ON-DEMAND ESPRESSO COFFEE GRINDER No. 59
OPERATION AND MAINTENANCE MANUAL
!
Coffee grinders - Fruit juicers - Mixers - Blenders - Drinks dispensers - Planetary mixers
Cheese graters - Ice crushers - Mincers - Vegetable slicers – Dough mixer
Coffee grinders - Fruit presses - Mixers - Blenders - Drink dispensers - Mixer-blenders - Dough mixer -
www.santos.fr
MANUEL D'UTILISATION ET D'ENTRETIEN
OPERATING AND SERVICING MANUAL
BENUTZUNGS- UND WARTUNGSANLEITUNG
MANUAL DE UTILIZACION Y DE MANTENIMIENTO
IMPORTANT: documents contained in this manual to be kept:
GEBRUIKS-EN-ONDERHOUDSHANDLEIDING
• "EC" DECLARATION OF CONFORMITY
• WARRANTY CERTIFICATE
Translation of the original version
Cheese graters - Ice crushers - Meat mincers - Vegetable cutters
REGISTERED DESIGN - FRANCE AND INTERNATIONAL
INTERNATIONALLY PATENTED MODELS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Santos 59
Summary of Contents for Santos 59
- Page 1 69120 VAULX-EN-VELIN (LYON) - FRANCE TEL. 33 (0) 472 37 35 29 - FAX 33 (0) 478 26 58 21 Email:santos@santos.fr www.santos.fr ON-DEMAND ESPRESSO COFFEE GRINDER No. 59 MANUEL D'UTILISATION ET D'ENTRETIEN OPERATION AND MAINTENANCE MANUAL OPERATING AND SERVICING MANUAL...
-
Page 2: Table Of Contents
SANTOS: Operating & Servicing Manual CONTENTS "EC/EU" DECLARATION OF CONFORMITY ..................3 SAFETY RULES4 INSTALLATION - HANDLING ........................4 RESTRICTIONS:............................4 ELECTRICAL CONNECTION: ........................5 USE ................................5 END-OF-LIFE PRODUCT RECYCLING ....................6 YOUR ON-DEMAND ESPRESSO COFFEE GRINDER NO. 596 USING THE APPLIANCE.......................... -
Page 3: Ec/Eu" Declaration Of Conformity
SANTOS: Operating & Servicing Manual "EC/EU" DECLARATION OF CONFORMITY THE MANUFACTURER: SANTOS SAS - 140-150, Av. Roger SALENGRO 69120 VAULX-EN-VELIN (LYON) FRANCE Declares that the appliance to be launched on the professional market, hereinafter: Designation: On-Demand espresso coffee grinder Type Number: is in compliance: •... -
Page 4: Safety Rules4
10. Do not use the appliance with a damaged power cord. It must be replaced either by an approved SANTOS dealer or the SANTOS company or by similarly qualified persons to avoid any hazards. 11. Use only original SANTOS-certified spare parts. -
Page 5: Electrical Connection
➢ either on the manufacturer's plate (16) under the appliance. ➢ or on the manufacturer's plate on the last page of this manual. • If the power cable (10) is damaged, it must be replaced by a SANTOS authorized dealer or the SANTOS company, or similarly qualified persons, to avoid danger. -
Page 6: End-Of-Life Product Recycling
YOUR ON-DEMAND ESPRESSO COFFEE GRINDER No. 59 • The On-demand espresso coffee grinder No. 59 is intended for bars, cafés, hotels, restaurants. It adapts to all espresso coffee machines. • The appliance consists of a grinding unit and a base made of aluminium, a bean hopper made of transparent plastic, an electronic system that integrates the dosing, dose counting, the burrs wear indicator. -
Page 7: Use
1. Turn the appliance on by turning the On/Off switch (11) to position "1" (the control panel screen (19) displays the SANTOS logo then the main screen) (fig. D). 2. Press the selection button (20, 21 or 22) that corresponds to your choice (1 coffee, 2 coffees or the "Pulse"... -
Page 8: Setting The Dose Of Ground Coffee (Timers)
090 for an espresso coffee. Grind setting (Mark of the graduated plate of the Nut (5)) Indicative values for one dose and for new SANTOS burrs The settings for the 2 selection buttons (20) and (21) are independent (fig. D). Single dose setting: 1. -
Page 9: Resetting To Factory Settings
SANTOS: Operating & Servicing Manual • Pressing selection button 2 (21), increases the value by one unit (0.01 seconds) 5. Pressing the "P" selection button 22), confirms the value displayed 6. Go back to the main screen (see the "General operations of screen settings"... -
Page 10: Customising The Main Screen
