Carrier SmartVu control Manual page 15

5 - USER INTERFACE: MENU STRUCTURE
PRESSURE – Pressure
No. Name Status
1 DP_A -
2 SP_A -
3 DP_B -
4 SP_B -
*Depends on the selected language (English by default).
SETPOINT – Setpoint
No. Name Status
-28.9 to 20.0
1 csp1
-20.0 to 68.0
-28.9 to 20.0
2 csp2
-20.0 to 68.0
25.0 to 55.0
3 hsp1
77.0 to 131.0
25.0 to 55.0
4 hsp2
77.0 to 131.0
0.1 to 1.1
5 ramp_sp
0.2 to 2.0
3.9 to 50.0
6 cauto_sp
39.0 to 122.0
0 to 46.1
7 hauto_sp
32.0 to 115.0
8 lim_sp1 0 to 100
9 lim_sp2 0 to 100
10 lim_sp3 0 to 100
26.7 to 60.0
11 min_sct
80.0 to 140.0
*Depends on the selected language (English by default).
INPUTS – Inputs
No. Name Status
1 ONOFF_SW open/close
2 HC_SW open/close
3 on_ctrl xxx
4 SETP_SW open/close
5 LIM_SW1 open/close
6 LIM_SW2 open/close
7 LIM_ANAL -
8 FLOW_SW open/close
9 leak_v1 -
10 leak_v2 -
11 DSHT_SW open/close
12 PWRIN_ST open/close
13 HP_SWA open/close
14 HP_SWA3B open/close
*Depends on the selected language (English by default).
Unit Displayed text*
kPa/PSI Discharge Pressure A
kPa/PSI Suction Pressure A
kPa/PSI Discharge Pressure B
kPa/PSI Suction Pressure B
Default Unit Displayed text*
7.0 °C
Cooling Setpoint 1
44.6 °F
7.0 °C
Cooling Setpoint 2
44.6 °F
38.0 °C
Heating Setpoint 1
100.4 °F
38.0 °C
Heating Setpoint 2
100.4 °F
0.6 ^C
Ramp Loading
1.0 ^F
23.9 °C
Cool Changeover Setpt
75.0 °F
17.8 °C
Heat Changeover Setpt
64.0 °F
100 % Switch Limit Setpoint 1
100 % Switch Limit Setpoint 2
100 % Switch Limit Setpoint 3
40.0 °C
Desuperheater Min Sct
104.0 °F
Unit Displayed text*
- Remote On/Off Switch
- Remote Heat/Cool Switch
- Current Control
- Remote Setpoint Switch
- Limit Switch 1
- Limit Switch 2
mA Limit Analog Input
- Cooler Flow Switch
V Leakage detector #1 val
V Leakage detector #2 val
- Desuperheater Switch
- Power Input Stable
- HP Switch Circuit A
- HP Switch Circuit A2/B
Description
Compressor discharge pressure, circuit A
Compressor suction pressure, circuit A
Compressor discharge pressure, circuit B
Compressor suction pressure, circuit B
Description
Cooling setpoint 1
Cooling setpoint 2
Heating setpoint 1
Heating setpoint 2
Ramp loading
Cool changeover setpoint
Heat changeover setpoint
Switch limit setpoint 1
Switch limit setpoint 2
Switch limit setpoint 3
Desuperheater minimum saturated condensing
temperature
Description
Remote On/Off switch
Remote Heat/Cool switch
Current control status: Off, On Cool, On Heat, On Auto
Remote setpoint switch:
open = setpoint 1
closed = setpoint 2
Demand limit switch 1
Demand limit switch 2
Limit Analog Input 4-20mA
Water exchanger flow switch
Leakage detector 1
Leakage detector 2
Desuperheater switch
Power input stable
High pressure switch, circuit A
High pressure switch, circuit A2** / B
**A2 applies to units with 3 compressors: HP switch A is connected
to the second HP switch input)
