ESSENTIAL INDIVIDUAL COMPONENTS

IGNITION SWITCH

The ignition switch (1) is on the right side
below the steering.
"OFF" ( )
Position/Lock Open
"LOCK" Position
Key position
The engine can be started, Turn signal indicators,
Horn, Tail/Stop lamp and Fuel gauge will be
"ON" ( )
functional. Programmed FI malfunction indicator
lamp (MIL) illuminates.
Engine cannot be started and no electrical
"OFF" ( )
system will be functional.
"LOCK" Steering can be locked.
"ON" ( )
Position
2
3
(1) Ignition switch
(2) Ignition key
(3) Steering lock position
Function
22
Key removal
Key cannot be removed
Key can be removed
Key can be removed
