Table 4-3 Xpico Wi-Fi Recommended Operating Conditions - Lantronix xPico XPW100A003-01-B Integration Manual

Parameter
Supply Voltage
Supply Voltage Ripples
TX Power @ 16.5dBm, 802.11b, 11Mbps
TX Power @ 15dBm, 802.11g, 6Mbps
TX Power @ 13dBm, 802.11g, 54Mbps
TX Power @ 14.5dBm, 802.11n, MCS0
TX Power @ 12dBm, 802.11n, MCS7
RX Power @ 802.11b, 11Mbps
RX Power @ 802.11g, 54Mbps
RX Power @ 802.11n, MCS7
Power Management State 1 @ 25°C
Power Management State 1 @ +85°C
Power Management State 1 @ -40°C
Supply Reset Threshold
CPx Pull-ups/ Pull-downs
CPx, RX
Input Low Voltage
CPx, RX
Input High Voltage
CPx, TX Output Low Voltage
(I = 4 mA)
OL
CPx, TX Output High Voltage
(I = -4 mA)
OH
Reset Pin Low Voltage
Reset Pin High Voltage
Note 1. For xPico Wi-Fi 5V tolerant pins, in order to sustain a voltage higher than Vcc+0.3, the internal pull-
up/pull-down resistors must be disabled.
xPico® Embedded Device Server Integration Guide

Table 4-3 xPico Wi-Fi Recommended Operating Conditions

(1)
Symbol Min Typical
V 3.15 3.3
CC
V
CC_PP
I
330
CC
I 300
CC
I 255
CC
I 290
CC
I 230
CC
I 125
CC
I 125
CC
I 125
CC
I 6
CC
I 12
CC
I 5
CC
V
RST
R 30 40
PU
V -0.3
CP_IL
V 2
CP_IH
V
CP_OL
V 2.4
CP_OH
VRES_IL -0.3
VRES_IL
2
4: Specifications
Max Units
3.46 Vdc
2 %
mA
380
345 mA
295 mA
335 mA
265 mA
150 mA
150 mA
150 mA
μA
μA
μA
Vdc
50 Kohm
0.75 Vdc
5.5 Vdc
0.4 Vdc
Vdc
0.8 Vdc
Vcc+0.3 Vdc
40
