Summary of Contents for Chauvet SX Abyss
-
Page 1: User Manual
SX Abyss™ Snapshot Ok on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave 115V/230V Switch Replaceable Fuse User Serviceable Duty Cycle USER MANUAL Chauvet, 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
OUNTING Orientation ... 7 Rigging ... 7 4. OPERATING INSTRUCTIONS... 7 ... 8 ENERAL ROUBLESHOOTING ... 9 ECHNICAL UPPORT 5. APPENDIX... 9 ... 9 ENERAL AINTENANCE ... 9 ETURNS ROCEDURE ...10 LAIMS ...10 ECHNICAL PECIFICATIONS SX Abyss User Manual 2006-12-11/15:07... -
Page 3: Before You Begin
1. B EFORE What is included 1 x SX Abyss™ ELC3 24V 250W Lamp Warranty Card User Manual Unpacking Instructions Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition. Notify the shipper immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling. -
Page 4: Safety Instructions
There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929-1115. Duty Cycle This fixture has a 15/15 duty cycle, meaning it can be run for fifteen minutes, and then must be left off for 15 minutes before it is turned on again. -
Page 5: Introduction
4 constantly changing dichroic colors Stop effect on a color Adjustable ripple speed Fan cooled Product Overview Hanging Bracket Focusing Lens Effect Speed Knob Color Rotation Switch Lamp Access Thumbscrew SX Abyss User Manual Fuse Power Cord Lamp Access Thumbscrew 2006-12-11/15:07... -
Page 6: Setup
Hold the new lamp with a lint-free c Insert lamp into socket. Slide the lamp down past the springs until it stops. Insert lamp housing into the fixture. Tighten both thumbscrews SX Abyss User Manual Figure A loth. Figure B Figure C 2006-12-11/15:07... -
Page 7: Fuse Replacement
Use the color rotate switch to enable or disable color rotation (up = rotation enabled; down = disabled). Turn the focusing lens to focus the beam onto your projection surface. SX Abyss User Manual The fuse is located inside this compartment. -
Page 8: General Troubleshooting
If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support at the location on the next page. -
Page 9: Technical Support
Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 10: Claims
Fuse... 6.3A 250V Power Consumption ...276W Max Inrush Power ... 348W LIGHT SOURCE Lamp...ELC3 24V 250W Lamp PHOTO OPTIC Beam Angle ... 44° THERMAL Maximum ambient temperature...95°F (35°C) ORDERING INFORMATION SX-Abyss...SX-ABYSS WARRANTY INFORMATION Warranty ... 1-year limited warranty SX Abyss Manual 2006-12-11/15:07...
