Yetter TITAN Series Operator's Manual
Hide thumbs
Also See for TITAN Series:
- Owner's manual (24 pages) ,
- Operator's manual (24 pages) ,
- Owner's manual (20 pages)
Advertisement
Quick Links
Advertisement
Related Manuals for Yetter TITAN Series
Summary of Contents for Yetter TITAN Series
- Page 1 TITAN SERIES 2967-013B /2967-014B NARROW ROW SHORT U.N.T. ™ RESIDUE MANAGER OPERATOR’S MANUAL PART IDENTIFICATION 2565-748_REV_J 07/2021 YETTER MANUFACTURING CO. FOUNDED 1930 Colchester, IL 62326-0358 Toll free: 800/447-5777 309/776-3222 (Fax) Website: www.yetterco.com E-mail: info@yetterco.com...
- Page 2 The warranty does not obligate Yetter Manufacturing to bear the cost of labor in replacement of parts. It is the policy of the Company to make improvements without incurring obligations to add them to any unit sold prior.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION ................4 BOLT TORQUE ..................3 INSTALLATION INSTRUCTIONS ............5-6 OPERATION ................... 7-9 PART IDENTIFICATION ..............10-15 BOLT TORQUE Important: Over tightening hardware can cause as much damage as under tightening. Tightening hardware beyond the recommended range can reduce it shock load capacity. -
Page 4: Safety Information
SAFETY INFORMATION BE ALERT! YOUR SAFETY IS INVOLVED It is the responsibility of the owner, operator, or supervisor to know and instruct everyone using this machine at the time of initial assignment and at least annually thereafter, of the proper operation, precautions, and work hazard which exist in the operation of the machine in accordance with OSHA regulations. -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS 2967-013A STEP 1. Attach the Residue Manager Assembly to the planter unit using 3) ½” bolts and lock nuts. INSERT 1/2” X 1” BOLT THROUGH THE LOWER RIGHT HOLE IN ROW UNIT FROM REAR AND THREAD INTO THE MOUNT BRACKET INSERT 1/2”... - Page 6 INSTALLATION INSTRUCTIONS STEP 2. Choose the hole in which to attach the R.M. wheel assemblies. Attach the R.M. wheel/hub assemblies to the combo arm using 5/8” lock washers and hex nuts. Torque to 150 ft. lbs. Step 3: ONLY FOR 2967-014B MOUNTING ON CNH RU Attach the up-stop to the planter row unit parallel arms using the provided hardware.
-
Page 7: Operation
OPERATION CAUTION: Where rocks are present the residue manager should be set in the “float” position, not locked down. Adjust the residue manager to move crop residue aside and not move any soil. Adjustments to the residue manager may have to be made when changing field conditions and type and amount of residue. Use the handle for leverage when changing depth settings. - Page 8 IMPORTANT: failure to properly set the planter frame height and levelness can result in less than successful operation of the planter and the Yetter product and may result in damaged equipment. All operators should read and thoroughly understand the instructions given prior to using the Yetter product.
- Page 9 PLANTER ADJUSTMENT...
-
Page 10: Part Identification
PART IDENTIFICATION 2967-013B... - Page 11 PART IDENTIFICATION 2967-013A-SUB ASSEMBLY...
- Page 12 PART IDENTIFICATION 2967-014B...
- Page 13 PARTS IDENTIFICATION 2965-135 UP-STOP KIT ITEM PART # DESCRIPTION 2502-244 3/8-16 x 1-1/4 HHCS GR 5 2960-223 UP-STOP 2520-255 3/8-16 HEX LOCK NUT 2526-253 3/8 SAE FLATWASHER...
- Page 14 PARTS IDENTIFICATION 2966-140-ST-FW RIGHT HAND SHARK TOOTH WHEEL ASSEMBLY PARTS IDENTIFICATION 2966-140-BW-FW RIGHT HAND BEVEL WHEEL ASSEMBLY...
- Page 15 PARTS IDENTIFICATION 2966-141-FW LEFT HAND SPOKE WHEEL ASSEMBLY...
- Page 16 2565-748_REV_J ● 07/2021...
