5 - USER INTERFACE: MENU STRUCTURE

5.9 - Alarms menu

Home Previous screen
Current Alarms
Reset Alarms
The Alarms menu allows the user to monitor alarms that occurred
on the unit as well as reset alarms that require manual reset.
■ To access the Alarms menu, press the Alarms menu button
located in the upper-right part of the Home screen.
The Alarm history is divided into two parts:
■ Alarm Historic that displays up to 50 recent general alarms.
■ Alarm Major Historic that displays up to 50 recent major alarms,
including alarms connected with process failure, compressor
failure, and VFD drives.
IMPORTANT: For more information about alarms, please go
to section 8.6.
CUR_ALM – Current Alarms
No. Name Date
1 Alarm YYYY/MM/DD
... Alarm YYYY/MM/DD
10 Alarm YYYY/MM/DD
*Depends on the selected language (English by default).
ALMHIST1 – Alarm Historic
No. Name Date
1 Alarm YYYY/MM/DD
... Alarm YYYY/MM/DD
50 Alarm YYYY/MM/DD
*Depends on the selected language (English by default).
32
Main Menu System Menu
Alarms menu
Alarm Historic
Hour Alarm text
HH:MM Alarm text (see section 8.6)
HH:MM Alarm text (see section 8.6)
HH:MM Alarm text (see section 8.6)
Hour Alarm text
HH:MM Alarm text (see section 8.6)
HH:MM Alarm text (see section 8.6)
HH:MM Alarm text (see section 8.6)
User Login Start / Stop
Major Alarm Historic
Legend:
Basic access (no password)
User password required
Alarms Menu
