Optional Accessories - SMC Networks VP Series Manual

VP500/700-X538, X555, X585

Optional Accessories

Piping Adapter: 3/8, 1/2
A piping adapter allows installation/removal of the component
without removing the piping and thus makes maintenance easier.
Port size
Centre of
F.R.L.
body
D
Note)
Part no. Port size
E300-„03-A
3/8 31.8
E400-„04-A
1/2 31.8
Note) „ in part numbers indicates a pipe thread type.
No indication is necessary for Rc; however,
indicate N for NPT, and F for G.
∗ Separate interfaces are required for modular unit.
Ordering Example ∗
VP544-5DZ1-03-X538 ······· 1 pc.
Filter regulator
AW30-03G-B ····················· 1 pc.
Spacer with bracket
Y300T-A ···························· 3 pcs.
Piping adapter
E300-03-A ························· 2 pcs.
∗ Each product is not assembled.
Spacer with Bracket Mounting Position
Dual residual pressure release valve (-X538)
IN
a b
d
Model a
VP544-5DZ1-03-X538 33.9
VP744-5DZ1-04-X538
34.4
17
A
A B D
30 30
36 36
Dual residual pressure release valve
with soft start-up function
Piping
adapter
OUT
c
b c d Note
AW30-03G-B
57.2 95.7 220.7 Y300T-A
E300-03-A
AW40-04G-B
75.2 118.7 262.7 Y400T-A
E400-04-A
Spacer with Bracket
D
K
J
Centre of
F.R.L.
body
Seal
Part no. A B C D
Y300T-A
4.2 82 41 71.5
Y400T-A
5.2 96 48 86.1
Spacer with bracket
Dual residual pressure release valve with soft start-up
function (-X555/X585)
IN
a b
d
Model a
VP544-5DZ1-03-X555
33.9
VP544-5DZ1-03-X585
VP744-5DZ1-04-X555
34.4
VP744-5DZ1-04-X585
H
F
A
(Spacer width)
E F G H J
35 14 7 19 4
40 18 9 26 5
OUT
c
b c d Note
AW30-03G-B
57.2 129.2 254.2 Y300T-A
E300-03-A
AW40-04G-B
75.2 160.2 304.2 Y400T-A
E400-04-A
K
41
50
