Alcolizer HH3 Alcohol Tester User Manual
User Manual
Disclaimer – External Documents note to reader
The BrAC reading obtained by correct use of this device is only considered accurate at the time of testing.
Great care has been taken to ensure the accuracy of each reading.
Neither the manufacturer, the distributor, nor the owner accepts liability or responsibility due to any action
or claim arising from the reading produced by this device, whether used correctly or incorrectly.
REF: Alcolizer HH3 Alcohol Tester User Manual V6
Page 1
© Alcolizer Technology
Uncontrolled when printed

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HH3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Alcolizer HH3

  • Page 1 Neither the manufacturer, the distributor, nor the owner accepts liability or responsibility due to any action or claim arising from the reading produced by this device, whether used correctly or incorrectly. REF: Alcolizer HH3 Alcohol Tester User Manual V6 Page 1 ©...
  • Page 2: Table Of Contents

    Installing Alcoconnect Software ................18 Using AlcoCONNECT ....................19 Filtering Data ......................20 Saving Event Logs ...................... 20 Controlling Access to Data ..................21 REF: Alcolizer HH3 Alcohol Tester User Manual V6 Page 2 © Alcolizer Technology Uncontrolled when printed...
  • Page 3 Setting the date and time ..................22 7.6.1 PC Clock ......................23 7.6.2 Set Clock Manually ..................... 23 REF: Alcolizer HH3 Alcohol Tester User Manual V6 Page 3 © Alcolizer Technology Uncontrolled when printed...
  • Page 4: Introduction

    • Carry bag or metal case (optional), and • Neoprene cover (optional). Device Overview The HH3 is a handheld device consisting of a hard plastic outer case, rubberised hand grip, wrist strap and the following user displays, buttons and adaptor sockets (refer Figure 1): • Test Key, •...
  • Page 5: Test Key

    2.2.3 Mouthpiece Locator and Sample Inlet Spigot The disposable mouthpiece (sample tube) is located on the Mouthpiece Locator which surrounds the Sample Inlet Spigot (refer Figure 2). REF: Alcolizer HH3 Alcohol Tester User Manual V6 Page 5 © Alcolizer Technology...
  • Page 6: Up And Down Arrow Keys

    3 OPERATING INSTRUCTIONS CAUTION While the HH3 is a robust device, it does contain sensitive instrumentation and should not be subject to rough handling or become submerged in water. Do not store device in direct sunlight or places where extreme temperature conditions can occur.
  • Page 7: Cleaning Requirements

    Following a Passive test that indicates the presence of alcohol, a Mouthpiece test should then be performed if an accurate BrAC is required. Mouthpieces There are two types of Mouthpieces available for use on the HH3 (refer Figure 3). These are the: • Spit Trap Non Return Valve Mouthpiece, and •...
  • Page 8: Charging The Battery

    CAUTION The battery in the HH3 device is a Li-ION battery. As such it should not be tampered with in anyway. Should any problems occur that are related to the battery, contact your local Alcolizer representative for advice (1300 789 908).
  • Page 9: Turning On Device

    Figure 6 - Start Mouthpiece Test messa Testing 3.6.1 Mouthpiece Testing CAUTION To maintain a healthy sampling environment, the following procedures must be strictly adhered to. REF: Alcolizer HH3 Alcohol Tester User Manual V6 Page 9 © Alcolizer Technology Uncontrolled when printed...
  • Page 10: Taking A Mouthpiece Breath Sample

    The standard breath test time out period is 60 seconds. If a test time out does occur during a breath test, a new breath test must be performed. Perform a Mouthpiece Test as follows: REF: Alcolizer HH3 Alcohol Tester User Manual V6 Page 10 © Alcolizer Technology...
  • Page 11 The exhaled breath volume is indicated via a bar graph, scrolling left to right at the bottom of the screen. A beeping sound is also heard during the breath sample delivery phase, indicating a satisfactory breath sample is being delivered (refer Figure 11). REF: Alcolizer HH3 Alcohol Tester User Manual V6 Page 11 © Alcolizer Technology...
  • Page 12: Analysing A Mouthpiece Breath Sample

    BrAC reading. This will normally take a few seconds. In cold climate conditions it may take longer to display the BrAC reading (refer Figure 13). Analysing Sample... Figure 13 - Analysing Sample message REF: Alcolizer HH3 Alcohol Tester User Manual V6 Page 12 © Alcolizer Technology Uncontrolled when printed...
  • Page 13: Passive Testing

    REF: Alcolizer HH3 Alcohol Tester User Manual V6 Page 13 ©...
  • Page 14: Taking A Passive Breath Sample

    • Hold the device no further than 100mm in front of the test subject’s mouth; so that the subject is breathing or talking directly into the device’s sample inlet port (refer Figure 17). Figure 17 - Providing a Passive sample REF: Alcolizer HH3 Alcohol Tester User Manual V6 Page 14 © Alcolizer Technology Uncontrolled when printed...
  • Page 15: Analysing A Passive Breath Sample

    • If a Warning Alcohol Present reading is displayed the device has indicated that alcohol was detected in the near vicinity of subject’s exhaled breath (refer Figure 19). Figure 19 - Warning Alcohol Present message REF: Alcolizer HH3 Alcohol Tester User Manual V6 Page 15 © Alcolizer Technology Uncontrolled when printed...
  • Page 16: Shutting Down

    Mouthpiece Breath Test be performed, after the recovery period has ended (refer paragraph Error! Reference source not found. Shutting Down The HH3 will automatically shut down after a period of inactivity. Should the device be required to be shut down manually (e.g., to conserve battery life), perform the following procedures: •...
  • Page 17: Calibration

    It is recommended that the device be returned to Alcolizer Technology for calibration prior to the number of days to recalibration warning message expiring. This will avoid the inability and inconvenience of not being able to perform further breath testing when required.
  • Page 18: Specifications

    202mm H x 63mm W x 39mm D Calibration Six monthly recalibrations at Alcolizer’s service facility 7 ALCOCONNECT AlcoCONNECT assists in the analysis of data downloaded from the HH3 instrument. The AlcoCONNECT software can be downloaded from Alcolizer website https://www.alcolizer.com/software-updates onto a compatible computer running MS Windows®...
  • Page 19: Using Alcoconnect

    • Connect the device to the computer via the USB cable. • Double click the AlcoCONNECT icon. • Turn the HH3 device on (refer paragraph 3.5). The Read Event Log window will be displayed (refer Figure 22). Figure 22 - Read Event Log Window •...
  • Page 20: Filtering Data

    Click the “Save as type:” drop down menu and select required format (Options are CSV, XML or xlsx) Figure 24 – Saving Event Logs REF: Alcolizer HH3 Alcohol Tester User Manual V6 Page 20 © Alcolizer Technology Uncontrolled when printed...
  • Page 21: Controlling Access To Data

    Controlling Access to Data To control access to the data, files must be saved and protected by the user. Figure 26 - Event log REF: Alcolizer HH3 Alcohol Tester User Manual V6 Page 21 © Alcolizer Technology Uncontrolled when printed...
  • Page 22 • Device clock indicates what the attached device time and date are set to. The user has two options • Use PC clock • Set Clock Manually REF: Alcolizer HH3 Alcohol Tester User Manual V6 Page 22 © Alcolizer Technology Uncontrolled when printed...
  • Page 23 • Enter the time in the following format HH:MM:SS PM or HH:MM:SS AM • Click Manual Setting button • The Device clock field will now change to reflect the manually entered values. REF: Alcolizer HH3 Alcohol Tester User Manual V6 Page 23 © Alcolizer Technology...
