- Page 1 Installation and operating instructions for Brake DT XXX FEA-XXX H-ST E 09.793e Schaberweg 30-38 Phone +49 6172 275 0 www.ringspann.com 61348 Bad Homburg +49 6172 275 275 info@ringspann.com Germany...
- Page 2 Disregarding or misinterpreting these installation and operating instructions invalidates any product liability or guarantee by RINGSPANN; the same applies if the product is taken apart or changed. These installation and operating instructions should be kept in a safe place and should accompany the product if it is passed on to others -either on its own or as part of a machine- to make it accessible to the user.
-
Page 3: Table Of Contents
Intended use Impermissible use Condition as delivered Handling and storage Technical prerequisite for reliable operation Installing the RINGSPANN brake 8.1 General instructions regarding assembly and installation 8.2 Assembly description 8.3 Adjusting / readjusting the brake pad distance Start-up 10. Disassembling the brake 11. -
Page 4: General Notes
Installation and operating instructions for E 09.793e Brake DT XXX FEA-XXX H-ST spring activated – electro hydraulically released Issue: 12.05.2021 Version: 2 Drawn: BAHS Checked: EISF Pages: 22 Page: 4 General notes 1.1 General safety instructions Read these installation/operating instructions carefully before putting the brake into operation. Consider these instructions as well as the drawings in the individual sections. -
Page 5: Identification
As well as these instructions, please also consider the catalogue data for the brake at www.ringspann.com and the drawings in the individual sections. -
Page 6: Drawing And Parts List
Installation and operating instructions for E 09.793e Brake DT XXX FEA-XXX H-ST spring activated – electro hydraulically released Issue: 12.05.2021 Version: 2 Drawn: BAHS Checked: EISF Pages: 22 Page: 6 2.3 Drawing and parts list Overview illustration of brake DT XXX FEA-XXX H-ST NC with all options for details look into catalog. -
Page 7: Intended Use
1.5mm. Handling and storage The technical data of the brake such as clamping force, oil volume, dimensions and weight are shown on the catalogue pages for the brake. The current data can also be found on the RINGSPANN website www.ringspann.com. -
Page 8: Technical Prerequisite For Reliable Operation
Fastening the brake on low vibration stability machine parts will ensure quiet braking without creaking. Installing the RINGSPANN brake 8.1 General instructions regarding assembly and installation Before installing the brake, the brake drum must be cleaned with alcohol (e.g. spirit (ethanol) or isopropyl alcohol) or with water-based tenside solutions (soapy water or the like). - Page 9 Installation and operating instructions for E 09.793e Brake DT XXX FEA-XXX H-ST spring activated – electro hydraulically released Issue: 12.05.2021 Version: 2 Drawn: BAHS Checked: EISF Pages: 22 Page: 9 Important! Leaked oil must be completely removed. Leaks are to be removed immediately! Before mounting onto the brake drum, the brake caliper must be released (opened) and adjusting the distance pad to the brake drum.
- Page 10 Installation and operating instructions for E 09.793e Brake DT XXX FEA-XXX H-ST spring activated – electro hydraulically released Issue: 12.05.2021 Version: 2 Drawn: BAHS Checked: EISF Pages: 22 Page: 10 The connecting plate for the brake as well as the brake drum must be checked for dimensional accuracy.
- Page 11 Installation and operating instructions for E 09.793e Brake DT XXX FEA-XXX H-ST spring activated – electro hydraulically released Issue: 12.05.2021 Version: 2 Drawn: BAHS Checked: EISF Pages: 22 Page: 11 Important! If the brake calliper is manually released, this manual release must be removed again to ensure a functional brake! Electric connection: The cable may entry from both sides of terminal box.
- Page 12 Installation and operating instructions for E 09.793e Brake DT XXX FEA-XXX H-ST spring activated – electro hydraulically released Issue: 12.05.2021 Version: 2 Drawn: BAHS Checked: EISF Pages: 22 Page: 12 Fig. 8.2 8.3 Setting / adjusting of the brake pad distance The brake pad distance is set after the brake calliper has been assembled and after pad wear through adjusting / readjusting, see Fig.
