5 - USER INTERFACE: MENU STRUCTURE
RUNTIME – Runtime
No. Name Status
1 hr_mach -
2 st_mach -
3 hr_cp_a1 -
4 st_cp_a1 -
5 hr_cp_a2 -
6 st_cp_a2 -
7 hr_cp_a3 -
8 st_cp_a3 -
9 hr_cp_b1 -
10 st_cp_b1 -
11 hr_cp_b2 -
12 st_cp_b2 -
13 hr_cpum1 -
14 hr_cpum2 -
15 hr_fana1 -
16 st_fana1 -
17 hr_fana2 -
18 st_fana2 -
19 hr_fanb1 -
20 st_fanb1 -
21 nb_def_a -
22 nb_def_b -
*Depends on the selected language (English by default).
DCFC_STA – DC Free Cooling Status
No. Name Status
1 oat -
2 lwt -
3 wloop -
4 m_dcfc no/yes
5 dcfc_cap 0 to 100
6 f_stage 0 to 10
7 vf_speed 0 to 100
8 pid_out 0 to 100
9 FC_HOUR 0 to 999999
10 FC_FAN1S 0 to 999999
11 FC_FAN1H 0 to 999999
12 FC_FAN2S 0 to 999999
13 FC_FAN2H 0 to 999999
14 FC_FAN3S 0 to 999999
15 FC_FAN3H 0 to 999999
16 FC_FAN4S 0 to 999999
17 FC_FAN4H 0 to 999999
18 FC_FAN5S 0 to 999999
19 FC_FAN5H 0 to 999999
20 FC_FAN6S 0 to 999999
21 FC_FAN6H 0 to 999999
22 FC_FAN7S 0 to 999999
23 FC_FAN7H 0 to 999999
24 FC_VFANS 0 to 999999
25 FC_VFANH 0 to 999999
*Depends on the selected language (English by default).
Unit Displayed text*
hour Machine Operating Hours
- Machine Starts Number
hour Compressor A1 Hours
- Compressor A1 Starts
hour Compressor A2 Hours
- Compressor A2 Starts
hour Compressor A3 Hours
- Compressor A3 Starts
hour Compressor B1 Hours
- Compressor B1 Starts
hour Compressor B2 Hours
- Compressor B2 Starts
hour Water Pump #1 Hours
hour Water Pump #2 Hours
hour Circuit A Fan #1 Hours
- Circuit A Fan #1 Starts
hour Circuit A Fan #2 Hours
- Circuit A Fan #2 Starts
hour Circuit B Fan #1 Hours
- Circuit B Fan #1 Starts
- Circuit A Defrost Number
- Circuit B Defrost Number
Unit Displayed text*
°C/°F OAT Free Cooling
°C/°F FC Leaving Water Temp
°C/°F FC Water Loop Temp
- Free Cooling Mode Active
% FC Capacity
- Fix Speed Fans Stage
% Varifan Speed
% PID Output
hour DCFC Operating Hours
- DCFC Fan Stage 1 Start
hour DCFC Fan Stage 1 Hours
- DCFC Fan Stage 2 Start
hour DCFC Fan Stage 2 Hours
- DCFC Fan Stage 3 Start
hour DCFC Fan Stage 3 Hours
- DCFC Fan Stage 4 Start
hour DCFC Fan Stage 4 Hours
- DCFC Fan Stage 5 Start
hour DCFC Fan Stage 5 Hours
- DCFC Fan Stage 6 Start
hour DCFC Fan Stage 6 Hours
- DCFC Fan Stage 7 Start
hour DCFC Fan Stage 7 Hours
- DCFC Variable Fan Start
hour DCFC Variable Fan Hours
Description
Unit operating hours
Number of unit starts
Operating hours, compressor A1
Number of starts, compressor A1
Operating hours, compressor A2
Number of starts, compressor A2
Operating hours, compressor A3
Number of starts, compressor A3
Operating hours, compressor B1
Number of starts, compressor B1
Operating hours, compressor B2
Number of starts, compressor B2
Operating hours, water pump 1
Operating hours, water pump 2
Operating hours, fan 1, circuit A
Number of starts, fan 1, circuit A
Operating hours, fan 2, circuit A
Number of starts, fan 2, circuit A
Operating hours, fan 1, circuit B
Number of starts, fan 1, circuit B
Defrost session number, circuit A
Defrost session number, circuit B
Description
OAT Free Cooling (see section 6.11)
Free Cooling LWT
Free Cooling Water Loop Temperature
Free Cooling Mode Status
Capacity in Free Cooling Mode
Actual Fix Speed Fans Stage
Actual Varifan Speed
PID Output Value
Dry Cooler Free Cooling running time
Number of starts, DCDCFC stage 1
Operating hours, DCFC stage 1
Number of starts, DCFC stage 2
Operating hours, DCFC stage 2
Number of starts, DCFC stage 3
Operating hours, DCFC stage 3
Number of starts, DCFC stage 4
Operating hours, DCFC stage 4
Number of starts, DCFC stage 5
Operating hours, DCFC stage 5
Number of starts, DCFC stage 6
Operating hours, DCFC stage 6
Number of starts, DCFC stage 7
Operating hours, DCFC stage 7
Number of starts, DCFC variable speed fan
Operating hours, DCFC variable speed fan
