P. Technical specifications

1. Physical characteristics - LS100 IQ / LS100 ENERGY

Dimensions (L x w x h): machine
Net weight: machine
Dimensions (L x w x h): machine + packing
Weight: machine + packing
Table surface
Engraving area
Weight: permissible object
Dimensions (L x w x h): permissible object
Travel distance Z
Surface flatness

2. Physical characteristics - LS100 EX / LS100 EX ENERGY

Dimensions (L x w x h): machine
Net weight: machine
Dimensions (L x w x h): machine + packing
Weight: machine + packing
Table surface
Engraving area
Weight: permissible object
Dimensions (L x w x h): permissible object
Travel distance Z
Surface flatness
M_LS100IQ EX Energy_EN_C
LS100 IQ
775 mm (30.512 in) x 725 mm (28.543 in) x 450 mm (17.717 in)
Maximum: 43 kg (94.799 lb)
840 mm (33.071 in) x 900 mm (35.433 in) x 630 mm (24.803 in)
Maximum: 66 kg (145.505 lb)
506 mm (19.921 in) x 330 mm (12.992 in)
Maximum: 460 mm (18.110 in) x 305 mm (12.008 in)
Maximum: 15 kg (33.069 lb)
506 mm (19.921 in) x 330 mm (12.992 in) x 145 mm (5.709 in)
145 mm (5.709 in)
< 0.2 mm (0.008 in)
LS100 EX
1025 mm (40.354 in) x 725 mm (28.543 in) x 450 mm (17.717 in)
Maximum: 70 kg (154.324 lb)
890 mm (35.039 in) x 1150 mm (45.276 in) x 685 mm (26.968 in)
Maximum: 92 kg (202.825 lb)
760 mm (29.921 in) x 330 mm (12.992 in)
Maximum: 610 mm (24.016 in) x 305 mm (12.008 in)
Maximum: 20 kg (44.092 lb)
740 mm (29.134 in) x 330 mm (12.992 in) x 145 mm (5.709 in)
145 mm (5.709 in)
< 0.2 mm (0.008 in)
LS100 ENERGY
Maximum: 40 kg (88.185 lb)
Maximum: 63 kg (138.891 lb)
< 0.3 mm (0.012 in)
LS100 EX ENERGY
Maximum: 67 kg (147.710 lb)
Maximum: 89 kg (196.211 lb)
< 0.3 mm (0.012 in)
