Alcolizer Centurion Zero Tolerance User Manual

For more information, please visit alcolizer.com
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Centurion Zero Tolerance
User Manual
Disclaimer – External Document note to reader
The qualitative alcohol reading obtained by correct use of this device is only considered accurate at the
time of testing. Great care has been taken to ensure the correctness of each reading.
Neither the manufacturer, the distributor, nor the owner accepts liability or responsibility due to any
action or claim arising from the reading produced by this device, whether used correctly or incorrectly.
Document status: ISSUED
Page 1 of 46
Version: 13
Uncontrolled document when printed

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Centurion Zero Tolerance and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alcolizer Centurion Zero Tolerance

Summary of Contents for Alcolizer Centurion Zero Tolerance

  • Page 1 Centurion Zero Tolerance User Manual Disclaimer – External Document note to reader The qualitative alcohol reading obtained by correct use of this device is only considered accurate at the time of testing. Great care has been taken to ensure the correctness of each reading.

  • Page 2: Table Of Contents

    Centurion Zero Tolerance User Manual Contents INTRODUCTION ........................5 DESCRIPTION OF THE CENTURION ZERO ................5 The Instrument ......................5 Specifications ......................5 Equipment Overview ....................6 2.3.1 External view ......................6 2.3.2 Internal view ......................7 INSTALLATION PROCEDURE ....................8 Installing the Back Plate .....................
  • Page 3 Centurion Zero Tolerance User Manual Powering the Instrument Off ................... 15 Status LEDs ....................... 16 STAT4 - Logs Status indicator................... 16 6.4.1 STAT5 - Operating status indicator..............16 Buttons ........................17 USB Keyboard......................18 6.6.1 USB Keyboard Function Keys ................18 Upgrade Kits Available .....................
  • Page 4 Centurion Zero Tolerance User Manual 12.1.1 Network Setup ....................31 12.2 Services ........................32 12.2.1 Authorisation Over Network................32 12.2.2 Alcolizer Portal ....................32 12.2.3 Enabling AlcoCONNECT Data Management Portal .......... 33 13 EMAIL ..........................34 13.1 Email Settings ......................34 13.1.1...

  • Page 5: Introduction

    If you have Zero Tolerance for Alcohol this is the device for you, and when used in conjunction with a quality Police grade Breathalyzer, such as the Alcolizer LE5, HH4 or the HH3, will deliver a total solution for your business.

  • Page 6: Equipment Overview

    • The instrument requires an adequate connection to earth/ground at all times. 2.3 Equipment Overview With a long lasting and durable steel construction, Centurion Zero Tolerance is manufactured to withstand long-term use. Weighing under 10kg, Centurion can be wall mounted in multiple, accessible locations.

  • Page 7: Internal View

    Centurion Zero Tolerance User Manual 2.3.2 Internal view USB Ports Function buttons Sample Module Brass Thumb Knob Document status: ISSUED Page 7 of 46 Version: 13 Uncontrolled document when printed...

  • Page 8: Installation Procedure

    Centurion Zero Tolerance User Manual 3 INSTALLATION PROCEDURE Installing the Back Plate 3.1.1 Mounting location When choosing a suitable mounting location, the following factors should be considered: • The instrument must be mounted on a wall or structure that can support the weight of the instrument.

  • Page 9: Mounting And Starting The Instrument

    3.2.2 Initial starting Perform the following steps for the initial start-up: 1. The Centurion Zero Tolerance will automatically begin the start-up process once you plug it into the mains power. 2. The instrument will take several minutes to start up. The loading screen will be visible.

  • Page 10: General Guidelines

    Centurion Zero Tolerance User Manual All wiring of the centurion must be performed by an appropriately trained, competent, and qualified technician. Failure to implement correct terminations may result in poor instrument operation or intermittent failure. 3.4.1 General Guidelines • DO NOT store or leave excess cable inside the cabinet.

  • Page 11: Serial Db9 Connections

    Centurion Zero Tolerance User Manual • Use of an appropriate connector is mandatory. Use connector TE Connectivity, 3- 640599-2 or compatible connector to mate with the relay headers on the PCBA. Wiring is to be as paired conductors either as twin flex cable or as a sheathed pair.

  • Page 12: Operating Instruction

    Centurion Zero Tolerance User Manual 4 OPERATING INSTRUCTION 4.1 Pre-Test Instructions • For accurate testing results, food, beverages, medications, smoking, vaping or substances that contain alcohol should not be consumed for at least 15 minutes prior to testing. • Allow 15 minutes for any potential interfering alcohol to be cleared from the donor before testing again.

  • Page 13: Analysing The Breath Sample

    Centurion Zero Tolerance User Manual b. Stop blowing when the display shows STOP BLOWING. 4.2 Analysing the breath sample The instrument will perform an analysis after the breath sample has been received and then display the result. If the BAC (Breath Alcohol concentration) detected is zero, the display will be green, indicating no alcohol was detected and stating just that result on the screen.

