Electrical Installation - STEINEL XLED home 2 Instructions Manual

D Sensor unit
E Time setting (XLED home 2 S/XLED home 2 XL S)
F Twilight setting
(XLED home 2 S/XLED home 2 XL S)
Product components, (XLED home 2) (Fig. 3.12)
A LED panel
B Enclosure
C Wall mount
Luminous intensity distribution (Fig. 3.13)

4. Electrical installation

• Switch OFF power supply. (Fig. 4.1)
Connecting the mains power supply lead
The supply lead is a 2 or 3-core cable:
L = phase conductor (usually black,
brown or grey)
L' or  = phase conductor (usually black,
brown or grey), in master/master
or master/slave mode only. Mains
supply lead is used as connection
lead for switching output.
N = neutral conductor (usually blue)
= protective-earth conductor (green/
PE
yellow)
Note:
The protective-earth conductor need not be con-
nected for this product.
Wiring diagram, master/slave (Fig. 4.2)
Wiring diagram, master/master (Fig. 4.3)
Wiring diagrams, slave (Fig. 4.4)
Wiring diagram, XLED home 2 SC (Fig. 4.5)
Important:
Incorrectly wired connections will produce a short
circuit later on in the LED floodlight or your fuse
box. In this case, you must identify the individual
conductors once again and reconnect them.
The light source of this LED floodlight cannot
be replaced. If the light source needs to be
replaced (e.g. at the end of its service life), the
complete LED floodlight must be replaced.
5. Installation
• Check all components for damage.
• Do not use the product if the LED floodlight is
damaged.
• Select an appropriate mounting location, taking
the reach and motion detection into considera-
tion. (Fig. 5.1/5.2/5.3)
• Align the LED floodlight. (Fig. 5.4)
The most reliable way to detect movement is given
by mounting the LED floodlight to point across the
direction in which people walk and by making sure
no obstacles (e.g. trees, walls etc.) interrupt the line
of sensor vision. (Fig. 5.2/5.3)
Mounting procedure
• Switch OFF power supply. (Fig. 4.1)
• Undo retaining screw. (Fig. 5.5)
• Detach enclosure (B) from wall mount (C). (Fig. 5.6)
• Detach plug-in terminal from wall mount. (Fig. 5.7)
• Mark drill holes. (Fig. 5.8)
• Drill holes and fit ground plugs. (Fig. 5.9)
• Fit sealing plug. (Fig. 5.10)
– Power supply lead, concealed (Fig. 5.11)
– Power supply lead, surface-mounted, with
spacers (Fig. 5.12)
• Connect conductors.
– XLED home 2 S / XLED home 2 XL S
(Fig. 5.13)
An additional external load can be connected
to N und L'/.
– XLED home 2 SC / XLED home 2 (Fig. 5.14)
• Connect plug-in terminal. (Fig. 5.15)
• Fit enclosure onto wall mount. (Fig. 5.16)
• Screw in locking screw. (Fig. 5.17)
• Switch ON power supply. (Fig. 5.17)
• Make settings ➜ "6. Function"
6. Function
XLED home 2 S/XLED home 2 XL S/
XLED home 2
Factory settings
Time setting (E): 8 seconds
Twilight setting (F): 2000 lux, (daytime mode)
