Altronix ALTV615DC Series Installation Manual page 2

These Altronix DC CCTV Power Supplies provide 6-15VDC distributed via sixteen (16) fuse or PTC protected outputs
for powering CCTV Cameras, heaters and other video accessories.
Altronix
Model Number
ALTV615DC1016
ALTV615DC1016CB
• Sixteen (16) individual outputs.
• Filtered and electronically regulated outputs.
• Short circuit and thermal overload protection.
• Unit maintains camera synchronization.
1. Mount unit in desired location.
2. Connect AC power to the two black and two white flying leads of the transformer (Fig. 1, pg. 3). Use 18 AWG or
larger for all power connections (Battery, DC output).
Units with linecord installed skip Instruction #2.
3. Adjust output voltage using trimpot on the power supply board prior to connecting CCTV devices.
4. Measure output voltage before connecting devices. This helps avoid potential damage.
Terminals marked [1P - 8P] are positive (+) and terminals marked [1N - 8N] are negative.
CAUTION: Determine the maximum operating voltage of the equipment being powered before adjusting the
output voltage.
5. Connect devices to terminals marked [1P - 1N through 8P - 8N] on PD8UL/PD8ULCB board (Fig. 1, pg. 3) carefully
observing correct polarity.
6. Green LED will illuminate when unit is powered.
7. Upon completion of wiring, secure enclosure door with screws (supplied).
Caution: Equipment to be installed / serviced by authorized / trained personnel only.
Shut branch circuit power before installing / servicing equipment.
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture.
This installation should be made by qualified service personnel and should conform to all local codes
and in accordance with the National Electrical Code.
Sixteen (16) Output ALTV615DC Reference Chart:
10 amp 6-15VDC
10 amp 6-15VDC
Installation Instructions:
Overview:
16 - x
16 x -
Specifications:
• Ease of installation saves time & eliminates costly labor.
• Spare fuses included (on fuse protected models).
Enclosure Dimensions:
13"H x 13.5"W x 3.25"D
- 2 -
3.5 amp 1.9 amp
2.5 amp 1.9 amp
