Safety Standard ISO 13849-1 Certifi ed
Residual Pressure Release Valve with Detection of Main Valve Position
Valve Specifi cations
Fluid
Type of actuation
Operation
Operating pressure range
External pilot pressure
Maximum operating frequency
Minimum operating frequency
Operating and ambient temperature
Ambient humidity
Manual override
Pilot exhaust
Lubrication
Mounting orientation
Impact/Vibration resistance
Enclosure
Operating environment
Weight
B10d (MTTFd calculation)
Internal Pilot Type
Caution
Valve may not operate properly when air supply to P port is not adequate and the supply pressure
to the valve is lower than 0.25 MPa, the minimum operating pressure. Be careful with insuffi cient
supply pressure.
Piping for External Pilot Type
Caution
The product may not operate when the external pilot pressure is insuffi cient due to simultaneous
operation or restricted air piping. In this case, use the check valve (AKH series) with the external
pilot port, change the piping size or adjust the set pressure to provide a constant pressure of 0.25
MPa or more.
Flow Rate Characteristics
Series
VG342-X87
∗
These values have been calculated according to ISO 6358 and indicate the fl ow rate under standard
conditions with an inlet pressure of 0.6 MPa (relative pressure) and a pressure drop of 0.1 MPa
Solenoid Specifi cations
Electrical entry
Rated voltage
Allowable voltage –15 % to +10 % of
fl uctuation
Power consumption
Suppressor
Indicator
3 Port Solenoid Valve/
N.C. (Spring return)
Internal pilot
0.25 to 0.7 MPa
—
−10 to 50 °C (No freezing)
95 %RH or less (No condensation)
2.8 kg
Flow rate characteristics
1 2 (P A)
C Q
b Cv
[l/min (ANR)] ∗
3
[dm /(s·bar)]
26.6 0.04 5.5 5864
Safety Limit Switch Specifi cations
DIN terminal Manufacturer
24 V DC Electrical wiring
Contact resistance
rated voltage
Min. applicable load 5 V DC, 1 mA (Load resistance) 5 V DC, 5 mA (Load resistance)
2.2 W Max. voltage
Diode Max. load current
LED Max. load inductance
Insulation voltage
Protection against electric shock
VG342-X87
Air
External pilot
0.25 to 0.7 MPa
0.25 to 0.7 MPa
(Same as operating pressure)
30 times/minute
1 time/week
None
Individual exhaust
Not required
Unrestricted
150/50 m/s 2
IP40
Indoors
2.9 kg
900000 times
2 3 (A R)
C
b Cv
[l/min (ANR)] ∗
3
[dm /(s·bar)]
28.6 0.03 5.6 6278
OMRON Rockwell Automation
M12 connector
25 mΩ or less 50 mΩ or less
24 V DC
50 mA
0.5 H
300 V 600 V
Class II (EN 60947-5-1: 2004)
Q
20