- Page 13 Installation and operating instructions for E 09.793e Brake DT XXX FEA-XXX H-ST spring activated – electro hydraulically released Issue: 12.05.2021 Version: 2 Drawn: BAHS Checked: EISF Pages: 22 Page: 13 Fig. 8.3 Maintenance setting / adjusting FEA automatic wear compensator •...
- Page 14 Installation and operating instructions for E 09.793e Brake DT XXX FEA-XXX H-ST spring activated – electro hydraulically released Issue: 12.05.2021 Version: 2 Drawn: BAHS Checked: EISF Pages: 22 Page: 14 Maintenance FEA manual setting / adjustment for changing brake pads with reset the automatic wear compensator •...
- Page 15 Installation and operating instructions for E 09.793e Brake DT XXX FEA-XXX H-ST spring activated – electro hydraulically released Issue: 12.05.2021 Version: 2 Drawn: BAHS Checked: EISF Pages: 22 Page: 15 Important! It's very important verifying the stop position of the piston, taking into account that it should not go closer than 10-15mm see Fig.
-
Page 16: Start-Up
Installation and operating instructions for E 09.793e Brake DT XXX FEA-XXX H-ST spring activated – electro hydraulically released Issue: 12.05.2021 Version: 2 Drawn: BAHS Checked: EISF Pages: 22 Page: 16 Important! It must be ensured that the brake pad (item 2) do not grind on the brake drum while the brake is released! Important! If the brake is released by Hand release lever (item 9), this hand release lever... -
Page 17: Disassembling The Brake
Installation and operating instructions for E 09.793e Brake DT XXX FEA-XXX H-ST spring activated – electro hydraulically released Issue: 12.05.2021 Version: 2 Drawn: BAHS Checked: EISF Pages: 22 Page: 17 10. Disassembling the brake Life-threatening danger! When disassembling the brake it is to be ensured that the entire drive train is secured against being switched on unintentionally. -
Page 18: Maintenance
If you have no wear at the brake pad after 5 - 7 years working time you also have to replace the brake pads. Because of the brake pad age you will loose brake performance. Only original RINGSPANN brake pads may be used. -
Page 19: Options
Installation and operating instructions for E 09.793e Brake DT XXX FEA-XXX H-ST spring activated – electro hydraulically released Issue: 12.05.2021 Version: 2 Drawn: BAHS Checked: EISF Pages: 22 Page: 19 Before exchanging the brake pads, ensure that the mass held by the brake is secured against moving, since parts of the brake need to be loosened for this purpose. - Page 20 Installation and operating instructions for E 09.793e Brake DT XXX FEA-XXX H-ST spring activated – electro hydraulically released Issue: 12.05.2021 Version: 2 Drawn: BAHS Checked: EISF Pages: 22 Page: 20 General data -25°C … +80°C Ambient temperature: Max. actuation frequency: 3600 operating cycles1/hour Mechanical endurance: 20 million operating cycles...
- Page 21 Installation and operating instructions for E 09.793e Brake DT XXX FEA-XXX H-ST spring activated – electro hydraulically released Issue: 12.05.2021 Version: 2 Drawn: BAHS Checked: EISF Pages: 22 Page: 21 Fig. 12.2 The installation of the micro-switch brake on/off. The micro-switch signaling brake on/off has the role of confirming the executed opening of the brake.
-
Page 22: Handrelease
Installation and operating instructions for E 09.793e Brake DT XXX FEA-XXX H-ST spring activated – electro hydraulically released Issue: 12.05.2021 Version: 2 Drawn: BAHS Checked: EISF Pages: 22 Page: 22 washer pushes the taster of the micro-switch and give the signal. If the signal pad wear comes to soon the adjusting parts spindle brake pad wear has to be turn back.
