Residual Pressure Release Valve with Detection of Main Valve Position
Dimensions
D
VP744(R)-5 Z1-04„-S1„„-X555/X585
Y
Safety limit switch
Made by
Rockwell Automation
Vent port
(Ø 6.2)
(With check valve)
M12 connector
2 x 1/2"
[3(R) port]
Vent port
18.5
(Ø 6.4)
27.2
70.2
Safety Standard ISO 13849-1 Certifi ed
Dual Residual Pressure Release Valve with Soft Start-up Function (-X555/X585)
(22.9)
2 x Ø 6.2
(For mounting)
(Variable throttle type)
(Max. 10)
1/2"
[2(A) port]
3 Port Solenoid Valve/
1/2"
[1(P) port]
40 86.3
245
67 6.5
(86.3)
236.4
40
Safety limit switch (made by Rockwell Automation)
Part number: 440P-CDPB03R6
VP-X555, X585
Port size: 1/8" (Without check valve)
Applicable tube O.D.: Ø 6, Ø 1/4" (With check valve)
(External pilot port)
Applicable cable O.D.
Ø 3.5 to Ø 7
18
117.3
8
A
View A
M12 connector
Pin
number
16
