Temperature increasing
indicator
Constant temperature
indicator
Temperature decreasing
indicator
Timer indicator
Vibration speed indicator
Button explanation
Temperature set up buttons
Temp
Press
Temp
Keep pressing
Vibration time set up buttons
Time
Press
Time
Keep pressing
Vibration speed set up buttons
Speed
Speed
Press
Instant spot vibration button
Short
Press it to start spot vibration. The running speed is the highest vibration speed.
Prog
It is also a function button for temperature calibration.
Start/Stop button
Start
Stop
Press this button to start or stop the mixing of the device (valid for only mixing).
8.0 Operation Guide
8.1 Before turning on power
Check and confirm the following items first
Unit is on stable and level surface
The voltage is comply with the specification (see Section 5)
The power plug is tightly plugged into the outlet
The ground and module connection are reliable
8.2 Set up of temperature, vibration time, and vibration speed
Approximately 5 seconds after the power is turned on, the
monitor will display a temperature of 28.5°C, which is the instant
temperature of the module.
The display of TEMP 100.0 is the set up temperature of last run, the
display of TIME 80:00 is the set up vibration time of last run, and the
display of SPEED 1000 is the vibration speed of last run.
At same time, the device will automatically heat or cool, to achieve
the setting temp. point.
If the display is abnormal when the power is turned on, please shut down immediately and contact
the supplier.
or
to adjust the value ant set the requested temperature.
or
may help to speed up the setting time.
or
to adjust the value and set the requested vibration time.
or
may help to speed up the setting time.
or
to adjust the value and set the requested vibration speed.
Actual temperature
Set temperature
Actual vibration time
Set vibration time
Actual vibration speed
Set vibration speed
TEMP
TIME
SPEED
TEMP
TIME
SPEED
Instruction Manual
|
5
TEMP
