Dimensions
VG342(R)-5DZ-06„-S1„-X87
Safety limit switch
Made by
Rockwell Automation
Port size: 1/8" (Without check valve)
Applicable tube O.D.: Ø 8, Ø 5/16" (With check valve)
(External pilot port)
Safety limit switch
(made by Rockwell Automation)
Part number: 440P-CDPB03R6
Applicable cable O.D.
Ø 4.5 to Ø 7
37.5
3/4"
[1(P) port]
Safety Standard ISO 13849-1 Certifi ed
Residual Pressure Release Valve with Detection of Main Valve Position
Channel 2
A
(75)
Vent port
Should be normally open.
3 x Ø 8.5
(Mounting hole)
3
2
73
2 x 3/4" [3(R) port]
Should be normally open.
3 Port Solenoid Valve/
Dual Residual Pressure Release Valve (-X87)
Channel 1
M12 x 1
Pg9
(48.2)
3
1
(11.4)
73 10
75 45.5
164.5
75 42.3
VG342-X87
64.5
34
(27.7)
37.5
77
3/4"
[2(A) port]
View A
M12 connector
Pin
number
(Max. 3)
