PW3336
PW3336-01, PW3336-02, PW3336-03
PW3337
PW3337-01, PW3337-02, PW3337-03
POWER METER
Measurement Guide
June 2013 Edition 1 Printed in Japan
PW3336A984-00 13-06H
Part names
Switches the display channel
Switches display parameters.
(when in the shift state,
changes the rectifier).
Displays measured values
and settings.
Switches the voltage range.
Switches the current range.
1. Connecting the instrument
Before connecting the instrument, read "Operating Precautions" in
Example 1: 1P2W
the Instruction Manual carefully.
Inverter
Power supply
Thank you for purchasing the HIOKI PW3336, PW3336-01, PW3336-02,
PW3336-03, PW3337, PW3337-01, PW3337-02, or PW3337-03 Power
Meter. This Measurement Guide introduces basic measurement methods
to individuals using the instrument for the first time. Be sure to review the
Instruction Manual before using the instrument.
HRM: switches to the harmonic display.
START/STOP: Starts and stops integration; resets integrated values.
HOLD: Switches between the hold, maximum value, and minimum
value displays.
SHIFT: Press to access functions shown in blue.
Warning display lamps
(for each channel)
Status display lamps
(for each channel)
Function settings
POWER switch
Switches the voltage and current
range channel (applies to both
voltage and current ranges).
Wiring diagram
Example 2: 3V3A
Inverter
Power
supply
Wiring diagram
CH(3)
2. Turning on the instrument
Do not activate input to the instrument before it has been turned on.
1
Connect the power cord.
3. Selecting the wiring mode
Display
Description
Allows you to measure three 1-phase/2-
1P2W×3
wire circuits. (PW336: Allows you to
(PW3336: 1P2W×2)
measure two such circuits.)
Measures a 1-phase/3-wire circuit with
1P3W&1P2W
CH1 and CH2. The PW3337 can simul-
(PW336: 1P3W only)
taneously measure a 1-phase/2-wire
circuit with CH3.
Measures a 3-phase/3-wire circuit with
CH1 and CH2 and measures active
3P3W&1P2W
power
(PW336: 3P3W only)
method. The PW3337 can simultane-
CH(3)
ously measure a 1-phase/2-wire circuit
with CH3.
CH(2)
CH(1)
Display
Description
Measures a 3-phase/3-wire circuit with CH1 and CH2 and
measures active power using the two-power-meter
3P3W2M
method. Calculates line voltage and phase current, which
are not actually measured, using vector calculations and
displays the result as the CH3 voltage and current.
Measures a 3-phase/3-wire circuit with connections for all
3V3A
line voltages and phase currents and measures the
active power using the two-power-meter method.
Measures a 3-phase/3-wire circuit. Uses the same con-
using
the
two-power-meter
nections as the 3V3A wiring mode but converts line volt-
3P3W3M
ages into phase voltages by means of vector calculations
and displays the results.
3P4W
Measures a 3-phase/4-wire circuit.
Motor
2
Turn on the POWER switch.
: Power ON
Press
to select the wiring mode.
