Yetter TITAN 2967-008A Operators Manual And Parts Identification

Residue manager for cnh planter units
Hide thumbs Also See for TITAN 2967-008A:

Advertisement

Quick Links

YETTER MANUFACTURING CO.
FOUNDED 1930
Colchester, IL 62326-0358
Toll free: 800/447-5777
309/776-3222 (Fax)
Website:
www.yetterco.com
E-mail:
info@yetterco.com
TITAN
RESIDUE MANAGER
FOR
CNH PLANTER UNITS
2967-008A
OPERATOR'S MANUAL
PART IDENTIFICATION
2565-695_REV_M • 08/2024

Advertisement

loading
Need help?

Need help?

Do you have a question about the TITAN 2967-008A and is the answer not in the manual?

Questions and answers

Summary of Contents for Yetter TITAN 2967-008A

  • Page 1 TITAN RESIDUE MANAGER CNH PLANTER UNITS 2967-008A OPERATOR’S MANUAL PART IDENTIFICATION 2565-695_REV_M • 08/2024 YETTER MANUFACTURING CO. FOUNDED 1930 Colchester, IL 62326-0358 Toll free: 800/447-5777 309/776-3222 (Fax) Website: www.yetterco.com E-mail: info@yetterco.com...
  • Page 2 It is the user’s responsibility to deliver his machine to the Yetter dealer who sold him the product for service or replacement of defective parts, which are covered by the warranty policy.
  • Page 3 SAFETY PRECAUTIONS A brief description of signal words that may be used in this manual: DANGER: Indicates an imminently hazardous situation which, if not avoided “will” result in death or serious injury. This signal word is to be limited to the most extreme situations. WARNING: Indicates a potentially hazardous situation which, if not avoided, “could”...
  • Page 4 TABLE OF CONTENTS Introduction…………………………………………………………..pg.2 Warranty……………………………….……………………………..pg.2 Safety Information…………………………………………………...pg.2-3 Table of Contents……………………………………………………pg.4 Bolt Torque…………………………………………………………...pg.4 Use Guide/Troubleshooting………………………………………...pg.5-6 Installation Instruction……..…….………………..…………..…….pg.7-9 Operation……………………………...……………………………..pg.10 Parts Identification………………………………..………….……...pg.11-15 BOLT TORQUE Mounting bolts and hardware Before operating the Titan Residue Manager for the first time, check to be sure that all hardware is tight. Check all hardware again after approximately 50 hours of operation and at the beginning of each planting season.
  • Page 5 OPERATION GUIDE/TROUBLESHOOTING NOTICE: Please check the amount of travel that the planter row unit has before going to the field to plant. NOTE: The recommended height of a level planter toolbar frame is 20”-22”. Always visually check seed spacing and depth-calibrate your equipment if necessary. Figure A.
  • Page 6 OPERATION GUIDE/TROUBLESHOOTING NOTICE: Please check the amount of travel that the planter row unit has before going to the field to plant. NOTICE: Check the drive shaft clearance with the residue manager wheels. If the residue manager wheels can make contact with the drive shaft, the drive shaft could be damaged.
  • Page 7 INSTALLATION INSTRUCTIONS 2967-008 - TITAN RESIDUE MANAGER WITH A 2960 COULTER  BLADE REMOVED FOR CLARITY STEP 1. Attach the 2966-253 mount bracket to the coulter bracket using 2) ½” x 1-3/4” bolt and ½” lock nuts.
  • Page 8 INSTALLATION INSTRUCTIONS Attach the 2966-252 combo arm to the 2966-253 mount bracket using the 5/8” bolts, STEP 2. flat washers, bushings, 2967-623 adjustment plate and 5/8” lock nuts. Also, install the ½” x 2” bolt, 2967-622 spacer, ½” lock nut, 2984-326 pin and 2570-446 bowtie cotter on the 2967-623 adjustment plate.
  • Page 9 INSTALLATION INSTRUCTIONS STEP 3. Choose the mounting hole in which to attach the R.M. wheels. Attach the R.M. wheel/hub assemblies to the 2966-252 Combo Arm using the 5/8” hex nuts. Adjust the bearing shield (optional) to top dead center, rotate slightly forward. Torque to 180 ft./lbs. MOUNTING CONFIGURATIONS FOR RESIDUE WHEELS 2967-404 –...
  • Page 10 OPERATION NOTICE: Where rocks are present the residue manager should be set in the “float” position, not locked down. Adjust the residue manager to move crop residue aside and not move any soil. Adjustments to the residue manager may have to be made when changing field conditions and type and amount of residue. Use the handle for leverage when changing depth settings.
  • Page 11 PARTS IDENTIFICATION 2967-008A-ST-FW...
  • Page 12 PARTS IDENTIFICATION 2966-140-ST-FW 2966-140-ST-PFW 2966-140-STF-PFW RIGHT HAND SHARKTOOTH FINGER WHEEL ASSEMBLY...
  • Page 13 PARTS IDENTIFICATION 2966-140-BW-FW 2966-141-FW...
  • Page 15 ITEM PART NO DESCRIPTION 2502-221 5/16-18 X 1 HHFS GRADE 5 2502-222 5/16-18 X 1-1/4 HHFS GRADE 5 2502-225 5/16-18 X 1-1/2 HHFS GRADE 5 2940-560 SET SCREW 2965-500 HUB ASSEMBLY 1.406 SPINDLE 2965-501 HUB ASSEMBLY 2.406 SPINDLE 2965-502 HUB ASSEMBLY 1.157 SPINDLE ITEM PART NO DESCRIPTION...
  • Page 16 2565-695_REV_M  08/2024...
