, note that the buttons have polarity because of the leds inside, longer leg is the positive (+) side. The bottom of the button also shows + & - markings to show the polarity.
- Page 10 ADDAC305 Assembly Guide We’ll now describe s a good practice that minimizes any damage that may occur to all front panel parts for continued exposure to the soldering iron heat. It happens often that users not very used to soldering spend too much time on each pad.
- Page 11 ADDAC305 Assembly Guide STEP 17: After all parts are placed we’ll now solder all pads. Follow the process described in the previous page. STEP 18: Once finished it will look like this. Congratulations, you’re done! ADDAC SYSTEM page 11...
-
Page 12: Assembly Guide
For feedback, comments or problems please contact us at: addac@addacsystem.com ADDAC305 ASSEMBLY GUIDE Revision.01 November.2017...
