Carrier SmartVu control Manual page 18

5 - USER INTERFACE: MENU STRUCTURE
MODES – Modes
No. Name Status
1 m_delay no/yes
2 m_2ndspt no/yes
3 m_reset no/yes
4 m_limit no/yes
5 m_ramp no/yes
6 m_cooler no/yes
7 m_pmprot no/yes
8 m_pmpper no/yes
9 m_night no/yes
10 m_SM no/yes
11 m_leadla no/yes
12 m_auto no/yes
13 m_heater no/yes
14 m_lo_ewt no/yes
15 m_boiler no/yes
16 m_ice no/yes
17 m_defr_a no/yes
18 m_defr_b no/yes
19 m_sst_a no/yes
20 m_sst_b no/yes
21 m_dgt_a no/yes
22 m_dgt_b no/yes
23 m_hp_a no/yes
24 m_hp_b no/yes
25 m_sh_a no/yes
26 m_sh_b no/yes
*Depends on the selected language (English by default).
Trendings
No. Name Status
1 TEMP_LWT -
2 TEMP_EWT -
3 TEMP_SCT_A -
4 TEMP_SST_A -
5 TEMP_SCT_B -
6 TEMP_SST_B -
*Depends on the selected language (English by default).
OPT_STA – Software Options
No. Name Status
1 opt5 no/yes
2 opt6 no/yes
3 opt149 no/yes
4 opt149B no/yes
*Depends on the selected language (English by default).
18
Unit Displayed text*
- Delay Active
- Second Setpoint Active
- Reset Active
- Demand Limit Active
- Ramp Loading Active
- Cooler Heater Active
- Pump Rot Active
- Pump Per Active
- Night Low Noise Active
- System Manager Active
- Master Slave Active
- Auto Changeover Active
- Electric Heat Active
- Heating Low EWT Lockout
- Boiler Active
- Ice Mode Active
- Defrost Active On Cir A
- Defrost Active On Cir B
- Low Suction Circuit A
- Low Suction Circuit B
- High DGT Circuit A
- High DGT Circuit B
- High Pres Override Cir A
- High Pres Override Cir B
- Low SuperHeat Circuit A
- Low SuperHeat Circuit B
Unit Displayed text*
°C/°F -
°C/°F -
°C/°F -
°C/°F -
°C/°F -
°C/°F -
Unit Displayed text*
- OPT5: Medium Brine
- OPT6: Low Brine
- OPT149: BACnet
- OPT149B: Modbus
Description
Delay active (when switching between modes)
Second setpoint active (during unoccupied periods)
Reset is active
Demand limit active
Ramp loading active
Water exchanger heater active
Pump rotation active
Periodical pump start active
Night low noise mode active
System Manager active
Master/Slave active
Auto changeover active
Electric heating active
Heating low EWT lockout
Boiler active
Not applicable
Defrost active, circuit A
Defrost active, circuit B
Low suction temperature, circuit A
Low suction temperature, circuit B
High discharge gas temperature, circuit A
High discharge gas temperature, circuit B
High pressure override, circuit A
High pressure override, circuit B
Low superheat, circuit A
Low superheat, circuit B
Description
Leaving water temperature
Entering water temperature
Saturated suction temperature, circuit A
Saturated suction temperature, circuit B
Saturated condensing temperature, circuit A
Saturated condensing temperature, circuit B
Description
Parameter set to "yes" means that Medium brine option which
requires the Software Key is activated (see section 6.20)
Parameter set to "yes" means that Low brine option which
requires the Software Key is activated (see section 6.20)
Parameter set to "yes" means that BACnet option which
requires the Software Key is activated (see also section 6.21)
Parameter set to "yes" means that Modbus option which
requires the Software Key is activated (see also section 6.22)
