ADDAC System ADDAC222 User Manual

1v/oct to midi notes

Table of Contents

Need help?

Do you have a question about the ADDAC222 and is the answer not in the manual?

Page 2 Welcome to: ADDAC222 1V/OCT TO MIDI NOTES USER’S GUIDE Revision.01 August.2019 CONTROLS DESCRIPTION MIDI Channel: Each channel can be set to an independent MIDI Channel - from 1 to 9 NOTE 1 OFF: Depending on the Mode select- ed, either cancels the oldest...
Page 3 ADDAC222 User’s Guide OPERATION PRINCIPLE This module allows the conversion of CV signals to a stream of MIDI notes. A MIDI Note is defined by 3 variables, MIDI Channel, Note Number and Velocity. The MIDI Channel can be set from 1 to 9.
Page 4 ADDAC222 User’s Guide OPERATION MODES There are 3 Operation Modes: Continuous, Triggered and Gated. MODE 1 - Continuous: In this Mode a new note will be generated every time a CV change is detected at the 1v/oct CV input. The [NOTE1 OFF] push buttons and trigger inputs will cancel the oldest active note.
Page 5 ADDAC222 User’s Guide CHEAT SHEET MIDI CHANNEL CHANNEL 1 CHANNEL 2 BANK A CHANNEL 3 CHANNEL 4 CHANNEL 5 BANK B CHANNEL 6 CHANNEL 7 CHANNEL 8 BANK C CHANNEL 9 NOTE1 OFF MODE 1 : TRIGGER CANCELS OLDEST NOTE...
Page 6 For feedback, comments or problems please contact us at: addac@addacsystem.com ADDAC2222 USER’S GUIDE Revision.01 August.2019...
