1. About the product

When construction and building the heat pump all relevant
EU guidelines have been followed. (Also se EU-declaration
of conformity)
Any work carried out on this unit may only be
done by skilled personnel. Take all necessary
precautions to avoid accidents.

1.1 Scope of delivery

• Heat pump with built-in control
• Installation manual with technical data
• Operating instructions

1.2 Product description

Vanvex RS is a domestic water heat pump with a condenser
on the outside of the boiler. The application area and
operating principles of the heat pump are specified in the
operating instructions.

1.3 Technical data

Domestic hot water heat pump Vanvex R OPTIMA 155
Diameter without pipe connectionr mm
High
Weight without water
Electrical connection
Heat pump safety
Cooling medier
Performance data
Performance specified for heating of domestic water from
15°C (could water) to 45°C (domestic water)
Thermal output (with air 15°C /
water 15°C – 45°C
Power input (with air 15°C / water
15°C – 45°C)
COP (with air 15°C / water 15°C
– 45°C)
Power consumption electrical
heating element
Operating range / limits
Max. air temperature
Max. water temperature (with the
heat pump on)
Max. water temperature (with
operation of heat pump and
electrical heating element)
Sound level
1 meter in front of unit
Ø660
mm 1837
kg 105
V/Hz 230/50
A 10
-/kg R134a /1,0
kW 1,52
kW 0,43
- 3,54
kW 1,5
°C 35
°C 55
°C 65
dB(A) 52
- Technishce Änderungen vorbehalten -
Installation Manual
Domestic water boiler
Material
Net volume
Airflow volume
Airflow volume (free flow)
1.4 Refrigerant circuit – description
The cooling system is used for processing the heat in the
inlet air. This is the manner by which the extracted heat is
transferred to the water. This process is only possible with
the external addition of energy, which takes place in the
compressor.
In the vaporiser, heat is absorbed from the air and refrigerant
in gaseous form and fed to the compressor. In the compressor,
the refrigerant is raised up to a higher pressure and energy
level, so it can deliver the heat to the water through the
condenser pipe, which is coiled around the tank. The
condensed coolant fluid is throttled down to a lower pressure
using the expansion valve so it becomes possible to repeat
the cooling cycle in the evaporiser.
Steel specially
enamelled
Litre 285/279
m³/h 250
3
