SMC Networks VP Series Manual page 26

VG342-X87
Dimensions
VG342(R)-5DZ-10„-S1„-X87
Safety limit switch
Made by
Rockwell Automation
Safety limit switch
(made by Rockwell Automation)
Part number: 440P-CDPB03R6
Applicable cable O.D.
Ø 4.5 to Ø 7
37.5
1"
[1(P) port]
25
Port size: 1/8" (Without check valve)
Applicable tube O.D.: Ø 8, Ø 5/16" (With check valve)
(External pilot port)
Vent port
Should be normally open.
3 x Ø 8.5
(Mounting hole)
3
N
2
2 x 1" [3(R) port] 30
Should be normally open.
Channel 2 Channel 1
A
M12 x 1
(75)
3
1
73 73
75 43.5
160.5
220.5
230.5
75 75.3
Dual Residual Pressure Release Valve (-X87)
64.5
34
Pg9
(13.4)
(76.2)
38 37.5
30 (5) 77
View A
M12 connector
Pin
number
(Max. 3)
(27.7)
1"
[2(A) port]
