Table 4-5 Xpico Wi-Fi Technical Specification - Lantronix xPico XPW100A003-01-B Integration Manual

Category
CPU, Memory
Firmware
WLAN Standards
Antenna Connector
Frequency Band
Channel Support
Modulation
Protocols Supported
Data Rates 802.11b
Data Rates 802.11g
Date Rates 802.11n
802.11b, CCK Mode
Average Output Power
802.11g, OFDM Mode
Average Output Power
802.11n, OFDM Mode
Average Output Power
802.11b
Average Output EVM
802.11g
Average Output EVM
802.11n
Average Output EVM
802.11b, PER <8%
RX Sensitivity @ 1Mbps
802.11b, PER <8%
RX Sensitivity @ 11Mbps
802.11g, PER <10%
RX Sensitivity @ 6Mbps
802.11g, PER <10%
RX Sensitivity @ 54Mbps
802.11n, PER <10%
RX Sensitivity @ MCS0
802.11n, PER <10%
RX Sensitivity @ MCS7
Serial Interface
Serial Line Formats
Modem Control
Flow Control
Programmable I/O
LEDs
xPico® Embedded Device Server Integration Guide

Table 4-5 xPico Wi-Fi Technical Specification

Description
Cortex M3 CPU, 1MB Flash, 128KB+4KB SRAM, Additional 1MB on
board Flash
Upgradeable via TFTP and serial port
802.11 b/g/n Wireless LAN with external antenna
U.FL connector for external antenna
2.400Ghz to 2.484Ghz
Channel 1 to Channel 14
DSSS, CCK, OFDM, BPSK, QPSK, 16QAM, 64QAM
ARP, UDP/IP, TCP/IP, Telnet, ICMP, SNMP, DHCP, BOOTP, TFTP,
Auto IP, SMTP, and HTTP
1, 2, 5.5, 11 Mbps
6, 9, 12, 18, 24, 36, 48, 54 Mbps
HT20 MCS0 (6.5Mbps) to HT20 MCS7 (65Mbps)
16.5 +/- 1.5dBm Typical @ 25C
15 +/- 1.5dBm, Typical @ 25C, 6Mbps
13 +/- 1.5dBm, Typical @ 25C, 54Mbps
14.5 +/- 1.5dBm, Typical @ 25C, MCS0
12 +/- 1.5dBm, Typical @ 25C, MCS7
IEEE Spec -10dBm
IEEE Spec, -5dB @ 6Mbps
IEEE Spec, -25dB @ 54Mbps
IEEE Spec, -5dB @ MCS0
IEEE Spec, -28dB @ MCS7
-93dBm Typical
-89dBm Min
-88dBm Typical
-84dBm Min
-87dBm Typical
-83dBm Min
-74dBm Typical
-70dBm Min
-87dBm Typical
-83dBm Min
-71dBm Typical
-67dBm Min
CMOS (Asynchronous) 3.3V-level signals
Rate is software selectable: 300 bps to 921600 bps
Data bits: 7 or 8 Stop bits: 1 or 2 Parity: odd, even, none
DTR/DCD, CTS, RTS <- Serial 1 only
Serial 1: XON/XOFF (software), CTS/RTS (hardware)
Serial 2: XON/XOFF (software)
8 PIO pins (software selectable), sink or source 4mA max.
WLAN Status, System Status logic level outputs
4: Specifications
42
