SANTOS SAS :
SANTOS: Operation and maintenance manual
140-150 AVENUE ROGER SALENGRO
69120 VAULX-EN-VELIN (LYON) - FRANCE
PHONE. 33 (0) 472 37 35 29 - FAX 33 (0) 478 26 58 21
E-Mail:santos@santos.fr
OPERATION AND MAINTENANCE MANUAL
!
Coffee grinders - Fruit juicers - Mixers - Blenders - Drinks dispensers - Planetary mixers
Cheese graters - Ice crushers - Mincers - Vegetable slicers – Dough mixer
Moulins à café – Presse-fruits - Mixers - Blenders – Distributeurs de boissons – Batteurs
mélangeurs - Pétrin – Râpes à fromage – Broyeurs à glaçons – Hache-viande – Coupe-légumes
98143 EN 3.6 - 09 2021
TO
www.santos.fr
IMPORTANT: Documents contained in this manual and to be
kept:
• "EC" DECLARATION OF CONFORMITY
• WARRANTY CERTIFICATE
TRANSLATION OF THE ORIGINAL VERSION
REGISTERED DESIGN - FRANCE AND INTERNATIONAL
INTERNATIONALY PATENTED MODELS
1 / 17
SHOP COFFEE GRINDER No. 43
www.santos.fr
Advertisement
Table of Contents
Related Manuals for Santos 43
Summary of Contents for Santos 43
- Page 1 69120 VAULX-EN-VELIN (LYON) - FRANCE PHONE. 33 (0) 472 37 35 29 - FAX 33 (0) 478 26 58 21 E-Mail:santos@santos.fr www.santos.fr SHOP COFFEE GRINDER No. 43 OPERATION AND MAINTENANCE MANUAL IMPORTANT: Documents contained in this manual and to be kept: •...
-
Page 2: Table Of Contents
SANTOS: Operation and maintenance manual CONTENTS "EC" DECLARATION OF CONFORMITY ................3 SAFETY RULES ......................... 4 INSTALLATION - HANDLING ..................4 CONTRAINDICATIONS: ....................4 ELECTRICAL CONNECTION: ..................5 END-OF-LIFE PRODUCT RECYCLING ................5 YOUR COFFEE GRINDER ....................6 USING THE APPLIANCE ....................6 TURNING THE APPLIANCE ON AND OFF .............. -
Page 3: Ec" Declaration Of Conformity
SANTOS: Operation and maintenance manual "EC" DECLARATION OF CONFORMITY THE MANUFACTURER: SANTOS SAS - 140-150, Av. 69120 VAULX-EN-VELIN (LYON) - FRANCE Declares that the appliance destined to be placed on the professional market, hereinafter referred to as: Description: SHOP COFFEE GRINDER... -
Page 4: Safety Rules
8. Never use the appliance with a damaged power cable. It must be replaced by an authorized SANTOS dealer or the Santos company, or by persons of similar qualification, to avoid danger. 9. Unplug the appliance before any intervention on it: Cleaning, maintenance or servicing. -
Page 5: Electrical Connection
➢ on the manufacturer’s plate on the bottom of the appliance. ➢ or on the nameplate on the last page of this manual. • If the power cable is damaged, it must be replaced by a Santos authorized dealer or the Santos company, or similarly qualified persons, to avoid danger. -
Page 6: Your Coffee Grinder
SANTOS: Operation and maintenance manual YOUR COFFEE GRINDER • The coffee grinder is intended for coffee shops, communities and coffee roasters, • The grinder delivers ground coffee in 250 g, 500 g and 1 kg bags. • The appliance consists of a cast aluminium frame and sheet metal. The plastic bean hopper has a capacity of 1.7 kg. -
Page 7: Replacing The Grinding Discs
Marked on the bottom of the appliance. REPLACING THE GRINDING DISCS IMPORTANT : Always replace the 2 grinding discs (17) at the same time. (Use SANTOS grinding disc sets ref: 00001B or 00001 depending on model). Grinding disc set selection chart: Models 43V1... -
Page 8: Adjusting The Minimum Grinding Disc Spacing
Accurately identify the cause of the appliance stoppage. In all cases: If the problem persists, switch off the power (unplug the mains plug) and call in a person from the maintenance department or contact a Santos authorized dealer. The appliance does not start: •... -
Page 9: The Appliance Stops After A Few Minutes Of Operation
SANTOS: Operation and maintenance manual • Press the overcurrent protector button (14) once • Check that there are no foreign objects caught between the grinding discs. • Check the electrical components by replacing them one after the other The appliance stops after a few minutes of operation: •... -
Page 10: Technical Features Of The Appliance
SANTOS: Operation and maintenance manual TECHNICAL FEATURES OF THE APPLIANCE ELECTRICAL SPECIFICATIONS Model 43V4 43V1 Supply voltage 220-240 220-240 100-120 Frequency (Hz) 50/60 Motor: Absorbed power Speed (rpm) 1500 1800 1500/1800 Set of Santos grinding discs, Ø63 mm 00001B 00001... -
Page 11: Electrical Diagram
SANTOS: Operation and maintenance manual Electrical diagram Electrical diagram - 110-120V 50/60Hz Blue Black Capacitor Yellow White White Brown Black Starting relay Brown Overcurrent Brown protector f(t) > On/off Black White White White Green / yellow 98143 EN 3.6 - 09 2021 11 / 17 www.santos.fr... -
Page 12: Wiring Diagram - 220-240V 50Hz
SANTOS: Operation and maintenance manual Electrical diagram - 220-240V 50Hz Brown Capacitor White White Starting relay Brown Brown Black Overcurrent protector On/off f(t) > White White Green/yellow 98143 EN 3.6 - 09 2021 12 / 17 www.santos.fr... - Page 13 SANTOS: Operation and maintenance manual Electrical diagram - 220-240V 60Hz Blue Capacitor Yellow White White Brown Black Starting relay Brown Overcurrent Brown protector f(t) > On/off Black White White White Green / yellow 98143 EN 3.6 - 09 2021 13 / 17...
-
Page 14: Figures
SANTOS: Operation and maintenance manual Figures Fig. A 98143 EN 3.6 - 09 2021 14 / 17 www.santos.fr... - Page 15 SANTOS: Operation and maintenance manual 98143 EN 3.6 - 09 2021 15 / 17 www.santos.fr...
- Page 16 SANTOS: Operation and maintenance manual ITEM DESIGNATION Bean hopper cover Bean hopper Front top plate Adjustment index Knob locking screw Grind setting knob Index locking screw Bag clamp operating pull Bag clip strip Ground coffee outlet tube Base plate Non-slip feet...
-
Page 17: Warranty Certificate
Our warranty does not extend to the payment of penalties, to the repair of direct or indirect damages, and in particular to any loss of profits resulting from the non-conformity or defect of the products, SANTOS’s overall liability being limited to the selling price of the delivered product and the possible repair of defective products.
