Vehicle Views - HERO PLEASURE+ PROGRAMMED FI Manual

TOP VIEW
(1) Odometer
(2) Horn switch
(3) Turn signal switch
(4) Integrated brake lever
(5) Lever lock
(6) Rear view mirror
(7) Dimmer switch
(8) High beam indicator
(9) Speedometer
(10) Fuel gauge
*Accessories and features shown may not be part of standard fitment.

VEHICLE VIEWS

(1 ) Side stand indicator 1
(1 ) 2 Turn signal indicators
(1 ) 3 Programmed FI malfunction indicator
lamp (MIL)
(14) Front brake lever
(15) Throttle grip
(16) Electric starter switch
(17) Ignition switch with steering lock
(18) USB charger
14
