Section 5 - Hydraulic; Hydraulic Component List - Hyd-Mech S-20 A Manual

The S20-A, S23-A hydraulic system does not require any special work on a new machine before its start up. The hydrau-
ensure proper operation upon initial start up.

HYDRAULIC COMPONENT LIST

ITEM BALLOON
NUMBER
1
2
3
4
5
6 8b
7 8a
8 9a, 9b
9 7a, 7b
10 10
11 2
12 3
13
14
15
16 5
17 1.4
18
19
20 11

SECTION 5 - HYDRAULIC

PART
QTY
NUMBER
800006-S23A
1 800003-S22A
2 800000
1 800045
0(2) 800001
1 DDF1-0-00A
1 362748
1 362748
2 362749
2 362747
1 362757
1 362752
1 362753
1 362756
0(1) 362758
0(1) 363145
0(1) 360745
1 362758
0(2) 363205
0(4) 363220
1 362751
Hydraulic Power Pack
DESCRIPTION
Head Cylinder
Vise Cylinder
Shuttle Cylinder
Bundling Cylinder (Option)
Ddf Valve
Dcv3P-Ab-T, Head Control Valve
Dcv3P-Ab-T, Shuttle Control Valve
Dcv3P-Ab-C , Vise Valve
Dpch-1, Double Pilot Check Valve
Pv2P-A-C , Chb-20 , Cushion Valve Assembly
Pump
Motor 240 Vac, 1Hp, Three Phase
Filter Element
Variable Vise Pressure Block (Vvp Option)
Pressure Reducing Valve (Vvp Option)
Pressure Gauge (Vvp Option)
Oil Side Gauge
Ball Valve (Bundling Option)
Flow Control Valve (Bundling Option)
Valve, Pressure Reducing Ng 6, Pilot Operated
5.1
