Summary of Contents for Chauvet Q-Spot 160-LED
- Page 1 User Manual...
- Page 2 Copyright Notice CHAUVET® owns the content of this user manual in its entirety, including but not limited to pictures, logos, trademarks, and resources. © Copyright 2010 CHAUVET®. All rights reserved Electronically published by CHAUVET®...
-
Page 3: Table Of Contents
DMX Values ... 14 Basic Mode ... 14 Advanced Mode ... 15 5. Technical Information ...16 General Maintenance ... 16 Photometrics ... 16 Troubleshooting Guide ... 17 Returns Procedure ... 18 Q-Spot™ 160-LED User Manual Rev. 01b Table of Contents... - Page 4 Table of Contents Claims ... 18 Contact Us ... 18 Technical Specifications... 19 Q-Spot™ 160-LED User Manual Rev. 01b...
-
Page 5: Before You Begin
“COLORado™ UM” MENU > Settings Icon Meaning The term “DMX” used throughout this document refers to the USITT DMX512-A transmission protocol. Q-Spot™ 160-LED User Manual Rev. 01b One Q-Spot™ 160-LED Two mounting brackets One power cord Three extra gobos Warranty Card... -
Page 6: Safety Notes
Operation • • • In the unlikely event that your CHAUVET® product may require service, please contact CHAUVET® Technical Support. Expected LED LEDs gradually decline in brightness over time, mostly because of heat. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular optimum Lifespan conditions. -
Page 7: Introduction
The Q-Spot™ 160 LED has two DMX modes, Basic (9 channels) and Advanced (12 channels). The table below shows the functions assigned to each channel in these Summary DMX modes. DMX Channel Q-Spot™ 160-LED User Manual Rev. 01b 9 or 12-channel DMX LED moving yoke Pan: 540º Tilt: 270º Color Wheel... -
Page 8: Product Overview
Introduction Product Overview DMX In DMX Out Power Input/Fuse holder On/Off Switch NOTE: Dimension in inches rounded to the nearest decimal digit Gobo cover Control Panel Q-Spot™ 160-LED User Manual Rev. 01b... -
Page 9: Setup
This product has an auto-ranging power supply that can work with an input voltage range of 100~240 VAC, 50/60 Hz. Make sure that you are connecting the Q-Spot™ 160-LED to the proper voltage, as per the specifications in this guide, the product’s manual or on the product’s sticker. -
Page 10: Dmx Linking
Setup DMX Linking You may link any Q-Spot™ 160-LED fixture to a DMX controller using a standard DMX serial connection. If using other DMX compatible fixtures with a Q-Spot™ 160-LED fixture, it is possible to control them individually with a single DMX controller. -
Page 11: Gobo Wheel
Gobo Wheel The Q-Spot™ 160-LED comes equipped with a gobo wheel featuring seven rotating and replaceable (slot-n-lock system) gobos. The gobo wheel has an eighth position with no gobo (open). Gobo Wheel Diagram Gobo The Q-Spot™ 160-LED features a gobo wheel that holds seven interchangeable, slot-n- lock gobos. -
Page 12: Mounting
• Procedure You can mount the Q-Spot™ 160-LED on a flat, rigid surface or hang it from a truss. This fixture includes two mounting brackets for overhead mounting. You can attach a rigging clamp to . You must supply your own “C” or “O” clamps as well as your safety cable, making sure that they are capable of supporting the weight of this fixture. -
Page 13: Operation
<ENTER> <DOWN> Control Options You can set the Q-Spot™ 160-LED start address in the 001~512 DMX range. This allows for the control of up to 42 fixtures in the 12-channel Advanced DMX mode. Programming Carry out all the programming procedures indicated below from the control panel. Refer to the Menu Map on page 13 to learn how the menu options relate to each other. -
Page 14: Master/Slave
No (move-in-black will stay active for as long as the Control channel remains between 020~039) or Yes (move-in-black will activate permanently if the Control channel remains between 020~039 for 3 seconds. Continues on the next page Q-Spot™ 160-LED User Manual Rev. 01b... -
Page 15: Movement Ranges
3) Reverse the direction of the TILT movement (270º~0). 4) Change the way the COLOR wheel rotates. 5) Activate/disable the movement modifications. Q-Spot™ 160-LED User Manual Rev. 01b Continued from previous page a) Select P/Start. b) Select a value (000~255). -
Page 16: Edit Custom
Use = Yes Step 4: Time = 0 Use = Yes Step 5: Time = 0 Use = No Step 255 Time = 0 Use = No (This step creates a loop) (Unused steps) Q-Spot™ 160-LED User Manual Rev. 01b... -
Page 17: Menu Map
Gobo 5-Edit Gobo_Rot Prism Dimmer Strobe Time 6-Default Default Q-Spot™ 160-LED User Manual Rev. 01b Level Description 001~512 Sets the DMX starting address Yes/No Resets the fixture to the “home” position DMX-512 Sets the fixture to DMX mode Auto 1... -
Page 18: Dmx Values
Auto 2 100 119 Sound 1 120 139 Sound 2 140 159 Custom 160 179 Test 180 199 No function 200 219 Reset 220 255 No function Q-Spot™ 160-LED User Manual Rev. 01b... -
Page 19: Advanced Mode
Dimmer Strobe Control (Hold each of these for 3 s to trigger function) Q-Spot™ 160-LED User Manual Rev. 01b Value Percent/Setting 000 255 0~540° 000 255 Fine pan adjustment 000 255 0~270° 000 255 Fine tilt adjustment 000 ... -
Page 20: Technical Information
Dust build up reduces light output performance and can cause overheating. This can lead to reduced light source life and increased mechanical wear. CHAUVET® recommends cleaning the fixture’s external optics with a soft cloth using normal glass cleaning fluid. To clean a fixture, follow the recommendations below: •... -
Page 21: Troubleshooting Guide
• Too many fixtures • Interference from AC wires If you still experience technical problems after trying the above solutions, contact CHAUVET® Technical Support. Q-Spot™ 160-LED User Manual Rev. 01b Technical Information Action(s) • Clean optic path • Check dimmer setting from control panel •... -
Page 22: Returns Procedure
The user must clearly label the package with a Return Merchandise Authorization Number (RMA #). CHAUVET® will refuse any product returned without an RMA #. DO NOT write the RMA # directly on the box. Instead, write it on a properly affixed label. -
Page 23: Technical Specifications
