Summary of Contents for Chauvet TFX-UVLED
- Page 1 LED Shadow™ TFX-UVLED USER MANUAL CHAUVET, 3000 N 29 Ct, Hollywood, FL 33020 U.S.A (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com 2006-10-11 12:19...
-
Page 2: Table Of Contents
UPPORT ©CHAUVET, 2006, All Rights Reserved Information and specifications in this User Manual are subject to change without notice. CHAUVET assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. TFX-UVLED User Manual ... 9 ... -
Page 3: Before You Begin
World Wide Web TFX-UVLED User Manual Save the carton and all packing If you should require sending any items back to CHAUVET, call CHAUVET for a (RMA) Return Merchandise Authorization number. The factory will not allow any shipments without an RMA. -
Page 4: Important Safety Information
If you have any questions about how to operate the fixture safely, please contact CHAUVET. P r o t e c t i o n a g a i n s t E l e c t r i c S h o c k •... -
Page 5: Introduction
CONTROL MODES & OPTIONS (Rows) For a detailed view of DMX values turn to the Appendix section in this manual. Control mode parameters are set by DMX values in Channel # 1. TFX-UVLED User Manual Intensity 000~029 0% ~ 100%... -
Page 6: Product Overview
DIP-switches Power Link Out DMX Addressing IEC Plug for AC Input & Fuse Compartment Flush Mounting Bracket LED Front Panel TFX-UVLED User Manual Hanging Yoke Audio Sensitivity Rotary knob DMX Output Red LED: Power Indicator Blue LED: Signal Indicator Introduction... -
Page 7: Setup
(2) Flush Mount Brackets for flush mounting to flat surfaces. You must supply your own clamp and make sure the clamp is capable of supporting the weight of this fixture. You can order C-clamps from any CHAUVET dealer or distributor. -
Page 8: Fixture Linking
Maximum recommended number of fixtures on a serial data link: 32 fixtures Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 9: 3-Pin To 5-Pin Conversion Chart
TFX-UVLED User Manual If you use a controller with a 5 pin DMX output connector, you will need to use a 5 pin to 3 pin adapter. CHAUVET Model No: DMX5M. The chart below details a proper cable conversion: IN TO... -
Page 10: Operating Instructions
“Master/Slave” configuration. Single-Fixture Mode The TFX-UVLED can be set to operate independently of other fixtures or a DMX controller in either a sound-active or automatic mode. A serial data-link is not necessary for this mode of operation and it is recommended that no connection to other fixtures be made at all. -
Page 11: Dmx Control Mode
DMX Control Mode The TFX-UVLED can be operated from a DMX controller. This control mode environment gives the user the greatest flexibility when it comes to customizing or creating a show by enabling the control of each individual trait of the fixture and each fixture independently. -
Page 12: Appendix
XLR male to female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’) Returns Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. -
Page 13: Binary & Dmx Dip-Switch Addressing
Total = 24 Resolving address using simple math. Address 233 TFX-UVLED User Manual 9 10 9 10 233 – (128) = 105, Turn ON Dip # 8 105 – (64) = 41, Turn ON Dip # 7 41 – (32) = 9, Turn ON Dip # 6 9 –... -
Page 14: Binary Addressing Quick Reference Chart
Binary Addressing Quick Reference Chart DMX & Binary Address Quick Reference Chart DMX DIP-SWITCH SET #9 0=OFF 1=ON X=OFF or ON DIP-switch Position DMX Address TFX-UVLED User Manual DIP-switch Position Appendix 2006-10-11 12:19... -
Page 15: Dmx Channel Values
Channel Value 029 Dimmer Mode 059 Program 1 089 Program 2 119 Program 3 149 Program 4 179 Program 5 209 Program 6 255 Sound TFX-UVLED User Manual Function Ch 2 Ch 3 Flash Speed 100% Intensity Speed 100% Slow... -
Page 16: Technical Specifications
Data output ... locking 3-pin XLR female socket Data pin configuration ...pin 1 shield, pin 2 (-), pin 3 (+) Protocols... DMX-512 USITT DMX Channels ...3 ORDERING INFORMATION LED Shadow™ ...TFX-UVLED Technical Support Address: Service Dept. 3000 N 29th Ct, Hollywood, FL 33020 (U.S.A.) Support (Email): tech@chauvetlighting.com...
