- Page 1 Doc. no.DOC1098193 NN70005900 PRODUCT NAME 2 Port Solenoid Valve For Dust Collector (Direct piping type・For high temperature) MODEL / Series / Product Number ＶＸＦ２２Ａ（Ｃ，Ｄ）＊＊ ＶＸＦ２３Ａ（Ｃ，Ｄ）＊＊ ＶＸＦ２４Ａ（Ｃ，Ｄ）＊＊ ＶＸＦ２５Ａ（Ｃ，Ｄ）＊＊...
- Page 2 Contents Contents ――――――――――――――――――― P1 Contents ――――――――――――――――――― P2 3. Contents ――――――――――――――――――――― P9 Operation Principle ――――――――――――――― P9 Operation Principle ―――――――――――――― P12 Operation Principle ―――――――――――――― P13 Operation Principle ―――――――――――――― P14 - 1 -...
-
Page 3: Safety Instructions
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. -
Page 4: Limited Warranty And Disclaimer/Compliance Requirements
Safety Instructions Caution SMC develops, designs, and manufactures products to be used for automatic control equipment, and provides them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not allowed. Products SMC manufactures and sells cannot be used for the purpose of transactions or certification specified in the Measurement Act of each country. - Page 5 Design Warning Cannot be used as an emergency shutoff valve etc. The valves presented in this catalog are not designed for safety applications such as an emergency shutoff valve. If the valves are used in this type of system, other reliable safety assurance measures should also be adopted.
- Page 6 Fluid properties Use a general compressed air with a filter of 5 μm or less mounted on the inlet of the piping. (Excluding dry air) Caution Leakage voltage Particularly when using a resistor in parallel with a switching element and using a C-R element (surge voltage suppressor) to protect the switching element, take note that leakage current will flow through the resistor, C-R element, etc., creating a possible danger that the valve may not turn off.
- Page 7 Caution 1. Preparation before piping Before piping is connected, it should be thoroughly blown out with air (flushing) or washed to remove chips, cutting oil and other debris from inside the pipe. Install piping so that it does not apply pulling, pressing, bending or other forces on the valve body.
- Page 8 Maintenance Warning Removing the product The valve becomes hot depending on the fluid temperature. Confirm that the valve temperature has dropped sufficiently before performing work. If touched inadvertently, there is a danger of being burned. (1) Shut off the fluid supply and release the fluid pressure in the system. (2) Shut off the power supply.
- Page 9 ■Conduit When used as an IP65 equivalent, use seal to install the wiring conduit. Also, use the tightening torque below for the conduit. Class H coil: AWG18 Outside insulator diameter of 2.1mm Lead wire color Rated voltage ② ② 100 ACV Blue Blue 200 ACV...
- Page 10 3. Outline This operation manual introduces L shape 2-port valve with high response and instantaneous mass flow rate controlling capacity which discharges air in acoustic velocity and bruches off dust on the back filter or blows out work by taking advantage of impact wave. Though main valve opens and closes by the pressure operation from the pressure working chamber, the opening velocity of the main valve is set as high velocity to gain maiximum efficiency with smaller air consumption.
- Page 11 VXF23A**** VXF24A**** - 10 -...
- Page 12 VXF25A**** - 11 -...
- Page 13 5. Operation Principle（VXF25A***） When unenergized Spring The fluid enters the IN side and goes Supply orifice through the supply orifice to fill the Pressure chamber pressure chamber. The main valve is closed by the force which pushes down the valve and the spring reaction force.
-
Page 14: Troubleshooting
6． Trouble shooting When a failure during the operation, check in the procedure and take the countermeasures as shown below. Malfunctioning Slow opening/closing Break of part Replace with new part Leak from pilot valve Disassemble and clean the pilot valve Silencer clogging Replace with new part Silencer Clogging of supply port... - Page 15 7． Disassembly/ Assembly Procedure When disassembling, shut off the pressure source and release the residual pressure, then disassemble according to the following procedure. VXF22,23A*** bonnet diaphragm Ass'y spring VXF24A*** hexagon head bolt (4 places) VXF25A*** Fig1. Bolt tightening procedure 1． Disassembly/ Assembly Procedure 1) Loosen hexagon socket head cap screw 1 so that bonnet 2, spring 3 and diaphragm Ass'y 4 are disassembled.
- Page 16 Note 1) Check visually that thread part of hexagon socket head cap screw is completely got through the bolt hole of diaphragm Ass'y at assembly. If thread is not properly screwed in the bolt hole at tightening, leakage or diaphragm damage might be caused. Screw-in thread part of hexagon socket head cap screw to the bonnet and diaphragm Ass'y before assembling them on the body so that the risk of diaphragm falling is minimized.
- Page 17 Revision history Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © SMC Corporation All Rights Reserved...
