Connections - Installation
Input / Output characteristics (Sub-D15 connector)
Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Note: The loads switched by the NPN outputs can be powered by 5 V / 24 V.
Wiring example -
24 V inductive load
M_LS100IQ EX Energy_EN_C
Function Type:
O1 Output NPN
O2 Output NPN
O3 Output NPN
O4 Output NPN
5 V Available for powering the loads
switched by the NPN outputs (O1 -
O4)
I1 dry contact
Input
I3 dry contact
Input
Gnd Grounding
Available for powering the loads
24 V switched by the NPN outputs (O1 -
O4)
Gnd Grounding
I2 dry contact
Input
I4 dry contact
Input
Comments
Maximum current: 50 mA
Maximum current: 50 mA
Maximum current: 50 mA
Maximum current: 50 mA
Maximum current: 200 mA
TTL-compatible
TTL-compatible
The grounds are shared by pins
8-11-12-13.
Maximum current: 100 mA
Maximum current: 100 mA
The grounds are shared by pins
8-11-12-13.
TTL-compatible
TTL-compatible
Wiring example -
5 V inductive load
