M. Using the machine
Example: Engraving a keyring

1. Switching on the PC / Switching on the machine

1. Switch on the PC.
2. Wait until start-up is complete.
3. Switch on the machine.

2. Creating the composition

1. Adjust the page size to the maximum size of the engraving area in the graphics software (LS100 IQ
/ ENERGY: 460 mm (18.110 in) x 305 mm (12.008 in) - LS100 EX / EX ENERGY: 610 mm (24.016 in)
x 305 mm (12.008 in)).
2. Enter the text to be marked. It should have a black fill and no contour.
Example: enter "ABCDE".
3. Position the text in the top left corner of the page, depending on the position of the keyring on the
engraving table.
Screen (PC)
ABCDE

3. Setting the driver properties

Refer to the manual (L-Solution driver).