  • Page 14: Owner Servicing

    Centurion Zero Tolerance User Manual 5 OWNER SERVICING 5.1 Cleaning We recommend daily outside cleaning of the instrument and surrounding surfaces. We recommend cleaning be conducted using appropriate personal protective equipment (PPE) e.g.: gloves. The instrument should be cleaned with a soft cloth and antibacterial spray Do not use harsh cleaning agents, Do not use alcohol-based cleaning products, abrasive cleaning pads or chemicals.

  • Page 15: User Controls

    6.2 Powering the Instrument Off To power off a wall mount device, WM4, Centurion Zero Tolerance and Quantum, do NOT press and hold the OFF button. There are three supported ways to power off an Alcolizer Wall mounted instrument, Use a USB keyboard, navigate to Settings >...

  • Page 16: Status Leds

    The Instrument status can also be assessed by viewing the status LEDs on the main circuit board while the unit is on. Only STAT4 and STAT5 LEDs display status. If any other blinking patterns are noticed, contact your authorised Alcolizer service technician on 1300 789 908.

  • Page 17: Buttons

    DO NOT PRESS AND HOLD THE BUTTON. Pressing and holding the button may cause irreparable damage to the instrument and should only be performed by an Alcolizer Technician. Document status: ISSUED Page 17 of 46 Version: 13 Uncontrolled document when printed...

  • Page 18: Usb Keyboard

    Instrument to access certain menus during setup and fault finding. Users should not access the machine and attach a keyboard unless specifically requested to by instructions in this manual or verbally when in contact with your Alcolizer Technology technical representative.

  • Page 19: Upgrade Kits Available

    Centurion Zero Tolerance User Manual NOTE Use only the left Alt key. The right Alt key has no function. The spacebar has the same functionality as the Enter key in normal usage. When entering data, use the spacebar not the Enter key.

  • Page 20: Rfid Card Reader Upgrade Kit

    Centurion Zero Tolerance User Manual 741300 - Barcode Scanner, Datalogic GRYPHON I GFS4400 2D USB Barcode and QR code scanner for test donors to use identification cards. Wall mount keypad, can be mounted on case (retrofit required) 741270 – RFID Card Reader (Multi Format USB Reader 6 Foot Cable) Card reader for test donors to use identifying cards.
  • Page 21 Centurion Zero Tolerance User Manual 3- Use the mounting block box to pin mark two holes (Black Spots) on the mounting surface where RFID Card Reader Upgrade kit will be located 4- The Mounting block box must be screwed or drilled next to Centurion instrument using two screws that are suitable with the surface as shown below.

  • Page 22: User Interface

    Centurion Zero Tolerance User Manual 8 USER INTERFACE 8.1 Accessing the user menu To access the User Menu, perform the following steps: 1. Connect a keyboard in accordance with paragraph 6.2. 2. Press the F1 key to access the Centurion User Menu area.

  • Page 23: Status

    • Fault: The instrument has encountered a critical error and is unable to perform breath analysis. The fault must be manually cleared (or repaired) by an authorised Alcolizer service technician on 1300 789 908. • Alert: The instrument has encountered a temporary condition that is preventing the unit from performing breath analysis.

  • Page 24: Network Connections

    Centurion Zero Tolerance User Manual NOTE Status items are displayed to the user on the Status page in the instrument's current language. Each status item also includes a unique code to help identify the status item when the instrument is in a different language.

  • Page 25: Settings

    Centurion Zero Tolerance User Manual 9 Settings The settings page provides the configuration options available for the user: 9.1 Instrument Information The instrument information feature allows a customer to add user-specific descriptions of the instrument (e.g. “Site 13, Gate B”). This description is included in all email reports by default.

  • Page 26: Authorisation Code Entry

    Centurion Zero Tolerance User Manual 9.4 Authorisation Code Entry These settings are only accessible if breath test authorisation is enabled. They apply to authorisation code entry using a USB input device (keyboard, etc.). • Enabled: Check to allow authorisation codes to be entered using a USB input device.

  • Page 27: Custom Appearance

    Centurion Zero Tolerance User Manual 10 CUSTOM APPEARANCE 10.1 Background Image To import a background image, proceed as follows: 1. Connect a keyboard and access the User Menu in accordance with the procedures at paragraph 8.1. 2. From the User Menu, access the custom appearance screen by scrolling down to Custom Appearance and press enter.

  • Page 28: Intervals

    Centurion Zero Tolerance User Manual 10.3 Intervals It is possible to adjust the timings for some screen display intervals. Descriptions of how the timings apply to the display are presented for each adjustable interval. Document status: ISSUED Page 28 of 46...

  • Page 29: Logs

    Centurion Zero Tolerance User Manual 11 Logs 11.1 View The View contains the log records which consist of one or more pieces of information. Each record will show a unique log record ID entry followed by the date and time and a brief description of the logged event.

