VP-X538
Dimensions
D
VP544(R)-5 Z1-03„-„-X538
Y
D
VP544(R)-5 Z1-03„-M„-X538
Y
Safety limit switch
Made by
OMRON
2 x 3/8"
[3(R) port]
G 1/2
(M12 connector)
28.2
(59.7)
9
Vent port
(Ø 6.2)
(22.9)
(With check valve)
2 x Ø 5.2
(For mounting)
Channel 2
Channel 1
17.5
(Max. 10)
3/8"
[2(A) port]
28.5
3/8"
57
[1(P) port]
112 90.4
47 5
(90.4)
201.8
28.5
Dual Residual Pressure Release Valve (-X538)
For M12 connector
A
Port size: 1/8" (Without check valve)
Applicable tube O.D.: Ø 6, Ø 1/4" (With check valve)
(External pilot port)
11.3
(14)
Safety limit switch (made by OMRON)
Part number: D4N-2B31 (G 1/2)
: D4N-9B31 (M12 connector)
View A
Pin
number
Applicable cable O.D.
Ø 3.5 to Ø 7
97.3