SANTOS: Operating & Servicing Manual • Simultaneously press selection buttons 1 and 2 (20 and 21), or • Do not press any button for 30 seconds Note: The motor is deactivated when the menu is activated. CUSTOMISING THE MAIN SCREEN Display or hide the Total counter on the main screen 1. -
Page 11: Information Concerning The Coffee Grinder
SANTOS: Operating & Servicing Manual part) INFORMATION CONCERNING THE COFFEE GRINDER View the Total counter 1. Enter the settings menu (see the "General operations of screen settings" part) 2. Select "Statistics" 3. Select "Total counter" 4. Press the "P" selection button (22) to exit 5. -
Page 12: Burrs Wear Indicator
SANTOS: Operating & Servicing Manual The "Pulse" function can be configured in the settings of the appliance. The latter can be used via the portafilter Microswitch (25) or via the "P" selection button (22) Operation via the portafilter Microswitch (25): (Portafilter mode) 1. -
Page 13: Main Screen Standby Mode
MAIN SCREEN STANDBY MODE Putting the screen into standby mode saves power. The standby screen continues to display the last mode used (yellow cursor) and the SANTOS logo, and decreases screen brightness. When the screen is in standby mode, the appliance remains active and ready to use. -
Page 14: Cleaning
SANTOS: Operating & Servicing Manual 4. Adjust the time o Pressing selection button 1 (20), increases the value by one unit (minimum value: 1 min) o Pressing selection button 2 (21), increases the value by one unit (maximum value: 20 min) 5. -
Page 15: Replacing Burrs
SANTOS: Operating & Servicing Manual Replacing burrs: IMPORTANT:always replace the 2 burrs (9) at the same time. Use SANTOS burrs: Refer to the table of the appliance's specifications to order the reference for the burrs set that corresponds to your appliance. -
Page 16: Troubleshooting Assistance
In any case, if the problem persists, switch off (unplug the power cord (10)) and call in maintenance service or contact an approved SANTOS dealer. If necessary, remember to close the shutter (6) of the bean hopper before removing the hopper. -
Page 17: The Appliance Stops Following An Overload
If the problem persists, switch off the power (unplug the mains plug (10)) and call in maintenance service or contact a Santos authorized dealer. The dose of ground coffee is not even • Check that there are coffee beans in the bean hopper. We recommend having at least 400g of coffee beans in the hopper. -
Page 18: Technical Specifications Of The Appliance
SANTOS: Operating & Servicing Manual TECHNICAL SPECIFICATIONS OF THE APPLIANCE TECHNICAL SPECIFICATIONS Model 59 59V4 59V1 Power voltage .(V) 220-240 220-240 100-120 Frequency (Hz) 50/60 Single-phase Motor: Power Absorbed power 1150 1150 Speed (rpm) 2850 at 50 Hz/ 3400 at 60Hz... - Page 19 SANTOS: Operating & Servicing Manual Electrical diagram 110-120V 50/60Hz and 220-240V 50/60Hz Black Black Motor PP (main phase) Blue PA (auxiliary Capacitor phase) White White Control panel Bundle White Control part lectronic board Brown Power part Violet Blue Portafilter Violet...
-
Page 20: Correlation Table
SANTOS: Operating & Servicing Manual Correlation table ITEM Designation Bean hopper cover Bean hopper Grind collector Base plate Grinding body Bean hopper shutter Indexing pin Burr support plate Burr Power cord plug. On/off switch Graduated plate Overcurrent protector Capacitor Ground coffee tamper... - Page 21 SANTOS: Operating & Servicing Manual Fig. A Fig. B Fig. C Fig. E Fig. D Fig. F Fig. G Fig. H 98159 EN 1.0 - 09 2023 21 / 23 www.santos.fr...
- Page 22 Fig. I Fig. J SANTOS: Operating & Servicing Manual Fixed burr Movable burr Fig. L Fig. K Fig. N Fig. M Fig. P Fig. O 98159 EN 1.0 - 09 2023 22 / 23 www.santos.fr...
-
Page 23: Certificat De Garantie
– tarif horaire – main-d’œuvre). Il peut être fourni un devis préalable. Les moulins à café non munis de meules originales SANTOS ne sont pas pris sous garantie. Les conditions de garantie, réparation, reconditionnement, des moulins à café espresso font l’objet d’une notice spécifique.