  • Page 30: Export

    Centurion Zero Tolerance User Manual 11.2 Export Logs can be exported from the instrument into USB flash drive both by using different options. • Logs / Export Menu • Functions Menu 11.2.1 Exporting Logs can be exported from the instrument into USB flash drive both by using the Export button on the Export page or automatically when a USB flash drive is inserted if configured to do so.

  • Page 31: Networks

    Centurion Zero Tolerance User Manual 12 NETWORKS 12.1 Configuration The configuration panel provide general information about the network connection and device. 12.1.1 Network Setup The network IPv4 Configuration can be set to obtain an IP address automatically or use a static IP address.

  • Page 32: Services

    Centurion Zero Tolerance User Manual 12.2 Services The services panel provide access to enable Authorisation Over Network and Alcolizer Data Management Portal. 12.2.1 Authorisation Over Network A breath test authorisation over the network can be enabled through the Americium serial protocol on a TCP/IP port.

  • Page 33: Enabling Alcoconnect Data Management Portal

    • Press Tab • Right arrow to Services tab • Press Tab twice to select Alcolizer Portal • Press Space bar to insert X to enable Alcolizer Portal • Wait for status to show as below • Status Succeeded •...

  • Page 34: Email

    Centurion Zero Tolerance User Manual 13 EMAIL 13.1 Email Settings The Centurion is equipped for forwarding email notifications of status and logs. To configure the email function, perform the following steps: 1. Establish an internet connection via the Ethernet cable. This step is not required if the instrument has a GSM modem.

  • Page 35: Settings - Server

    Centurion Zero Tolerance User Manual 13.1.2 Settings – Server The Mail Server panel allows configuration of the email account used by the instrument to send emails. This must be a valid email account as it would be configured in a desktop email program.

  • Page 36: Email Status

    Centurion Zero Tolerance User Manual 13.2 Email Status This feature has two panels: • Status: indicates the status of the email/s being sent. • Queue: emails can be seen in the queue that are ready to send; the queue can be cleared by selecting the “Clear Email Queue”...

  • Page 37: Instrument Status

    Centurion Zero Tolerance User Manual report can also include information about previous breath tests from the same authentication code. 13.3.2 Instrument Status Notification about changes in instrument status can be sent from the instrument for various types of status information. The report includes information on all currently active status items, not just the status item that changed state.

  • Page 38: Configuration

    Centurion Zero Tolerance User Manual • COM: Common connection. • NC: Normally Closed, the COM/NC circuit is closed (passes current) when the relay is not triggered and open when the relay is triggered. • NO: Normally Open, the COM/NO circuit is open when the relay is not triggered and closed (passes current) when the relay is triggered.

  • Page 39: Serial Ports

    Centurion Zero Tolerance User Manual 16 Serial Ports This page contains all configuration options for both serial ports 1 & 2, and the Americium protocol operating across them. By default, the Americium version is set to a “Recommended” configuration for Centurion Zero on both serial ports and is suitable for many situations.

  • Page 40: Self-Check

    Centurion Zero Tolerance User Manual 3. Having the “Export logs” option selected, press FN4 to start the download. 4. Use the Menu button to select “Exit” and press FN4 to return to the operational screen. 5. On the operational screen you should see a progress bar.

  • Page 41: Upgrade Software

    To upgrade the software on your Centurion, you will need a USB stick. Follow instructions below to receive/download the latest software version. NOTE Contact Alcolizer to receive the latest software version or access our website for further information. 19.1 Saving software into the USB stick 1.
  • Page 42 Centurion Zero Tolerance User Manual 2. Turn the Centurion on. 3. Ensure the device has started correctly. It should display the message “Start Blowing” on the screen. 4. Insert the USB stick with the software to any of 4 USB ports. On the main screen a message will appear “Verifying Software Upgrade Package”...

  • Page 43: Checking The Software Version In Your Centurion

    Centurion Zero Tolerance User Manual Note: If FN2 switch is not pressed within 45 seconds, update process will be aborted. To restart upgrade process, remove USB stick and reconnect it. 6. Ensure “Apply Software Update” is highlighted. Press “Select” button (FN4 Button)”...
  • Page 44 Centurion Zero Tolerance User Manual Document status: ISSUED Page 44 of 46 Version: 13 Uncontrolled document when printed...

  • Page 45: Calibration

    ASM, the same method applies in reverse. Ensuring the thumb bolt is not screwed in too tightly. The sample module that was removed needs to be sent to your nearest Alcolizer Pty Ltd distributor in the packaging supplied as per the instructions accompanying your replacement module.

  • Page 46: Document Status: Issued

    22 Troubleshooting In the event the instrument may malfunction or a warning message should appear on the screen, consult Alcolizer Technology in the first instance. Contact Alcolizer Technology by any of the following means: T: 1300 789 908 service@alcolizer.com www.alcolizer.com...
